Samsung Component Placer SM321 Service Manual 4-6 4.1.3. Fly Camera Ass’y NO. P ART NO. P ART NAME Q’TY TYPE REMARK 1 J7155534A FL Y CAMERA BRACKET 1 J7155534A 2 J90551016A CAMERA COVER BOARD ASS’Y 1 J90551016A 3 J715926…

Head Module

4-5

NO. PART NO. PART NAME Q’TY

TYPE REMARK

22 J7055151A ARM JOINT 1 J7055151A

23 J6601080A BALL BEARING 4 MR148ZZ

24 J7055155A MIRROR JOINT-RIGHT 1 J7055155A

25 J7055153A MIRROR SCREW 2 J7055153A

26 J7055205A MIRROR JOINT-LEFT 1 J7055205A

27 J7055204A ARM JOINT 1 J7055204A

28 J7055556B MIRROR SENSOR BRACKET 1 J7055556B

29 J3212027A MICRO PHOTO SENSOR 3 PM-L24

30 J7155530A MIRROR SUPPORT 1 J7155530A

31 J6755002A FOLDING MIRROR 1 J6755002A

32 J7155197A MIRROR FIX PLATE 2 J7155197A

33 J71551120A LOWER COVER 2 1 J71551120A

34 J71551112A SIDE ILLUM BODY 1 J71551112A

35 J90601019A

HEAD SIDE LED BOARD ASS’Y 1 J90601019A

36 J90551011A SIDE ILLUM GUIDE ASS’Y 2 J90551001A

37 J9083179A SIDE ILL U/D SENSOR CABLE ASS’Y

1 SM-HD006

37-A J6711132A FITTING 1 M-5HL-4

37-B J6711156A HOSE NIPPLE (D/C) 1 M-5H-4

38 J7255085A SIDE ILLUM ISOLATOR 1 J7255085A

39 J7255084A SIDE REFLECTOR 6 J7255084A

Samsung Component Placer SM321 Service Manual

4-6

4.1.3. Fly Camera Ass’y

NO. PART NO. PART NAME Q’TY TYPE REMARK

1 J7155534A FLY CAMERA BRACKET 1 J7155534A

2 J90551016A CAMERA COVER BOARD ASS’Y 1 J90551016A

3 J7159265A COVER JOINT 3 J7159265A

4 J7155537A CAMERA REAR COVER 1 J7155537A

5 J90551006A FLY CAMERA ONE KIT ASS’Y (F25) 4 J90551006A

J90551009A FLY CAMERA ONE KIT ASS’Y (MEGA-F25)

4 J90551009A

5-A J7155535A CAMERA HOLDER 1 J7155535A

5-B J6751014A CCD CAMERA 1 VCC-G20E20

5-C J9059208A LENS ASS’Y(FOV25) 1 J9059208A

6 J9083161A FLYING CAMERA I/F CABLE ASS’Y 4 SM-VIS011

7 J90551008A FLY CAMERA ONE KIT ASS’Y (F10) 4 J90551008A

J90551007A FLY CAMERA ONE KIT ASS’Y (F15) 4 J90551007A

7-A J7155535A CAMERA HOLDER 1 J7155535A OPTION

7-B J6751014A CCD CAMERA 1 VCC-G20E20

7-C J7155550A COUPLER 1 J7155550A

7-D J9059203C LENS ASS’Y (FOV10) 1 J9059203C

J9059068C LENS ASS’Y (FOV15) 1 J9059068C

Head Module

4-7

4.1.4. Carrier Ass’y

NO. PART NO. PART NAME Q’TY TYPE REMARK

1 J7154099B RIGHT SIDE PLATE 1 HARNESS-HEAD002

2 J7154100B LEFT SIDE PLATE 1 J7154100B

3 J7154267A HARNESS PLATE 1 J7154267A

4 J7154105A SIDE CABLE TIE 2 HARNESS-HEAD013

5 J6103023A HEX SUPPORT 20 4 M3X20 (BOLT-NUT)

6 J6103011A HEX SUPPORT 30 4 M3X30 (BOLT-NUT)

7 J7055660A HEAD COVER SUPPORT-R 4 J7055660A

8 J7055661A HEAD COVER SUPPORT-F 1 J7055661A

9 J7155569A HEAD TOP COVER 1 J7155569A

10 J7055662A VACUUM SENSOR BRACKET 2 J7055662A

11 J9060412A HEAD VACUUM SENSOR SUB BOARD

1 REV 1.1

12 J90551068A AIR MODULE 1 J90551068A

12-A J71551001A MANIFOLD 1 J71551001A

12-B J7155544A FOOT BRACKET-L 1 J7155544A

12-C J7155545A FOOT BRACKET-R 1 J7155545A

12-D J7155546A INSERT 4 J7155546A

12-E J6711260A ONE TOUCH FITTING 2 FSE04-M5C

12-F J6711261A ONE TOUCH FITTING 4 FSC04-M5C

12-G J6702048A SOLENOID VALVE 4 VA01PEP34-1U-F

12-H J6702049A SOLENOID VALVE 1 RCS242-M3-D24NP

12-I J9058090A FILTER ASSY 4 J9058090A
