Page ohu~oh 104 HM520 / HM520h Air (4/6) A D C-A U2-4-6*4, B HP14-900033 SOLENOID V AL VE 3-HP06-900047 FITTING 2-HP09-900159 SILENCER HP03-001 133 CYLINDER 2-HP06-900047 FITTING HP14-900033 SOLENOID V AL VE 3-HP06-90004…
Page
ohu~oh
103
HM520 /
HM520h
Air (3/6)
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
1 HP06-000301 FITTING 1
2 HP11-000059 PUMP 1
3 HP06-000250 FITTING 1
4 HP06-000234 FITTING 1
5 HP06-900046 JOINT 1
6 HP14-002173 VALVE,CHECK 2
7 HP06-900092 #N/A #N/A
8 HP06-000457 FITTING 1
9 HP06-900170 FITTING 2
10 HP06-900153 FITTING 3
11 FC18-006589 O-RING 3 FC18-001093 Replace the following parts together (Per
machine (Front))
- O-RING: FC18-006589, 3EA
- O-RING HODLER: FC29-011782A, 3EA
- SHIM: FC29-001563, 3EA
FC29-011782A HOLDER-O-RING-3 3 FC29-009656A
FC29-001563 SHIM-SKB 3
Page
ohu~oh
104
HM520 /
HM520h
Air (4/6)
A
D
C-A
U2-4-6*4, B
HP14-900033
SOLENOID VALVE
3-HP06-900047
FITTING
2-HP09-900159
SILENCER
HP03-001133
CYLINDER
2-HP06-900047
FITTING
HP14-900033
SOLENOID VALVE
3-HP06-900047
FITTING
2-HP09-900159
SILENCER
HP03-001127
CYLINDER
2-HP06-900047
FITTING
WORK #1 STOPPER
BUFFER STOPPER
HP14-900033
SOLENOID VALVE
2-HP14-900088
SPEED CON.
2-HP09-900159
SILENCER
HP03-900013
CYLINDER
2-HP06-900056
FITTING
BACK UP TABLE
U2-4-4*2.5, B
U2-4-4*2.5, B
HP06-900054
FITTING
(REAR) CONVEYOR-BUT
HP06-900047
FITTING
HP14-900033
SOLENOID VALVE
2-HP06-001333
FITTING
2-HP09-900159
SILENCER
HP03-001110
CYLINDER
2-HP14-002200
SPEED CON.
(REAR) ANC
HP06-900199
FITTING
BLOW DUMP용
HP06-900199
FITTING
U2-4-4*2.5, B
U2-4-6*4, B
U2-4-4*2.5, B
HP06-900255
FITTING
C
1
1
6
3
2
3
4
5
7
6
10
11
12
13
5
14
8
4
5
9
3
1
3
4
5
Page
ohu~oh
105
HM520 /
HM520h
Air (4/6)
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
1 HP06-900199 UNION Y FITTING 4
2 HP03-001133 CYLINDER 2
3 HP06-900047 ELBOW FITTING 1
4 HP14-900033 SOL VALVE 1
5 HP09-900159 SILENCER 2
6 HP06-900054 UNION Y FITTING 2
7 HP06-900056 ELBOW FITTING 2
8 HP14-900088 SPEED CONTROLLER 2
9 HP06-900047 ELBOW FITTING 1
10 HP03-001110 CYLINDER 1
11 HP06-001333 FITTING 2
12 HP14-900033 SOL VALVE 1
13 HP14-002200 VALVE,CONTROL 2
14 HP06-900255 STRAIGHT FITTING 1
15 HP09-900159 SILENCER 2
