EUKYX
2-26199-4100
3.2 Machine Information list
Err Code
(HEX)
Display Area A Display Area B
802104
Feeder Maintenance
alarm
The feeder adsorption rate decreased and exceeded the previous
notice setting number.
802201 ACV Information
ACV Check Error. Component ID on the feeder is not same as one
specified by current program.
802202 ACV Information
Device (Block1) Cannot clear Clamp for feeder communication.
Please operate it again later.
802203 ACV Information
Device (Block2) Cannot clear Clamp for feeder communication.
Please operate it again later.
802204 ACV Information
Device (Block1) Cannot clear Clamp for receiving the result of ACV
Check Error. Please operate it again later.
802205 ACV Information
Device (Block2) Cannot clear Clamp for receiving the result of ACV
Check Error. Please operate it again later.
802206 ACV Information
Device (Block1) Time-out for receiving the result of ACV Check
Error. Please take out Feeder and then take it in again.
802207 ACV Information
Device (Block2) Time-out for receiving the result of ACV Check
Error. Please take out Feeder and then take it in again.
802208 ACV Information
Device (Block1) Time-out of Feeder communication. Please take out
Feeder and then take it in again.
802209 ACV Information
Device (Block2) Time-out of Feeder communication. Please take out
Feeder and then take it in again.
802301
Splicing No Check
Alarm
The seam passed the detection sensor as unregistered splicing.
Please register the splicing.
802401
Feeder Cover Tape
filled up alarm
The storage section of Cover Tape filled was detected. Please
remove Tape from internal storage section.
802501
Feeder Communication
Error
Failed to displaying Operational Panel. Please put the Cart down, or
pull out and insert Feeder.
802502
Feeder Communication
Error
The communication processing of Feeder was not done in prescribed
time.
802601
Side view camera
sensor
To set synchronized counting position of Head1 is failed.
802602
Side view camera
sensor
To set synchronized counting position of Head2 is failed.
802603
Side view camera
sensor
To reset DD origin position of Head1 is failed.
802604
Side view camera
sensor
To reset DD origin position of Head2 is failed.
802701
Comp Time Limit
Manage
Moisture deadline of component is approaching.
In preparation for the moisture expired, please prepare a new
component.
802702
Comp Time Limit
Manage
Since the moisture deadline of the component has passed, the
device will stop dispensing.
803001 FAN Stop alarm Fan rotation error of the case (Block2). Please clean up Fan.
803002 FAN Stop alarm Fan rotation error of the case (Block1). Please clean up Fan.
803003 FAN Stop alarm Fan rotation error of the power G4 (Upper). Please clean up Fan.
803004 FAN Stop alarm Fan rotation error of the power G4 (Rear). Please clean up Fan.
803005 FAN Stop alarm Fan rotation error of the roof (Left). Please clean up Fan.
803006 FAN Stop alarm Fan rotation error of the roof (Left). Please clean up Fan.
803028 FAN Stop alarm Fan rotation error of Control Box. Clean up Fan.
803101
Feeder Feeding Pitch
Correction
Auto Correction is executed for Feeder Feeding Pitch is out of
position.
803201
SL feeder loading
operation
Because Recovery Mode is "Stop Auto Run", loading of the following
tape was not carried out.
EUKYX
2-27199-4100
3.2 Machine Information list
Err Code
(HEX)
Display Area A Display Area B
803202
SL feeder loading
operation
Component verification was carried out, but the tape was not
detected.
803203
SL feeder loading
operation
Loading of the SL feeder.
803204
SL feeder loading
operation
Since the tape end was detected, placement from SL feeder is
moved forward.
803205
SL feeder loading
operation
Placement cycles of both heads are postponed together for SL
feeder loading.
804001 P.C.B. insert alarm
P.C.B. inserted in the Input conveyor. Please remove the inserted
P.C . B . .
804002 P.C.B. insert alarm
P.C.B. inserted in the Output conveyor. Please remove the inserted
P.C . B . .
805001
Backup base out-of-
step detection
Out-of-step detection was carried out with the positioning axis (left).
Adjust the position of the slit cam for out-of-step detection. Check
whether the sensor for slit detection is disconnected.
805002
Backup base out-of-
step detection
Out-of-step detection was carried out with the positioning axis
(right). Adjust the position of the slit cam for out-of-step detection.
Check whether the sensor for slit detection is disconnected.
805003
Backup base out-of-
step detection
Out-of-step detection was carried out with the positioning axis
(A-lane/left). Adjust the position of the slit cam for out-of-step
detection. Check whether the sensor for slit detection is
disconnected.
805004
Backup base out-of-
step detection
Out-of-step detection was carried out with the positioning axis
(A-lane/right). Adjust the position of the slit cam for out-of-step
detection. Check whether the sensor for slit detection is
disconnected.
805005
Backup base out-of-
step detection
Out-of-step detection was carried out with the positioning axis
(B-lane/left). Adjust the position of the slit cam for out-of-step
detection. Check whether the sensor for slit detection is
disconnected.
805006
Backup base out-of-
step detection
Out-of-step detection was carried out with the positioning axis
(B-lane/left). Adjust the position of the slit cam for out-of-step
detection. Check whether the sensor for slit detection is
disconnected.
806001
Bad Mark transfer
information
mismatching
Bad Mark transfer information and PP data have mismatching. Bad
Mark inspection is carried out.
809201
Library tape width
check
The tape width in library and the feeder are not in agreement. Please
check the library and feeder.
809301
Library Feed Pitch
check
Library Feed Pitch differs from Feeder. Please check Library and
Feeder.
809401
Library component size
check
Library Component size differs from Feeder. Please check Library
and Feeder.
809402
Library component size
check
Library Component size X is too large to a feeder. Please check
Library and Feeder.
809403
Library component size
check
Library Component size X is too small to a feeder. Please check
Library and Feeder.
809404
Library component size
check
Library Component size Y is too large to a feeder. Please check
Library and Feeder.
809405
Library component size
check
Library Component size Y is too small to a feeder. Please check
Library and Feeder.
809501
Library Feeder Type
check
Library Component Configuration differs from Feeder. Please use
Tape thickness extended Feeder.
EUKYX
2-28199-4100
3.2 Machine Information list
Err Code
(HEX)
Display Area A Display Area B
809502
Library Feeder Type
check
Library Component Configuration differs from Feeder. Please set
[Tape thickness extended Feeder] in [Use].
809503
Library Feeder Type
check
Library Component Configuration differs from Feeder. Please check
Library and Feeder.
809c01 Motor system error
(System Error : 0xE400) Communication not establish with Servo
Amp (XY Beam).
809c02 Motor system error (System Error : 0xE405) Servo Amp parameter error.
809c03 Motor system error
(System Error : 0xE400) Communication not establish with Servo
Amp (Head).
809c04 Motor system error The system error occurred in SSCNET.
809d01
Recycle conveyor filled
up
Recycle conveyor became Full. (Block1)
809d02
Recycle conveyor filled
up
Recycle conveyor became Full. (Block2)
809e01 Automatic Teaching
Please skip it because Automatic modification Teaching is
impossible in Nozzle position of Head1.
809e02 Automatic Teaching
Please skip it because Automatic modification Teaching is
impossible in Nozzle position of Head2.
809f01
Confirm Tray Safety
Cover
There is no magazine. Magazine 1 (Lower).
809f02
Confirm Tray Safety
Cover
Rack shutter of operator side is open. Magazine 1 (Lower)
809f03
Confirm Tray Safety
Cover
Rack shutter of traverse side is open. Magazine 1 (Lower)
809f04
Confirm Tray Safety
Cover
The Magazine is not set correctly. Magazine 1 (Lower)
Check lock lever of magazine.
809f05
Confirm Tray Safety
Cover
There is no magazine. Magazine 2 (Upper).
809f06
Confirm Tray Safety
Cover
Rack shutter of operator side is open. Magazine 2 (Upper)
809f07
Confirm Tray Safety
Cover
Rack shutter of traverse side is open. Magazine 2 (Upper)
809f08
Confirm Tray Safety
Cover
The Magazine is not set correctly. Magazine 2 (Upper)
Check lock lever of magazine.
809f09
Confirm Tray Safety
Cover
Motor Error of Magazine (Lower) is detected.
809f0a
Confirm Tray Safety
Cover
Motor Error of Magazine (Upper) is detected.
80a001 Recognition Error Failed in the recognition of the part. Please retry pickup of the part.
80a002 Recognition Error Nozzle position teaching failure. Check nozzle condition.
80a003 Recognition Error
It failed in the light emitter recognition of the side view camera.
Please confirm the light emitter of the side view camera.
80a101
Reading the Side view
camera sensor Version
The operation for turning on is invalid. Please do operation again
after turning on completely.
80b001
Automatic Teaching
Error
Failed in the recognition. Carr it out again on the next time. Please
carry out cleaning of a nozzle, cleaning of a reference mark, and
re-instruction based on head rotations.
80b002
Automatic Teaching
Error
The jam for a nozzle was detected (Recognition). Please carry out
cleaning of a nozzle
80c001 Tray turning on
Failed in turning on Driver power of Tray (Block1) Magazine1
(Lower).Please confirm the wiring of Machine
