Page ohu~oh 210 HM520 / HM520h Power Block Diagram (2/7) L22 L21 L23 4.0 mm (BLK) L13 L12 L1 1 L3 L2 L1 GROUND PLA TE -TRANS 220V L21 PE 22S 22R 22T TFL1 TFL2 TFL3 220V 220V L22 L23 FX,RX,FY ,RY (SERVO) 6.SECONDARY : 3Ø …
Page
ohu~oh
209
HM520 /
HM520h
Power Block Diagram (1/7)
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
1 AM03-010941A CABLE ASSY-VACUUM_EJECTOR_PWR 1
2 AM03-010940A CABLE ASSY-VACUUM_PWR 1
3 AM03-010943B CABLE ASSY-PUMP_PWR_ALARM_EXT 1
4 AM03-010942D CABLE ASSY-PCB_SENSOR_PUMP_ALARM 1 AM03-010942C
5 AM03-010822C CABLE ASSY-IN_CONV_30P_MODULE_A 1
6 AM03-010829D CABLE ASSY-EXIT_CONV_30P_MODULE_A 1 AM03-010829B
7 AM03-010812B CABLE ASSY-AXIS_SENSOR_BD_STP-BUT 1
8 AM03-011151B CABLE ASSY-IN_CV_30P_MODULE_B_FULL 1
9 AM03-011156A CABLE ASSY-EX_CV_30P_MODULE_B_FULL 1
10 AM03-019721A CABLE ASSY-IN_F_PCB_SEN_IN_WAIT_FULL 1
11 AM03-019721A CABLE ASSY-EX_CV_F_R_PCB_SEN_FULL 1
Page
ohu~oh
210
HM520 /
HM520h
Power Block Diagram (2/7)
L22
L21
L23
4.0 mm (BLK)
L13
L12
L11
L3
L2L1
GROUND PLATE
-TRANS
220V
L21
PE
22S
22R 22T
TFL1
TFL2
TFL3
220V 220V
L22 L23
FX,RX,FY,RY (SERVO)
6.SECONDARY : 3Ø 220(4.3KVA)
2.FREQUENCY : 50/60Hz
1.CAPACITY : 4.3KVA
3.PHASE : 3Ø
4. CONNECTION: Y-Y
<TRANS SPECIFICATION>
5.PRIMARY : 3Ø 200/208/220/240/380/415V, 4.3KVA
-MC1
2.5 mm (BLK)
FACTORY MAIN POWER
- 200/208/220/240/380/415VAC FLA15A
- 3 50/60Hz SCR 15KA(230VAC)
-TB1
(3Ø, 20A)
-MAIN SW
NF63-SVF
F-03SV LF
-MCCB
-NF1
(3 , 20A)
TNS-5020
NXD_PW-002
AM03-025663A
NXD_PW-001
2.5 mm (ORANGE)
AM03-025662A
2.5 mm (BLK)
-SK1
V1_BASE_200
J90751558A
RAV-801BXZ-4
NXD_PW-003
AM03-025664A
2.5 mm (BLK)
NXD_PW-004
AM03-025664A
240
208200
220
415380
240
208200
220
415380
240
208200
220
415380
1N
2N
1L1
1L2
2.5 mm(BLK)
PC(MONITOR)
24V PS #1(600W)
AC FAN
2.5 mm
2L1
2L2
24V PS #2(400W)
3L1
3L2
-MC2
XY DRIVER CONTROL
48V PS #5(600W)
SH203-C16
-CP2
(16A)
NXD_PW-006
AM03-025667A
2.5 mm
NXD_PW-007
AM03-025669A
2.5 mm
NXD_PW-009
AM03-025668A
NXD_PW-011
AM03-025672A
NXD_PW-012
AM03-025673A
-FUSE4 (AC250V,10A)
-FUSE3 (AC250V,10A)
-FUSE6 (AC250V,10A)
-FUSE5 (AC250V,10A)
48V PS #4(600W)
24V PS #3(400W)
NXD_PW-060
AM03-027818A
SH202-C10
-CP1
(10A)
NXD_PW-005
AM03-025666A
2.5 mm(BLK)
1
456
23
24
13
6
5
13 5
RST
UVW
U
V
W
246
135
264
135
2
1
4
3
1A 4A
13 5
7A 8A
9A
10A
U
V
V
W
A
B
A
B
A
B
A
B
U
W
2
PE14
2
2
2
2
2
2
2
2
E1-FG1
PE02
2
1
2
3
4
5
14
6
8
9
7
15
12
13
11
10
NXD_PW_100
AM03-029072A
AM03-025463A
NXD_PW-035
AM03-025695B
Page
ohu~oh
211
HM520 /
HM520h
Power Block Diagram (2/7)
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
1 AM03-029072A CABLE ASSY-MAIN POWER INPUT 1
2 AM03-025662A CABLE ASSY-TB1 MAIN SWITCH AC 1
3 AM03-025663A CABLE ASSY-TB1 GROUND PLATE FG 1
4 EP02-001577A SERGE KILLER ASSY 1 J90751558A
5 AM03-025664A CABLE ASSY-MAIN SW_NF AC 1
6 AM03-025664A CABLE ASSY-MAIN SW_NF AC 1
7 AM03-027818A CABLE ASSY-TRANSFORMER FG 1
8 AM03-025666A CABLE ASSY-TR_CP1 AC 1
9 AM03-025667A CABLE ASSY-CP1_TB2 AC 1
10 AM03-025669A CABLE ASSY-TR_FUSE3_4_TB2 AC 1
11 AM03-025668A CABLE ASSY-TR_FUSE5_6_TB2 AC 1
12 AM03-025672A CABLE ASSY-TR_CP2 AC 1
13 AM03-025673A CABLE ASSY-CP2_MC1 AC 1
14 AM03-025463A CABLE ASSY-HILL - HSBD RS422 IF CABLE 1
15 AM03-025695B CABLE ASSY-MC2_AC 1
