CL5760
Helical Tip Cleaning Rods
Packing List
003 4513-250724
INSTRUCTION MANUAL
Helical Tip Cleaning Rods
....................................... 1 set
Manual ......................... 1 unit
Ref. 0034513
CL5760 includes one set of helical
tip cleaning rods of various sizes.
They are used to clean or clear
clogged desoldering tips.
Helical Tip
Cleaning Rod
DR560
DS360
DR560
DR560
DR560
DR560
DR560
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm
130 mm
para manuales - color gris
200 mm
300 mm
Tip Maintenance
To avoid clogging or pressure loss on the desoldering tool, clean the tip periodically.
It is also possible to clean the tip from
the other side.
Helical Tip
Cleaning Rod
Clean with the cleaning
rod also from the top
Clean the inside regularly with the largest
possible rod. Insert the rod pressing
lightly while rotating it.
This operation should be performed while the tip is hot (min. temperature
of 250 °C) so that the tin inside is molten and easier to remove.
Proceed with caution.
