3 4 SQG. Assy Sel. (Metal SQG.) Head KHU-080917 MET AL W -SQG. 250 ASSY 1 MET AL W -SQG. SELECTION MET AL W -SQG.300 ASSY 21 MET AL W -SQG. 350 ASSY 31 7 6 2 22 32 23 8 8 9 9 10 11 4 12 11 3 5 8 7 6 13 22 32 23 8 9 9 10 …
2
4
SQG. Assy Sel. (Metal SQG.) (Half Etching Type)
Head
KHU-1012
METAL W-SQG. 250 ASSY
1
METAL W-SQG. SELECTION
METAL W-SQG.300 ASSY
21
METAL W-SQG. 350 ASSY
31
7
6
2
22
32
23
8
8
9
9
10
11
4
12
11
3
5
8
7
6
13
22
32
23
8
9
9
10
11
15
12
11
14
16
7
6
17
22
32
23
8
8
9
9
10
11
19
12
11
18
20
OLD
17
18
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KGY-M71X0-40 METAL W(S). 250 ASSY 1
2 KGJ-M7191-00 METAL HOLDER 1,250 1
3 KGJ-M7192-00 METAL HOLDER 2,250 1
4 KGJ-M7193-10 METAL SQG.,250 1
5 KGY-M71AB-00 TRIM, 250 1
6 KGJ-M7175-00 PLATE,SQG.1 5
7 KGJ-M7176-00 PLATE,SQG.2 5
8 KGJ-M7178-02 KNOB 2 10
9 KGJ-M7179-00 MAGNET 1 10
10 KGJ-M710B-C0 SPACER PIPE 5
11 KGJ-M710B-D1 KNOB 1 10
12 90990-41J035 COLLAR 5
13 KGJ-M71A1-00 METAL HOLDER 1,300 1
14 KGJ-M71A2-00 METAL HOLDER 2,300 1
15 KGJ-M71A3-10 METAL SQG.,300 1
16 KGY-M71BB-00 TRIM, 300 1
17 KGJ-M7171-02 METAL HOLDER 1,350 1
18 KGJ-M7172-04 METAL HOLDER 2,350 1
19 KGJ-M7173-10 METAL SQG.,350 1
20 KGY-M71CB-00 TRIM, 350 1
21 KGY-M71X0-30 METAL ASSY, W-SQG, 300 1
22 91312-04018 BOLT HEX.SOCKET HEAD 14
23 92A08-03306 SCREW,SET 10
24
25
26
27
28
29
30
31 KGY-M71X0-20 METAL W-SQG. 350 ASSY 1
3
4
SQG. Assy Sel. (Metal SQG.)
Head
KHU-080917
METAL W-SQG. 250 ASSY
1
METAL W-SQG. SELECTION
METAL W-SQG.300 ASSY
21
METAL W-SQG. 350 ASSY
31
7
6
2
22
32
23
8
8
9
9
10
11
4
12
11
3
5
8
7
6
13
22
32
23
8
9
9
10
11
15
12
11
14
16
7
6
17
22
32
23
8
8
9
9
10
11
19
12
11
18
20
OLD
17
18
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KGY-M71L0-00X METAL W-SQG. 250 ASSY 1
2 KGJ-M7191-00X METAL HOLDER 1,250 1
3 KGJ-M7192-00X METAL HOLDER 2,250 1
4 KGJ-M7193-01X METAL SQG.,250 1
5 KGJ-M7194-00X EDGE PROTECTOR,250 1
6 KGJ-M7175-00X PLATE,SQG.1 5
7 KGJ-M7176-00X PLATE,SQG.2 5
8 KGJ-M7178-02X KNOB 2 10
9 KGJ-M7179-00X MAGNET 1 10
10 KGJ-M710B-C0X SPACER PIPE 5
11 KGJ-M710B-D1X KNOB 1 10
12 KGY-M71R4-00X COLLAR,W-SQG. 5
12-1 90990-41J035 COLLAR 5 (2008/4/14) ME20133 OK
13 KGJ-M71A1-00X METAL HOLDER 1,300 1
14 KGJ-M71A2-00X METAL HOLDER 2,300 1
15 KGJ-M71A3-01X METAL SQG.,300 1
16 KGJ-M71A4-00X EDGE PROTECTOR,300 1
17 KGJ-M7171-01X METAL HOLDER 1,350 1
17-1 KGJ-M7171-02X METAL HOLDER 1,350 1 (2007/7/24) MD70080 NG
18 KGJ-M7172-03X METAL HOLDER 2,350 1
18-1 KGJ-M7172-04X METAL HOLDER 2,350 1 (2007/7/24) MD70080 NG
19 KGJ-M7173-03X METAL SQG.,350 1
20 KGJ-M7174-00X EDGE PROTECTOR,350 1
21 KGY-M71M0-00X METAL W-SQG. 300 ASSY 1
22 91317-04018 BOLT HEX.SOCKET HEAD 17 M4X18
22-1 91312-04018 BOLT HEX.SOCKET HEAD 14 (2007/7/26) MD70105 OK
23 92A08-03306 SCREW,SET 10
24
25
26
27
28
29
30
31 KGY-M71N0-00X METAL W-SQG. 350 ASSY 1
1
5
Cleaner Head-1
Cleaner
KHU-080918
48
58
6
38
55
49
49
50
31
52
21
30
32
34
47
39
54
36
37
59
4
42
48
12
48
63
22
59
5
18
14
19
20
49
9
29
45
7
58
38
48
15
61
35
28
62
49
61
60
60
1
64
43
25
11
46
17
10
57
51
49
63
40
24
44
64
56
51
23
56
63
49
3
3
2
48
8
26
53
49
50
41
33
27
13
16
65
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KHU-M3601-00X SPACER Y,L 1
2 KHU-M3601-10X SPACER Y,R 1
3 KHU-M3602-00X SPACER,CLE.BASE 2
4 KHU-M3603-00X PLATE,BASE 1
5 KHU-M3604-00X BRKT,PLATE 1
6 KHU-M3605-00X PLATE L 1
6-1 KHU-M3605-01X PLATE L 1 (2007/5/24) MD50117 OK
7 KHU-M3606-00X PLATE R 1
8 KHU-M3608-00X SHAFT,CLEANER 1
9 KHU-M3609-00X SHAFT,IDLER 1
10 KHU-M3619-00X STAY,BALL PLUNGER 1
11 KHU-M3620-00X BRACKET,SENSOR 1
12 KHU-M3623-00X COVER2,HNS 1
13 KHU-M3624-00X CABLE DUCT 1
14 KGJ-M3656-02X PLATE,ROLLER 2
15 KGG-M121A-10X DC MOTOR ASSY 1
16 KHU-M3685-00X STAY 3,STOPPER 1
16-1 KHU-M3685-01X STAY 3,STOPPER 1 (2007/6/18) MD50110 OK
17 KGJ-M3617-00X BALL PLUNGER 1
18 KGJ-M3648-01X ROLLER,CLUTCH 1
19 KGJ-M3654-00X SHAFT 3,ROLLER 1
20 KGJ-M3655-00X PIN,SPRING 2
20-1 90990-03J001 PIN,SPRING 2 (2007/11/30) MD00140 OK
21 KGJ-M3660-00X SPRING 2 1
22 KGJ-M3678-01X DOG,SENSOR 1
23 KGJ-M3681-03X PIN 2,LOCK 1
24 KGJ-M3683-00X STAY 1,STOPPER 1
25 KHU-M653D-00X SENSOR,CLNG DET 1
26 KGY-M3617-01X SHAFT,MOTOR 1
27 KGY-M3618-01X STAY,MOTOR 1
28 KGY-M3624-00X BRKT,SENSER 1
29 KGY-M3625-00X NUT:M6 1
30 KGY-M3650-00X SHAFT,SPRING 1
31 KGY-M3651-00X STAY,DRY BRG 1
32 KGY-M3652-00X OIL FREE BUSH 1
33 KGY-M3653-00X WASHER,SPRING 2
33-1 90990-28J056 WASHER,PLAIN 2 (2007/12/18) MDX0125 OK
34 KGY-M3661-B0X PIPE,PAPER 360 1
35 KGY-M653N-00X SENSOR, ROLL ANGLE 1
36 KHU-M653F-20X SENSOR,CLNG OFF 1
37 KHU-M653F-40X SENSOR,CLNG ON 1
38 KW3-M3635-00X BEARING:SFB34-8 2
38-1 90990-39J003 BEARING 2 (2008/4/15) ME20075 OK
39 KW3-M3656-00X CYL,LOCK 1
40 KW3-M3666-00X DAMPER2,PLATE 1
41 KW3-M3668-00X STOPPER1,SHAFT 2
41-1 90990-28J081 WASHER,PLAIN 2 (2008/8/19) MDY0047 OK
42 90K41-000550 LABEL,ALERT 1
43 90K80-S15LW0 LM BLOCK,SSR15W-L 1
44 90K80-S15RW0 LM BLOCK(SSR15W) 1
45 95302-06600 NUT HEXAGON 1
46 99780-12600 NUT,HEXAGON 1
47 $TS4-01 JOINT 2
48 91312-04006 BOLT HEX.SOCKET HEAD 10 M4X6
49 91312-04008 BOLT HEX.SOCKET HEAD 15 M4X8
50 91312-04010 BOLT HEX.SOCKET HEAD 6 M4X10
51 91312-04016 BOLT,HEX.SOCKET HEAD 8 M4X16
52 91312-04020 BOLT HEX.SOCKET HEAD 4 M4X20
53 91312-04025 BOLT HEX.SOCKET HEAD 2 M4X25
54 91312-04045 BOLT HEX.SOCKET HEAD 4 M4X45
54-1 91312-04050 BOLT HEX.SOCKET HEAD 4 M4X50 (2013/3/8) MK20158 NG
55 91312-05010 BOLT HEX.SOCKET HEAD 2 M5X10
56 91312-05014 BOLT HEX.SOCKET HEAD 6 M5X14
57 91312-05020 BOLT HEX.SOCKET HEAD 2 M5X20
58 91312-06014 BOLT HEX.SOCKET HEAD 8 M6X14
59 91312-06016 BOLT HEX.SOCKET HEAD 5 M5X16
60 91312-06020 BOLT HEX.SOCKET HEAD 4 M5X20
61 98902-03008 SCREW BINDING HEAD 1
62 92902-03200 WASHER PLAIN 2
63 92902-04600 WASHER PLAIN 3
64 92902-05200 WASHER PLAIN 8
65 90990-28J171 WASHER PLAIN 4 (2013/3/8) MK20158
