EUKYX
2-11199-4100
2.2 Management Information list
Code Display Area A Display Area B
18802 XY Origin Offset
Since the data transfer of XY-Origin offset is not completed, please
perform again after waiting for a while (Beam 2).
18901 Feeder communication
Feeder (Block1) is on communication. Please wait for a second, and
then operate again.
18902 Feeder communication
Feeder (Block2) is on communication. Please wait for a second, and
then operate again.
18a01
Library Feed Pitch
check
Library Feed Pitch differs from Feeder. Please check Library and
Feeder. (Block1)
18a02
Library Feed Pitch
check
Library Feed Pitch differs from Feeder. Please check Library and
Feeder. (Block2)
18b01
Library Tape Width
check
Library Tape Width differs from Feeder. Please check Library and
Feeder. (Block1)
18b02
Library Tape Width
check
Library Tape Width differs from Feeder. Please check Library and
Feeder. (Block2)
19001 Support Pin Please move exchange position of support pin.
19002 Support Pin
There is no available nozzle for backup pin exchange. In the case of a
multi function head, please set a Nozzle to No.1 - No.5 of the stocker,
and secure a Nozzle storage space to No.1 - No.5 of the stocker.
19003 Support Pin
Arranging data in current differs from it of Support Pin of current
pattern program. Please set-up the support pin.
19004 Support Pin
When PCB size 216 mm is exceeded, it is impossible to operate if
Support pins of Lane A remain. Please exchange Lane A, or take out it
from machine.
19005 Support Pin
It is impossible to do operation for only Lane B because Support Pins
of Lane A remain. Please exchange Lane A, or take out it from
machine.
19006 Support Pin
Operation for Lane A is impossible because Support Pins of Lane A
have not been installed. Please exchange Support pins or store them.
19007 Support Pin
It is impossible to do Operation for only Lane A because Support Pins
of Lane B remain. Please exchange Lane B, or take out it from
machine.
19008 Support Pin
Support pins of Lane B remain on the base for Support pins of Lane A,
so that it is impossible to do Conveyor width. Please exchange Support
pins or store them.
19009 Support Pin
Arrangement of Support Pins interferes in Conveyor. Please retry to
arrange it.
1900A Support Pin
“Vacuum/Blower” of Test Operation Mode is set “Disable”. Execute it
after cancelling Test Operation Mode.
1900B Support Pin
An unsettled component or a Support pin was detected (Head1).
Please check the state of Head, and discard the component.
1900C Support Pin
An unsettled component or a Support pin was detected (Head2).
Please check the state of Head, and discard the component.
1900D Support Pin Please exchange Support pins or store them.
1900E Support Pin
PCB Y size and Conveyor Width in Current Program are not equal.
Please change Current Program.
19101 Single-Tray (Block1)
The connection of Single-Tray differs from Cmpnt Arranging Data.
Please connect Single-Tray to Lane No.25 and No.55 Of Feeder cart.
19102 Single-Tray (Block1) Pallet Error of Single-Tray is detected. Please set Pallet to the inside.
19201 Single-Tray (Block2)
The connection of Single-Tray differs from Cmpnt Arranging Data.
Please connect Single-Tray to Lane No.25 and No.55 Of Feeder cart.
19202 Single-Tray (Block2) Pallet Error of Single-Tray is detected. Please set Pallet to the inside.
3012c Operation Requirement Please change enable mode into disable mode. (serial out mode)
EUKYX
2-12199-4100
2.2 Management Information list
Code Display Area A Display Area B
30162 Operation Requirement The pattern cannot be switched
30413 Operation Requirement Specify the order No.
30416 Operation Requirement
ACV server does not pass the authorization. Please retry to connect to
server on a screen [UNIT ADJ]-[ACV Set].
3041C Operation Requirement
ACV Check Error. Component ID on the feeder is not same as one
specified by current program.
30420 Operation Requirement
Communications with the ACV server is impossible. After confirming
the ACV server, please retry to perform it. [MAINT]-[UNIT ADJ]-[ACV
ADJ].
30421 Operation Requirement
ACV server is out of condition. Check the ACV server. Check HDD
capacity, database breakage, the condition of each module and
communication between severs.
30430 Operation Requirement
Can not detect Feeder cart (Block1). Please set Feeder cart to the
inside.[B0910, B0911]
30431 Operation Requirement
Can not detect Feeder cart (Block2). Please set Feeder cart to the
inside.[B0910, B0911]
30432 Operation Requirement
The connector of the feeder base (Block1) is not connected to the main
body, so that please connect it. [B0916]
30433 Operation Requirement
The connector of the feeder base (Block2) is not connected to the
main body, so that please connect it. [B0916]
30440 Operation Requirement The Safety cover is open. Please close it.
30441 Operation Requirement
It is impossible to do Pass Operation without Cart because func of
Traceability is valid. Please restart after setting Option invalid.
30442 Operation Requirement
It cannot run because a simple Cover locked. First, set Stage ready
OFF, then set Stage ready ON.
30450 Operation Requirement To run is impossible by start protect.
30451 Operation Requirement
Cannot start to run because the output folder on server is
disconnected. Please check output folder setting and the server status
of output folder.
30452 Operation Requirement
When “Lne Operatin System” is specified besides [LISA], the[Enable
(In Order)] setting cannot be done to “B.C.D.PpChg-P.P.Chng.Func
set”.
30453 Operation Requirement
When “Lne Operatin System” is specified besides [LISA], the[Enable
(BS)] setting cannot be done to “B.C.D.PpChg-P.P.Chng.Func set”.
30454 Operation Requirement
To run is impossible by shortage of components. (Component Remain
Stop Mode: PCB) Please supply the components.
30455 Operation Requirement
To run is impossible by shortage of components. (Component Remain
Stop Mode: Product PCB) Please supply the components.
30456 Operation Requirement
Since the [PCB Finishing Position] data of a Crnt.Prgm is a finish setup
[Sequence], it cannot start (Component Remain Stop Mode). Please
set to the [Output] or the [Input]
30457 Operation Requirement Please start Auto Opn after Comp library data updating.
30458 Operation Requirement The component skip is set up. Please choose other steps.
30459 Operation Requirement
Cannot start to run because the machine event output server is
disconnected. Please check machine event output setting and the
server status of output.
30460 Operation Requirement
Moisture deadline of component has passed.
Please replace the component in the moisture deadline.
30461 Operation Requirement
Customer system cooperation: The machine is communicating the
non-output information of the traceability information. Please wait for a
second, and then operate again.
EUKYX
2-13199-4100
2.2 Management Information list
Code Display Area A Display Area B
30462 Operation Requirement
AOI feedforward function: The machine is communicating the non-
output information of the Inspection information. Please wait for a
second, and then operate again.
30463 Operation Requirement
Cannot start to run because a LCR check is uncompleted. Please
check a target component in a LCR check screen.
30501
Misidentification a type
of Tray
The connected Tray unit (Block1) doesn’t match settings of Device.
Please confirm a type of tray unit, and set it on unit exchange screen.
30502
Misidentification a type
of Tray
The connected Tray unit (Block2) doesn’t match setup of Device.
Please confirm a type of tray unit, and set it on Unit Exchange Screen.
30601
Confirmation of the
position of Noz Stocker
Cannot use Noz stocker from the second to the forth line when full tray
is used. Please set the location of Noz stocker of Device (Block1) on
Unit exchange Screen.
30602
Confirmation of the
position of Noz Stocker
Cannot use Noz stocker from the second to the forth line when full tray
is used. Please set the location of Noz stocker of Device (Block2) on
Unit exchange Screen.
30603
Confirmation of the
position of Noz Stocker
Cannot use Noz stocker from the second to the forth line when full tray
is used. Please confirm the location of Noz stocker of Device (Block1).
30604
Confirmation of the
position of Noz Stocker
Cannot use Noz stocker from the second to the forth line when full tray
is used. Please confirm the location of Noz stocker of Device (Block2).
30701
Confirmation of 2D Bar
code Data
Mark No. of Operating Parameter/2D Bar Code data is specified as All
Skip (0). Please specify proper Mark No.
30801
Detect nozzle coming
off multi-functional
stocker
Machine (Block1) Detected that nozzle has come off the multi-
functional stocker of the 1st line.
30802
Detect nozzle coming
off multi-functional
stocker
Machine (Block1) Detected that nozzle has come off the multi-
functional stocker of the 4th line.
30803
Detect nozzle coming
off multi-functional
stocker
Machine (Block2) Detected that nozzle has come off the multi-
functional stocker of the 1st line.
30804
Detect nozzle coming
off multi-functional
stocker
Machine (Block2) Detected that nozzle has come off the multi-
functional stocker of the 4th line.
30901
Head nozzle dropped
detect
Please lock the main safety cover. Please perform all-zeroing when the
main safety cover has already been locked.
50201
Confirmation of PCB
existence
Remove PCB from the conveyor. Please delete the PCB memory
information on the edit screen if it remains.
50202
Confirmation of PCB
existence
PCB is detected from Input position when Finish mode is set [Output].
Please PCB from conveyor.
50203
Confirmation of PCB
existence
PCB is detected from Output position when Finish mode is set [Input].
Please PCB from conveyor.
50204
Confirmation of PCB
existence
PCB is detected from Inlet sensor of input conveyor. Please remove
PCB.
50205
Confirmation of PCB
existence
The operation mode of Lane A is set [STOP]. Please remove PCB
when not transferred.
50206
Confirmation of PCB
existence
The operation mode of Lane B is set [STOP]. Please remove PCB
when not transferred.
50207
Confirmation of PCB
existence
There is a possibility that there are 2 sheets of PCB on the input
conveyor. Please remove PCB from Deceleration Sensor, or move it to
Stop sensor, or delete the PCB memory information.
50208
Confirmation of PCB
existence
There is a possibility that there are 2 sheets of PCB on the input
conveyor in Lane A. Please remove PCB from Deceleration Sensor, or
move it to Stop sensor, or delete the PCB memory information.
