BOARD LIFTER(QC) 1/2

基板リフタ(QC) 1/2

番号図番 & ｺｰﾄﾞ番号個数品名規格材質備考

No. Drg.No. & Code No. QTY Description Rating Materials Remarks

35 BHPP0100 4 GUIDE ｶﾞｲﾄﾞ FE

35.1 H5174A 4 BOLT, HEX

ボルト六角

M04X040 ﾕﾆｸﾛﾒｯｷ(ｼﾛ) FE

35.2 N1080A 4 NUT, HEX

ナット六角

M 4 P=0.7 FE

39 BHPP0220 1 PIN ﾋﾟﾝ FE Option(Vacuum back up pins)

39.1 A5090A 1 O RING

Ｏリング

P 6 OT Option(Vacuum back up pins)

40 DNQC1030 1 BLOCK ブロック FE

41 H5290A 2

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴 M04X015 FE

42 W1011A 2

WASHER, CONICAL

ﾜｯｼｬ皿

M-4-L FE

43 A5091A 1

O RING

Oﾘﾝｸﾞ P7 OT

45 H2044A 2 PIN，SPRING ﾋﾟﾝｽﾌﾟﾘﾝｸﾞ 2°X15 FE

50 H5181A 1 BOLT, HEX

ボルト六角

M06X012 10.9 FE

51 Y3079R 1 UNION，ELBOW ﾕﾆｵﾝｴﾙﾎﾞ KQ2L06−M6 OT Option(Vacuum back up pins)

52 ABHPP8020 4 PIN, BACKUP ﾋﾟﾝﾊﾞｯｸｱｯﾌﾟ OT

53 BHPP0240 4 BKT BKT FE

54 BHPP0260 4 PIN, BACKUP ﾋﾟﾝﾊﾞｯｸｱｯﾌﾟ FE

55 H5299A 4

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴 M05X012 FE

56 ABHPP8010 4 PIN, BACKUP ﾋﾟﾝﾊﾞｯｸｱｯﾌﾟ OT Option(Vacuum back up pins)

57 BHPP0240 4 BKT BKT FE Option(Vacuum back up pins)

58 BHPP0250 4 PIN, BACKUP ﾋﾟﾝﾊﾞｯｸｱｯﾌﾟ FE Option(Vacuum back up pins)

59 H1189A 4

PAD

ﾊﾟｯﾄ VP-15RS OT Option(Vacuum back up pins)

60 A4042A 8

ELBOW

ｴﾙﾎﾞ PL6-M5M OT Option(Vacuum back up pins)

61 T2063A 4

TUBE

ﾁｭｰﾌﾞ TU0604B-20 (L=300) OT Option(Vacuum back up pins)

H5299A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M05X012
