EUKYX

3-10199-4100

3.1 Safety Device

Error ID Error Name, Description, Cause, and Remedy

400896 Servo Alarm

Zero set miss alarm

-----

40089F Servo Alarm

Battery warning

-----

4008E0 Servo Alarm

Over-Regenerative alarm

Drive with blocking tact.

4008E1 Servo Alarm

Overload alarm1

Drive with blocking Tact.

4008E3 Servo Alarm

Absolute position counter warning

Perform noise strategies of encoder or exchange servo amplifier.

4008E4 Servo Alarm

Parameter warning

Check out servo parameter.

4008E6 Servo Alarm

Servo forced stop alarm

EM1, emergency stop input of Servo amplifier is off.

4008E7 Servo Alarm

Controller emergency stopping warning

outputted emergency stop from Controller.

4008E8 Servo Alarm

No. of Rot dropping warning of Cooling Fan

Exchange the Cooling fan.

4008E9 Servo Alarm

Main circuit off warning

Main circuit is Off.

4008EB Servo Alarm

another axis warning

Error in another axis in the same P.C.B. Please remove the factor of error.

4008EC Servo Alarm

Overload alarm2

Please perform Optimize.

4008ED Servo Alarm

Output Watt over warning

Driver with blocking Tact.

40 0 911 Servo Alarm

Power drive Error, Over-current

Check out motor wiring or exchange both motor and driver

400921 Servo Alarm

Overload Alarm

Check out motor wiring or exchange both motor and driver. Either, Confirm that the blocking

exists with cutter pieces.

EUKYX

3-11199-4100

3.1 Safety Device

Error ID Error Name, Description, Cause, and Remedy

400931 Servo Alarm

Speed Alarm

Readjust motor gain.

400941 Servo Alarm

multi-cycle Error

Check out the motor wiring or exchange the motor.

400942 Servo Alarm

The value of variation counter is out of the range

Check out the wiring of Origin sensor. Or, Exchange driver.

400951 Servo Alarm

Power Drive detected temperature error

Ambient Temperature is high. Exchange driver.

400961 Servo Alarm

Sensor Error

Check Motor Encoder wires. Or, exchange the motor.

400962 Servo Alarm

Sensor Error

Check Motor Encoder wires. Or, exchange the motor.

400971 Servo Alarm

high drive Voltage

Insufficient power. Exchange driver.

400972 Servo Alarm

Low drive Voltage

Check out the drive power wiring putted in Driver. Or, check out DC48V.

400991 Servo Alarm

Reading Error on permanent memory

Exchange the driver.

400992 Servo Alarm

Writing Error on permanent memory

Exchange the driver.

400998 Servo Alarm

CPU Error

Exchange the driver.

400999 Servo Alarm

Parameter Error

Confirm the changed value of Parameter.

400a08 Head Interlock Error

Releasing the brake is impossible during Servo On.

-----

400b01 Feeder preparation complete

A pick up miss comp or disengaged Latch was detected.

Open the safety cover and confirm that there is no interference with the head, and then,

release the ready feeder.

400c01 Nozzle stocker down time out

Nozzle stock unit lower bound detection 1 was not turned on in prescribed time.

Please confirm the lower bound detection 1 sensor of nozzle stock unit.

EUKYX

3-12199-4100

3.1 Safety Device

Error ID Error Name, Description, Cause, and Remedy

400c02 Nozzle stocker down time out

Nozzle stock unit lower bound detection 2 was not turned on in prescribed time.

Please confirm the lower bound detection 2 sensor of nozzle stock unit.

400c03 Nozzle stocker down time out

Nozzle stock unit lower bound detection 3 was not turned on in prescribed time.

Please confirm the lower bound detection 3 sensor of nozzle stock unit.

400c04 Nozzle stocker down time out

Nozzle stock unit lower bound detection 4 was not turned on in prescribed time.

Please confirm the lower bound detection 4 sensor of nozzle stock unit.

400d01 Software Interlock Error

Head1 NL axis's poor operation was detected, and the scram of the XY axis was carried out.

Please perform a zeroing.

400d02 Software Interlock Error

Head2 NL axis's poor operation was detected, and the scram of the XY axis was carried out.

Please perform a zeroing.

400d03 Software Interlock Error

NL axis(Head2) Interlock Detected.

Please confirm the nozzle has not fallen when you push the beam by the hand.

Please perform a zeroing.

400d04 Software Interlock Error

NL axis(Head1) Interlock Detected.

Please confirm the nozzle has not fallen when you push the beam by the hand.

Please perform a zeroing.

400d05 Software Interlock Error

L1 axis(Head2) Interlock Detected.

Please confirm the nozzle has not fallen when you push the beam by the hand.

Please confirm detection of Pass Line, excess pushing.

400d06 Software Interlock Error

L2 axis(Head2) Interlock Detected.

Please confirm the nozzle has not fallen when you push the beam by the hand.

Please confirm detection of Pass Line, excess pushing.

400d07 Software Interlock Error

L3 axis(Head2) Interlock Detected

Please confirm detection of Pass Line, excess pushing.

400d08 Software Interlock Error

L1 axis(Head1) Interlock Detected.

Please confirm the nozzle has not fallen when you push the beam by the hand.

Please confirm detection of Pass Line, excess pushing.

400d09 Software Interlock Error

L2 axis(Head1) Interlock Detected.

Please confirm the nozzle has not fallen when you push the beam by the hand.

Please confirm detection of Pass Line, excess pushing.
