P-187-001 - 第217页
MODEL TCM-X300 0306-001 Key No. P AR T No. P AR T NAME Q’ ty REMARKS NOTE 215 MA-10 90 1 630 120 5717 C OV ER (P AN EL ) 1 812MA-010-901 90 2 630 1 10 6663 ASSY ,UNIT ,DISPLA Y 1 812MA-010-902 90 2 -01 630 1 10 6618 UN I…
MODEL TCM-X300
0306-001
214
ࠞࡃㇱ COVER SECTION
Fig. MA-10 ೨㕙ᠲࡄࡀ࡞ Front Operation Panel
902
904
928
908
937
907
912
909
923
A
911
936
912
918
911
902-01
902-02
902-04
902-05
902-03
914
913
922
A
905
927
926
925
906
924
921
901
920
919
934
931
929
903
924
932
933
930
See Fig.MB-6
See Fig.RL-6
MODEL TCM-X300
0306-001
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
215
MA-10
901 630 120 5717 COVER(PANEL) 1 812MA-010-901
902 630 110 6663 ASSY,UNIT,DISPLAY 1 812MA-010-902
902 -01 630 110 6618 UNIT,DISPLAY(FRONT) 1
902 -02 630 110 6632 CORD(3M) 1
902 -03 630 110 6656 UNIT,DISPLAY(REAR) 1
902 -04 630 110 6649 CORD(5M) 1
902 -05 630 110 6625 UNIT,DRIVER(CONTROLLER) 1
903 630 118 1783 COVER 1 812MA-010-903
904 630 109 6346 SWITCH,KEYBOARD(JOYSTICK) 1 SPB1,LED1,SPB10(LED10),SPB11,
LED11,SPB12(LED12),SPB13(LED13),
SW3,#LE-0100-03 812MA-010-904
905 630 109 3017 COVER 1 812MA-010-905
906 630 109 3024 STAY 1 812MA-010-906
907 630 109 6919 BRACKET 1 812MA-010-907
908 630 110 1767 MECH PARTS(STAY) 1 812MA-010-908
909 630 110 6120 SPRING,TENSION 2 812MA-010-909
911 411 141 2905 WASHER SPR 4 6 812MA-010-911
912 411 141 4008 WASHER V 4X9X0.8 6 812MA-010-912
913 630 106 5670 MECH PARTS(URETHANS) 2 812MA-010-913
914 630 000 7725 BOLT,HEX-SCT 2 812MA-010-914
918 630 000 7626 BOLT,HEX-SCT 4 812MA-010-918
919 411 042 0703 SCR PAN 3X8 7 812MA-010-919
920 411 086 4408 WASHER SPR 3 7 812MA-010-920
921 411 119 1909 WASHER V 3X7X0.5 7 812MA-010-921
922 411 140 8007 SCR TRS 5X6 2 812MA-010-922
923 411 140 7208 SCR FLT 4X6 2 812MA-010-923
924 411 051 1708 SCR TRS 4X6 8 812MA-010-924
925 630 000 7879 BOLT,HEX-SCT 2 812MA-010-925
926 411 141 3001 WASHER SPR 6 2 812MA-010-926
927 630 001 0237 WASHER 2 812MA-010-927
928 630 120 7988 NAME PLATE,PARTS 1 812MA-010-928
929 630 120 5724 PLATE 1 812MA-010-929
930 630 120 5731 PLATE 1 812MA-010-930
931 630 120 5748 PLATE 1 812MA-010-931
932 630 118 1974 PLATE 1 812MA-010-932
933 630 118 1981 PLATE 1 812MA-010-933
934 411 140 7901 SCR TRS 3X4 10 812MA-010-934
936 630 000 7633 BOLT,HEX-SCT 2 812MA-010-936
937 411 035 2707 SCR FLT 4X8 2 812MA-010-937
MODEL TCM-X300
0306-001
216
ࡈࠖ࠳ࠠࡖ࠶ࠫࠞࡃㇱ FEEDER CARRIAGE COVER SECTION
Fig. MB-1 ᓟ㕙ࠞࡃ Rear Cover
47
24
46
45
47
46
45
47
40
45
46
43
41
42
44
40
41
42
45
46
2
40
41
42
1
47
45
46
46
45
47
40
41
42
46
45
43
44
46
24
45
47
49
45
39
18
44
19
44
20
38
49
45
43
21
46
29
30
32
6
7
21
6
7
21
8
38
40
41
42
21
46
21
46
21
21
46
17
21
42
21
46
48
48
45
46
34
45
46
44
27
44
38
5
48
45
46
34
16
12
21
46
42
21
41
40
48
45
46
26
38
4
41
40
13
45
43
49
38
20
8
38
42
40
41
36
44
35
44
46
21
21
46
