1004-004 Key No. P AR T No. P AR T NAME Q’ty REMARKS New Code NOTE BC-6 BC-6 list-1 551 6301505473 CORD(HLS-LINK) 1 845BC-100-951 4W203714 551 6301505473 CORD(HLS-LINK) 1 845BC-100-951 4W203714 551 6301505473 CORD(HLS-LI…
0801-002
-A63
-A63
-A53
577
580
581
582
559
560
A
VIEW “A”
561
See Fig. BC-1
Key No.70
See Fig. BC-1
Key No.66
内が本体対応箇所です。(BLOCK3装着時)
The explanation in brackets is for the locations to be treated in the main machine.
(Case : BLOCK3 Used)
VIEW “A”
578
579
X531A
X531B
X5302
M53P
X15303
M63P
X16303
M63P
X16303
M53
M63
M63
X5303
X631A
X631A
X631B
X0502
X0523
X1605
X1603
X1604
X1637
X0517
X11604
See Fig. BC-4
Key No.381
See Fig. BC-4
Key No.351
-U05
576
-U16
572
551
575
571
X8501
BC-6 illust-1A
架台下
C UNDERFRAME C
Fig. BC-6
ケーブル２
Cable 2
(G -S050-10,Case:Block3) (G -S050-10,Case:Block3)
1004-004
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
BC-6
BC-6 list-1
551 6301505473 CORD(HLS-LINK) 1 845BC-100-951 4W203714
551 6301505473 CORD(HLS-LINK) 1 845BC-100-951 4W203714
551 6301505473 CORD(HLS-LINK) 1 845BC-100-951 4W203714
559 6301533070 CORD(X531B-X631A) 1 845BC-100-959 4W203896
560 6301577470 CORD(SSCNET-A63C-A63D) 1 845BC-100-960 4W204181
561 6301235417 CONNECTOR 1 845BC-100-061 4J100865
571 6301589282 CORD(HLS-LINK) 1
845BAA100050-A151
4W204294
571 6301589282 CORD(HLS-LINK) 1
845BAA100060-A151
4W204294
572 6301589312 CORD(HLS-LINK) 1
845BAA100050-A152
4W204295
572 6301589282 CORD(HLS-LINK) 1
845BAA100060-A152
4W204295
575 6301589336 CORD(I/O) 1
845BAA100050-A155
4W204296
575 6301589336 CORD(I/O) 1
845BAA100060-A155
4W204296
576 6301593241 ASSY,CORD 1
845BAA100050-A156
0W201751
576 6301593241 ASSY,CORD 1
845BAA100060-A156
0W201751
577 6301508511 CORD(M63) 2 845BC-100-977 4W203746
578 6301611440 CORD 2 845BC-100-978 4W204348
579 6301610726 CORD(CORD(A63-I/O)) 2 845BC-100-979 4W204346
580 6301531892 CORD(M53) 1 845BC-100-980 4W203879
581 6301611471 CORD 1 845BC-100-981 4W204350
582 6301611488 CORD 1 845BC-100-982 4W204351
GXH-3PH
G -S050-09
G -S050-10
