EUKYX
2-17199-4100
2.2 Management Information list
Code Display Area A Display Area B
05 0711 Convert Width Setup
Emergency Stop Switch of Shuttle Conveyor in Output side is pressed.
Please cancel it.
050712 Convert Width Setup
The safety cover of Shuttle Conveyor in Output side is open. Please
close it.
050713 Convert Width Setup
Deceleration Sensor of Shuttle Conveyor in Output side is detected.
Please remove PCB there is a possibility that it is inserted.
050714 Convert Width Setup
Stop Sensor of Output Conveyor is detected. Please remove PCB there
is a possibility that it is inserted.
050715 Convert Width Setup
Stop Sensor of Output Conveyor in Lane A is detected. Please remove
PCB there is a possibility that it is inserted.
050716 Convert Width Setup
Stop Sensor of Output Conveyor in Lane B is detected. Please remove
PCB there is a possibility that it is inserted.
050717 Convert Width Setup
Set Value of Delivery Position of Device System/Output Machine PCB
is not in the Movable Range. Please set the value 467 mm and less
whose value is the sum with Y size of PCB.
050718 Convert Width Setup
Please set [SMEMA] Mode for Device System/Output Machine Output.
And, Please confirm that Inp/Outp Machine Signal is set as [Enable].
050801
Warning about
Maintenance
It is time to perform the feeder maintenance.
60101
Feeder communication
Error
Can not communicate with Feeder. Please confirm that selected
Feeder is put in.
60201 Feeder type Error Library and Feeder are inconsistent.
60301
Feeder preparation
Error
Please drop Feeder base once. Then, rise it again.
60401 Feeder No. Error Cannot Pick-up The Feeder. Please select another one.
60501 Nozzle Check Nozzle is placed. Please Store it, and then retry to execute.
60601 Cart Check
Safety cover was not locked by following reasons. 1. Feeder Cart
position [S151F,S151B] 2. Safety circuit (Safety Relay [K3,K4], Safe
cover lock [S131,S132], Emergency stop [S105F,S105B], Magnetic
contractor [K33A,K33B], Relay [K11], Cable condition)
60602 Cart Check Cart (Block1) is not at upper position. Please put it up.
60603 Cart Check Cart (Block2) is not at upper position. Please put it up.
60604 Cart Check
Cannot operate it because Cart (Block1) is not at upper position or its
connector is off.
( It is dangerous to put the hand into a space between the Cart and the
Safety Cover.)
60605 Cart Check
Cannot operate it because Cart (Block2) is not at upper position or its
connector is off.
(It is dangerous to put the hand into a space between the Cart and the
Safety Cover.)
60606 Cart Check Please operate it after shutting the feeder area cover (Blocks 1 and 2).
60701
Error in Carrier
supplying Cmpnt
It is impossible to pick-up this cmpnt from specified Feeder. Please
change the Placement mode as [By Hand].
60702
Error in Carrier
supplying Cmpnt
Feeder location in equipment is not in agreement with a current pattern
program.
Please check feeder location in a FEEDER LOCATION screen.
60801 Cutter Please close and lock the safety cover, and then operate it (Block1).
60802 Cutter Please close and lock the safety cover, and then operate it (Block2).
EUKYX
2-18199-4100
2.2 Management Information list
Code Display Area A Display Area B
070101 Data matching
Backup Jig to support vacuum of [Pattern program/PCB positioning/
PCB positioning sequence] is set [Enable]. Please set Pattern program
[Disable]. Or, set up Jig and select [Jig] on the unit replace screen.
070102 Data matching
Backup Jig to support vacuum of [Pattern program/PCB positioning/
PCB positioning sequence] is set [Disable]. Please set Pattern
program [Enable]. Or, take off Jig and select [None] on the unit replace
screen.
070103 Data matching Input machine differs from Crnt. PP. Please match the Crnt. PP.
070104 Data matching
Failed to consistency check of input machine. Please checking LAN
connection.
070105 Data matching
Output machine differs from Crnt. PP. Please match the Crnt. PP of the
Output machine. Please set P.C.B. counter of the Output machine.
0d0a01 Nozzle position Nozzle is fallen. Please perform the all zeroing.
0d0b01
Confirmation of press
missing Cmpnt
Open the safety cover, then check the cmpnt on PCB. Please remove
or fix it.
0d0b02
Confirmation of press
missing Cmpnt
Open the safety cover, then check the cmpnt on PCB. Please remove
it.
0d0c01
Pickup miss comp,
Disengaged Latch
Check
Please open the safety door and confirm whether pickup miss comp is
dropped or no disengaged Latch is exist. If the comp is dropped, there
is a possibility of interference with Head. A detection state can be
checked on a control screen.
0d0d01 Confirm bending Noz
Open the safety door, and then confirm whether Noz placed in head is
bent.
0d0e01
Zeroing of Cutter is not
completed
Perform All zeroing
0d0f01 Height Teaching
Cmpnt is picked-up, or there is a nozzle which has turned on the Valve
(Head1). Please remove the cmpnt, and turn off the Valve.
0d0f02 Height Teaching
Cmpnt is picked-up, or there is a nozzle which has turned on the Valve
(Head2). Please remove the cmpnt, and turn off the Valve.
0d0f03 Height Teaching Tray’s Pallet is not pulled out (Block1). Please pull it out.
0d0f04 Height Teaching Tray’s Pallet is not pulled out (Block2). Please pull it out.
0d0f05 Height Teaching
Cannot teach Stocker Master height of the third and forth line for
Stocker 2 of One side Machine.
0d0f06 Height Teaching
There is no place for Glass Jig in the Head, so that could not teach the
height of Glass Jig.
0d1001 Stop Command Interlock is detected. Please retry to execute after removing the factor.
0 d1101
Flux dispensing unit
squeegee error detect
Please put down squeegee not to separate from flux dispensing unit.
0d1201
Flux dispensing unit
motor warning detect
Please take out/in flux dispensing and then restart to run.
0d1301
Uninstalled Flux
dispensing unit
Please set flux dispensing unit to use in pattern program data.
0d1401 Head type error Please restart it after setting the head type properly.
0d1501 Keep large nozzle
Please remove the large nozzle on the head1 by hand. Please retry to
operate it after editing nozzle arrangement data
0d1502 Keep large nozzle
Please remove the large nozzle on the head2 by hand. Please retry to
operate it after editing nozzle arrangement data
0d1601
Large nozzle
interference
The large nozzle is set positioning in the interfering position. Please
set positioning in the not interfering position, or perform all zeroing.
EUKYX
2-19199-4100
2.2 Management Information list
Code Display Area A Display Area B
0d1602
Large nozzle
interference
Operation is impossible because large nozzles are placed in 2 axes
adjacent to the head1. Please take off one of them by hand, and then
edit the nozzle arrangement data.
0d1603
Large nozzle
interference
Operation is impossible because large nozzles are placed in 2 axes
adjacent to the head2. Please take off one of them by hand, and then
edit the nozzle arrangement data.
0d1604
Large nozzle
interference
It cannot run because a large nozzle runs to the interfering position.
0d1701
Non-applied function of
the long board
The function is not applied to PCB which is longer than 610 mm.
0d1801 Transfer confirmation The machine has not stopped.
0d1901 Bowl Feeder
Bowl feeder cart (Block1) has not been set. Please check a type of the
cart. And, Please check the setting for unit exchange screen.
0d1902 Bowl Feeder
Bowl feeder cart (Block2) has not been set. Please check a type of
cart. And, Please check the setting for unit exchange screen.
0d2001
Non-applied function of
backup jig support to
vacuum
The function is not available if backup jig to support vacuum is applied.
0d2101
Independent /
alternation production
mode
The alternation production mode cannot run during an independent
production mode run. Please start again after stopping a machine.
0d2102
Independent /
alternation production
mode
By the state of the PCB in the machine, I do not come in a startup.
Please start again after I remove a PCB, or stopping it.
0d2201 Selection at any time
Please push the abandonment button of the control screen and specify
the place where parts are abandoned. (head1) The parts which have
set up “at-any-time selection” or “after-interlock recovery” are adsorbed
states.
0d2202 Selection at any time
Please push the abandonment button of the control screen and specify
the place where parts are abandoned. (head2) The parts which have
set up “at-any-time selection” or “after-interlock recovery” are adsorbed
states.
0d2301
Conveyor safety sensor
detection
The conveyor safety sensor (input side) is detected.
0d2302
Conveyor safety sensor
detection
The conveyor safety sensor (output side) is detected.
0d2401
Feeder safety sensor
detection (Block1)
The feeder safety sensor (Block1) is detected.
0d2402
Feeder safety sensor
detection (Block2)
The feeder safety sensor (Block2) is detected.
0d3001
PCB position
restoration check
Please open a safety door and return PCB to the specified position of
recovery guidance. If operations are resumed without returning PCB to
the specified position, it may discharge by un-mounting.
0d3101
Component storage box
without emission
(Block1) Component storage boxes are not detected. Please install
component storage boxes.
0d3102
Component storage box
without emission
(Block2) Component storage boxes are not detected. Please install
component storage boxes.
0d3201
Feeder Base Up/Down
Operation Restrictions
(Block1)
In order to make a feeder base go up and down, please remove the
stock stick unit on a base.
0d3202
Feeder Base Up/Down
Operation Restrictions
(Block1)
Please check that the stock stick unit is not carried on a feeder base,
and perform UP/DOWN operation of a base again.
