EUKYX

3-24199-4100

3.3 Conveyor

Error ID Error Name, Description, Cause, and Remedy

420133 Backup(L) Error

Adsorb of PCB was off during the production.

Please check the status of PCB, and perform positioning again.

420201 Backup(R) Error.

The Backup(R) Axis was not completed within predetermined time.

Backup axis is unable to do upward movement and down movement.

The factor is for Motor, Driver, Sensor Error or wiring Error.

Please check the motor, sensor on Machine check screen.

420202 Backup(R) Error.

Driver Alarm on Backup(R) Axis

Confirm reset Method of detailed Sub-system error counts of Alarm.

420203 Backup(R) Error.

Error in calculating data of positioning command of Backup(R) Axis

Please confirm the following data.

1. Machine Offset/Backup Pin(Up/Down)

2. Pattern Program/P.C.B. Information/P.C.B. size/Thickness

3. Control/Common/PRE-PLACED CMPNT THKNS/Bottom of P.C.B.

420204 Backup(R) Error.

Time-over of zeroing of Backup(R) Axis

Check out the dirt, error, disconnection of sensor. If there is no problem with sensor, the

problem could be with motor wire/single error.

420205 Backup(R) Error.

Time-over of the upward movement of stopper(R)

1. Please confirm whether P.C.B. is caught between stopper and conveyor.

2. Error in Up/Down detecting sensor. Please check sensor input.

3. Disconnection/Error of Output. Please confirm the stopper by manual if sensor

input is correct.

4. Please reset the speed by adjusting speed control when stopper is slow.

420206 Backup(R) Error.

Time-over of the downward movement of stopper(R)

1. Error in Up/Down detecting sensor. Confirm the sensor.

2. Disconnection/Error of Output. Please confirm the stopper by manual if sensor

input is correct.

3. Please reset the speed by adjusting speed control when stopper is slow.

420207 Backup(R) Error.

Communication Error of the command movement of P.C.B. positioning(Backup)

Motor Driver Error Trouble in communication system(AE-LINK), possibility of Error of

communication P.C.B.(API).

Please confirm wiring of communication line and Power line.

420208 Backup(R) Error.

Backup Pin/Jig under the conveyor belt is detected.

Check out the interference in Belt on Backup Base does not exist.

EUKYX

3-25199-4100

3.3 Conveyor

Error ID Error Name, Description, Cause, and Remedy

420210 Backup(R) Error.

Not ready for System setup of Backup(R) axis

Driver has not completed the parameter setup yet. It is a situation in which a correct setup

has not been received by Communication Error.

Check the Communication Mode, wiring, Power supply of Driver.

420211 Backup(R) Error.

Error in zeroing in Backup(R) axis

LS, discontinuous zeroing movement, was detected.

Check out the dirt, error of sensor and error in Motor body etc.

420212 Backup(R) Error.

Out-of-Control of Backup(R)

Motor Out-of-Control which is over the width of Out-of-Control detecting occurred. Please

execute all zeroing again, and the restart production.

Please set motor speed slow if it happens frequently. Also, in a case of structure motor

Error.

420213 Backup(R) Error.

Error in motor power voltage of Backup(R) axis

Motor power voltage dropped. Check out the Power supply line(48V Line)

420214 Backup(R) Error.

STP input of Backup(R) Axis is detected

STP input is detected. The function to stop motor by Hard signal.

420215 Backup(R) Error.

Over-current of Backup(R) Axis

Abnormal current in motor output line was detected.

Confirm the motor wiring, supplying power.

420216 Backup(R) Error.

Limit Sensor(+) of Backup(R) axis is detected

+LS signal was detected for moving for (+).

Please check the dirt of +LS sensor, disconnection.

420217 Backup(R) Error.

Limit Sensor(-) of Backup(R) axis is detected

-LS signal was detected for moving for (-).

Please check the dirt of -LS sensor, disconnection.

420218 Backup(R) Error.

Disconnection Motor of Backup(R) axis is detected

Disconnection to motor was detected.(Only stop mode)

Check the motor wiring.

420219 Backup(R) Error.

Error in the Control Power Voltage of Backup(R) axis

Control power for driver dropped. Check out the Power supply line.(24V Line)

42021a Backup(R) Error.

Reserved Code

Reserved Function of driver. Please make inquiries when error is detected.

EUKYX

3-26199-4100

3.3 Conveyor

Error ID Error Name, Description, Cause, and Remedy

42021b Backup(R) Error.

Reserved Code

Reserved Function of driver. Please make inquiries when error is detected.

42021c Backup(R) Error.

Reserved Code

Reserved Function of driver. Please make inquiries when error is detected.

42021d Backup(R) Error.

Reserved Code

Reserved Function of driver. Please make inquiries when error is detected.

42021e Backup(R) Error.

Reserved Code

Reserved Function of driver. Please make inquiries when error is detected.

42021f Backup(R) Error.

System Error of Backup(R) axis

System Error of internal driver. Driver error is supposed if this problem happens frequently.

420220 Backup(R) Error.

Communication Error of the Backup(R) axis

1. Confirm connection to communication cable.

2. Confirm Power supply(24V).

3. Confirm the communication setting of PCI board.

4. Confirm the address of driver and communication rate setting.

420231 Backup(R) Error.

Failed to adsorb PCB.

Please check the status of PCB, and perform positioning again.

420232 Backup(R) Error.

Failed to adsorb off of PCB.

Please check the status of PCB, and perform to release positioning again.

420233 Backup(R) Error.

Adsorb of PCB was off during the production.

Please check the status of PCB, and perform positioning again.

420301 A-lane Backup (L) Axis

-----

420401 A-lane Backup (R) Axis

-----

420501 B-lane Backup (L) Axis

-----

420601 B-lane Backup (R) Axis

-----

421001 Error in Transfer section

Transfer operation was not completed within predetermined time.

-----
