EUKYX

2-28199-4100

3.2 Machine Information list

Err Code

(HEX)

Display Area A Display Area B

809502

Library Feeder Type

check

Library Component Configuration differs from Feeder. Please set

[Tape thickness extended Feeder] in [Use].

809503

Library Feeder Type

check

Library Component Configuration differs from Feeder. Please check

Library and Feeder.

809c01 Motor system error

(System Error : 0xE400) Communication not establish with Servo

Amp (XY Beam).

809c02 Motor system error (System Error : 0xE405) Servo Amp parameter error.

809c03 Motor system error

(System Error : 0xE400) Communication not establish with Servo

Amp (Head).

809c04 Motor system error The system error occurred in SSCNET.

809d01

Recycle conveyor filled

Recycle conveyor became Full. (Block1)

809d02

Recycle conveyor filled

Recycle conveyor became Full. (Block2)

809e01 Automatic Teaching

Please skip it because Automatic modification Teaching is

impossible in Nozzle position of Head1.

809e02 Automatic Teaching

Please skip it because Automatic modification Teaching is

impossible in Nozzle position of Head2.

809f01

Confirm Tray Safety

Cover

There is no magazine. Magazine 1 (Lower).

809f02

Confirm Tray Safety

Cover

Rack shutter of operator side is open. Magazine 1 (Lower)

809f03

Confirm Tray Safety

Cover

Rack shutter of traverse side is open. Magazine 1 (Lower)

809f04

Confirm Tray Safety

Cover

The Magazine is not set correctly. Magazine 1 (Lower)

Check lock lever of magazine.

809f05

Confirm Tray Safety

Cover

There is no magazine. Magazine 2 (Upper).

809f06

Confirm Tray Safety

Cover

Rack shutter of operator side is open. Magazine 2 (Upper)

809f07

Confirm Tray Safety

Cover

Rack shutter of traverse side is open. Magazine 2 (Upper)

809f08

Confirm Tray Safety

Cover

The Magazine is not set correctly. Magazine 2 (Upper)

Check lock lever of magazine.

809f09

Confirm Tray Safety

Cover

Motor Error of Magazine (Lower) is detected.

809f0a

Confirm Tray Safety

Cover

Motor Error of Magazine (Upper) is detected.

80a001 Recognition Error Failed in the recognition of the part. Please retry pickup of the part.

80a002 Recognition Error Nozzle position teaching failure. Check nozzle condition.

80a003 Recognition Error

It failed in the light emitter recognition of the side view camera.

Please confirm the light emitter of the side view camera.

80a101

Reading the Side view

camera sensor Version

The operation for turning on is invalid. Please do operation again

after turning on completely.

80b001

Automatic Teaching

Error

Failed in the recognition. Carr it out again on the next time. Please

carry out cleaning of a nozzle, cleaning of a reference mark, and

re-instruction based on head rotations.

80b002

Automatic Teaching

Error

The jam for a nozzle was detected (Recognition). Please carry out

cleaning of a nozzle

80c001 Tray turning on

Failed in turning on Driver power of Tray (Block1) Magazine1

(Lower).Please confirm the wiring of Machine

EUKYX

2-29199-4100

3.2 Machine Information list

Err Code

(HEX)

Display Area A Display Area B

80c002 Tray turning on

Failed in turning on Driver power of Tray (Block1) Magazine1

(Upper).Please confirm the wiring of Machine

80c003 Tray turning on

Failed in turning on Driver power of Tray (Block2) Magazine2

(Lower).Please confirm the wiring of Machine

80c004 Tray turning on

Failed in turning on Driver power of Tray (Block2) Magazine2

(Upper).Please confirm the wiring of Machine

80c101

Tray ACV miss-

placement error (Step)

Error of miss-placement : Tray (Block1) Magazine1 (Lower)

80c102

Tray ACV miss-

placement error (Step)

Error of miss-placement : Tray (Block1) Magazine2 (Upper)

80c103

Tray ACV miss-

placement error (Step)

Error of miss-placement : Tray (Block2) Magazine1 (Lower)

80c104

Tray ACV miss-

placement error (Step)

Error of miss-placement : Tray (Block2) Magazine2 (Upper)

80c201

Tray ACV miss-

placement error

(Magazine)

Tray (Block1) Magazine1 (Lower) Cannot use it in AUTO OPN MODE

(PLACEMENT) because of miss-placement.

80c202

Tray ACV miss-

placement error

(Magazine)

Tray (Block1) Magazine2 (Upper) Cannot use it in AUTO OPN MODE

(PLACEMENT) because of miss-placement.

80c203

Tray ACV miss-

placement error

(Magazine)

Tray (Block2) Magazine1 (Lower) Cannot use it in AUTO OPN MODE

(PLACEMENT) because of miss-placement.

80c204

Tray ACV miss-

placement error

(Magazine)

Tray (Block2) Magazine2 (Upper) Cannot use it in AUTO OPN MODE

(PLACEMENT) because of miss-placement.

80c301

Tray Safety Cover Lock

cleared (Auto Run)

Cannot clear Lock because Cmpnt shortage is not found on Tray

(Block1) Magazine1 (Lower).

80c302

Tray Safety Cover Lock

cleared (Auto Run)

Cannot clear Lock because Cmpnt shortage is not found on Tray

(Block1) Magazine2 (Upper).

80c303

Tray Safety Cover Lock

cleared (Auto Run)

Cannot clear Lock because Cmpnt shortage is not found on Tray

(Block2) Magazine1 (Lower).

80c304

Tray Safety Cover Lock

cleared (Auto Run)

Cannot clear Lock because Cmpnt shortage is not found on Tray

(Block2) Magazine2 (Upper).

80c401 Nozzle Exchange

There is no nozzle required for production. Please check the

following.

1. Existence of Nozzle Stocker, Clamp Condition

2. Nozzle Configuration Data

80c402 Nozzle Exchange

A nozzle cannot be stored. Please check the following.

1. Existence of Nozzle Stocker, Clamp Condition

2. Nozzle Configuration Data

80c403 Nozzle Exchange ODD Noz of Head is stored for storing high-speed Noz.

80c404 Nozzle Exchange Noz is stored due to error in teaching Noz Position.

80c405 Nozzle Exchange Please take down the nozzle stocker.

80c406 Nozzle Exchange

A necessary nozzle is installed in the head that has not been

selected. Please select the back and forth block, and execute the

nozzle exchange.

80c501

Overall Setup

(Exchange support pin)

Pattern Program data set the support pin as [No exchange], so that

skipped it.

80c502

Overall Setup

(Exchange support pin)

Noz is not for Support Pin Exchange, so that it is stored.

EUKYX

2-30199-4100

3.2 Machine Information list

Err Code

(HEX)

Display Area A Display Area B

80c503

Overall Setup

(Exchange support pin)

There is no available nozzle for backup pin exchange. In the case of

a multi function head, please set a nozzle to No.1 - No.7 of the

stocker.

80c504

Overall Setup

(Exchange support pin)

Conveyor Width is stopped at the position for exchanging support

pins because the Support pins of Lane A are stored. Please take out

Support pins from machine, or install Conveyor Width after setting

them at production position.

80c505

Overall Setup

(Exchange support pin)

Support pins is not inserted correctly. Check the insertion of support

pins at "Setup"-"Sprt-Pins"-"Sup.Pins Insert Check", please insert

normally.

80c601

Overall Setup

(Conveyor width setup)

Pattern Program data set the conveyor width as [No Setup]. So that

skipped it.

80c701

Nozzle Level Offset

Teaching

All E/NR from side view camera sensor is detected. Please confirm

it because there is a possibility that ODD Noz is placed.

80c702

Nozzle Level Offset

Teaching

Could not do Teaching because Noz for measurement on Head1 is

not set.

80c703

Nozzle Level Offset

Teaching

Could not do Teaching because Noz for measurement on Head2 is

not set.

80c704

Nozzle Level Offset

Teaching

The Length of measured Noz is out of Allowable Range. Please

confirm the Noz of Head.

80c801 Cutter Auto Reset Cutter Auto Reset of Device (Block1) is executed. (The 1st)

80c802 Cutter Auto Reset Cutter Auto Reset of Device (Block2) is executed. (The 1st)

80c803 Cutter Auto Reset Cutter Auto Reset of Device (Block1) is executed. (The 2nd)

80c804 Cutter Auto Reset Cutter Auto Reset of Device (Block2) is executed. (The 2nd)

80c805 Cutter Auto Reset Cutter Auto Reset of Device (Block1) is executed. (The 3rd)

80c806 Cutter Auto Reset Cutter Auto Reset of Device (Block2) is executed. (The 3rd)

80c901

Recycling Conveyor

(Block1)

Recycling Conveyor (Block1) is on ready. Please remove parts and

resume production after completion of operation.

80ca01

Recycling Conveyor

(Block2)

Recycling Conveyor (Block2) is on ready. Please remove parts and

resume production after completion of operation.

80cb01

Undetermined Tray

Comp. (Block1)

An undetermined component is detected.

80cc01

Undetermined Tray

Comp. (Block2)

An undetermined component is detected.

80d001

Counter Board

synchronization gap

detection (Head1)

The synchronization gap of Counter Board was detected (X-axis).

80d002

Counter Board

synchronization gap

detection (Head1)

The synchronization gap of Counter Board was detected (Y-axis).

80d101

Counter Board

synchronization gap

detection (Head2)

The synchronization gap of Counter Board was detected (X-axis).

80d102

Counter Board

synchronization gap

detection (Head2)

The synchronization gap of Counter Board was detected (Y-axis).

80d201

Side view camera

synchronization gap

detection (Head1)

The synchronization gap of Side view camera was detected. Please

confirm the connector of the encoder cable.

80d301

Side view camera

synchronization gap

detection (Head2)

The synchronization gap of Side view camera was detected. Please

confirm the connector of the encoder cable.
