G -S015-01 0909-002 6 441 . 443 445 . 441 . 443 445 . 442 . 444 446 . 437 431 432 433 434 434 EXCHANGE EXCHANGE 436 431 434 433 REAR P ANEL FRONT P ANEL 407 406 カバー部 COVER SECTION Fig. G-5 パネル Panel
G -S015-01
0909-002
5
G -S015-01 (Rear)
G -S015-01 (Electrical)
G -S015-01 (Front)
G -S015-01 G -S015-01
ACV
システム対応
For ACV System
G -S015-01
0909-002
6
441
.
443
445
.
441
.
443
445
.
442
.
444
446
.
437
431
432
433
434
434
EXCHANGE
EXCHANGE
436
431
434
433
REAR PANEL
FRONT PANEL
407
406
カバー部
COVER SECTION
Fig. G-5
パネル
Panel
G -S015-01
1012-003
7
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
406 6301255798 PLATE 1→0 803G--210-306 211D9464
407 6301255781 BRACKET 1→0 803G--210-307 211F8188
431 6301494487 BRACKET 2
803G-A210070-A051
211FB265
432 6301300054 BRACKET 1
803G-A210070-A052
211F8792
433 6301409870 EQUIPMENT 2 -B79
803G-A210070-A061
4U260289
434 6301300184 MECH PARTS(RUBBER DAMPER) 1
803G-A210070-A076
226J1972
436 6301327839 PLATE 1
803G-A210070-306
211DA139
437 6301429007 BRACKET 1
803G-A210070-307
211FA455
441 6300007619 BOLT,HEX-SCT 12 M4X8 221A0016
442
6300007732 BOLT,HEX-SCT 4 M5X8 221A0028
443
4111412905 WASHER SPR 4 12 SW4 221H0284
444
4111416705 WASHER SPR 5 4 SW5 221H0287
445
4111414008 WASHER V 4X9X0.8 12 FW4 221H0315
446
4111414107 WASHER V 5X10X1 4 FW5 221H0318
G-5
