MODEL TCM-X300 0306-001 Key No. P AR T No. P AR T NAME Q’ ty REMARKS NOTE 289 SA-1 51 630 095 3817 N AME PLA TE,P ARTS 1 812SA-010-051 52 630 097 8094 N AME PLA TE,P ARTS 1 812SA-010-052 53 630 120 4635 N AME PLA TE,P AR…

100%1 / 306
MODEL TCM-X300
0306-001
288
㌏᧼ NAME PLATE
Fig. SA-1 ⵝ⟎㌏᧼ Name Plate for Machine
51
54
52
52
See Fig.MB-6
Key No.504
See Fig.MA-1
Key No.31
See Fig.RK-1
Key No.57
See Fig.MB-6
Key No.505
See Fig.MA-8
Key No.701
55
57
See Fig.RL-4
Key No.366
See Fig.RG-1
Key No.51
58
53
See Fig.MA-1
Key No.20
MODEL TCM-X300
0306-001
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
289
SA-1
51 630 095 3817 NAME PLATE,PARTS 1 812SA-010-051
52 630 097 8094 NAME PLATE,PARTS 1 812SA-010-052
53 630 120 4635 NAME PLATE,PARTS 1 812SA-010-053
54 630 122 4848 NAME PLATE,PARTS 1 812SA-010-054
55 630 120 4666 NAME PLATE,PARTS 1 812SA-010-055
57 630 120 9555 NAME PLATE,PARTS 1 812SA-010-057
58 630 120 9593 NAME PLATE,PARTS 1 812SA-010-058
MODEL TCM-X300
0306-001
290
ࠤ࡯ࡉ࡞㈩✢ CABLE WIRING
Fig. SB-1 ᧄ૕ㇱ㧝 Main Body Section-1
55
59
60
57
56
58
See Fig.RH-1
Key No.61
See Fig.SB-1
Key No.770
See Fig.RH-1
Key No.51
REC PCB
CPU1 PCB
LIGHTING CONTROLLER
See Fig.EB-8
Key No.752
53
52
51
See Fig.RH-2
Key No.161
See Fig.RH-1
Key No.53
54
67
63
LCD-CONTROLLER
See Fig.MA-10
Key No.902-05
