EUKYX
2-2199-4100
2. Management Information
2. Management Information
2.1 "Management Information" Window
When normal recovery does not occur after a mistake in the machine operation or an error, the
following management information window appears.
[1]
[4]
[3]
[2]
[5]
F4B2
[1] Management Information
In this window, the management information is displayed.
[2] Management Information Code
In this window, the management information code is displayed.
[3] Display Area A
The outline of the management information is displayed in this area.
[4] Display Area B
The details of the management information are displayed in this area.
[5] [OK] Button
The window returns just prior to the "Management Information" by pressing this button.
• Remedial Procedure from “Management Information” Window
(1) Make a note of the management information.
If you forget the Management Information, correct recovery can not be performed. Therefore,
make sure to make a note.
(2) Press the [OK] button to return to the original window.
(3) Perform the correct recovery based on the Management Information.
Notice
EUKYX
2-3199-4100
2.2 Management Information list
Code Display Area A Display Area B
10101 Emergency Stop Press [POWER ON] button to activate Load Power circuit.
10103 Emergency Stop Emergency Stop switch is pressed. Please cancel it.
10201 Air Pressure Drop Air Pressure Drop is detected
10401
Safety cover lock
confirm
Please close and lock the safety cover.
10402
Safety cover lock
confirm
Operate it after close and lock the safety cover.
10403
Safety cover lock
confirm
Operate after close and lock the safety cover.
10404
Safety cover lock
confirm
The safety cover is in unlock. Please complete to unlock and operate
it.
10503
Beam XY main circuit
OFF
Beam XY main circuit Error
10801
Feeder base confirm
(Block1)
Set the feeder cart (Block1) and connect cable.
10802
Feeder base confirm
(Block1)
Cannot set Feeder Cart downward to detect Elevator Unit (Block1).
Operate after remove it .
10803
Feeder base confirm
(Block1)
Elevator Unit (Block1) is not connected. Please connect to it with "Unit
Exchange Menu".
10804
Feeder base confirm
(Block1)
Batch Connector of Elevator Unit (Block1) is not connected. Please
check connection.
10805
Feeder base confirm
(Block1)
Feeder cart (Block1) is not upper position. Push Feeder Ready Switch.
10806
Feeder base confirm
(Block1)
Push Feeder Ready SW.
10807
Feeder base confirm
(Block1)
Feeder base power or Feeder power is "OFF". Please press "Feeder
Ready" switch (Block1), and put it up again after putting Feeder Cart
(Block1) down.
10901
Feeder base confirm
(Block2)
Set the feeder cart and connect cable. (Block2)
10902
Feeder base confirm
(Block2)
Cannot set Feeder Cart downward to detect Elevator Unit (Block2).
Operate after remove it.
10903
Feeder base confirm
(Block2)
Elevator Unit (Block2) is not connected. Please connect to it with "Unit
Exchange Menu".
10904
Feeder base confirm
(Block2)
Batch Connector of Elevator Unit (Block2) is not connected. Please
check connection.
10905
Feeder base confirm
(Block2)
Feeder cart (Block2) is not upper position. Push feeder ready sw.
10906
Feeder base confirm
(Block2)
Push feeder ready sw.
10907
Feeder base confirm
(Block2)
Feeder base power or Feeder power is "OFF". Please press "Feeder
Ready" switch (Block2), and put it up again after putting Feeder Cart
(Block2) down.
10b01
Feeder is not ready
(Block1)
Please turn on the Feeder Ready SW (Block1).
10c01
Feeder is not ready
(Block2)
Please turn on the Feeder Ready SW (Block2).
2.2 Management Information list
The following is the management information list by code.
EUKYX
2-4199-4100
2.2 Management Information list
Code Display Area A Display Area B
10d01
Pattern program is
abnormal
Please set the normal pattern program
10e01 Prod Chng is not ready
Conveyor width does not fit production data. Execute conveyor width
setup.
110 01 Empty Feeder (Block1) Please set the feeder (Block1) that used by the pattern program.
11101 Empty Feeder (Block2) Please set the feeder (Block2) that used by the pattern program.
11201
Stock Stick Feeder
(Block1)
A setup of a stock stick unit and part library data is not in agreement.
Please carry that whose discernment ID of a part library / supply data
and ID on the rear surface of a unit correspond.
11202
Stock Stick Feeder
(Block1)
Please check the value of the thickness data t and Ut of a part library.
11301
Stock Stick Feeder
(Block2)
A setup of a stock stick unit and part library data is not in agreement.
Please carry that whose discernment ID of a part library / supply data
and ID on the rear surface of a unit correspond.
1130 2
Stock Stick Feeder
(Block2)
Please check the value of the thickness data t and Ut of a part library.
11401 Zeroing not finish Perform All zeroing
11402 Zeroing not finish Perform All zeroing
11403 Zeroing not finish Perform All zeroing
11404 Zeroing not finish Perform All zeroing
1140 5 Zeroing not finish Perform All zeroing
1140 6 Zeroing not finish Motor is not servo on. Perform All zeroing
11701 PCB positioning Please position the PCB.
1170 2 PCB positioning Set Pos PCB [Output Position].
1170 3 PCB positioning Set Pos PCB [Input Position].
1170 4 PCB positioning Please cancel PCB positioning after cancelling operation.
1170 5 PCB positioning Please set PCB positioning [Input or Output] of [Lane A]
1170 6 PCB positioning Please set PCB positioning. [Output position] of [Lane A].
11707 PCB positioning Please set PCB positioning [Input position] of [Lane A].
1170 8 PCB positioning Please set PCB Positioning [Input or Output] of [Lane B].
1170 9 PCB positioning Please set PCB Positioning [Output position] of [Lane B].
1170 a PCB positioning Please set PCB positioning [Input position] of [Lane B].
1170 b PCB positioning Please set PCB positioning of input position on PCB transfer menu.
1170 c PCB positioning
Please set PCB positioning of [Lane A] input position on PCB transfer
menu.
1170 d PCB positioning
Please set PCB positioning of [Lane B] input position on PCB transfer
menu.
1170 e PCB positioning
Board has been positioned inside the unit two. For finishing, please
run it from an upstream position positioning sequentially one by one.
11901
Head unsettled comp.
confirmation
An unsettled component was detected. Please discard the component.
In case of the "Pauses" condition, perform the operation for
interruption.
11a01
Nozzle stocker lower
limit confirmation
Please perform All zeroing.
11c 01
Nozzle arrangement
confirmation
The nozzle arrangement of the Current Program differs from it of Head.
