EUKYX
3-41199-4100
3.3 Conveyor
Error ID Error Name, Description, Cause, and Remedy
424003 Stopper movement Error
Time Over of the upward movement of stopper
1.Check out the P.C.B. between stopper and conveyor
2. Error in Up/Down detection sensor. Check out the sensor input
3.Disconnection, Error of Movement output. Please check Stopper by manual movement if
sensor input is proper.
4. Please set speed again by adjusting speed control when stopper is slow.
424004 Stopper movement Error
Input stop sensor is detected before input stopper goes up.
PCB has reached the stopper. Please confirm that the start position for placement PCB is
correct.
424005 Stopper movement Error
Output stop sensor is detected before output stopper goes up.
PCB has reached the stopper. Please confirm that the start position for placement PCB is
correct.
424101 Detection of Input conveyor P.C.B.
P.C.B. was detected before starting placement from input machine
Please remove indefinite P.C.B. from conveyor. Confirm whether P.C.B. is not detected
before P.C.B. transfer.
424102 Detection of Input conveyor P.C.B.
P.C.B. on Input conveyor is existing
Remove P.C.B. from Conveyor.
424201 Detection of output conveyor P.C.B.
P.C.B. was detected before starting output for output machine
Remove P.C.B. from Conveyor.
424202 Detection of output conveyor P.C.B.
The output for Output machine is completed, but P.C.B. on conveyor was detected
Remove P.C.B. from Conveyor.
424301 Detection of positioning conveyor(R) P.C.B.
No P.C.B. on conveyor
Output P.C.B. is not detected. Please confirm whether P.C.B. is detected correctly or not.
424302 Detection of positioning conveyor(R) P.C.B.
The placement was completed, but P.C.B. was not detected.
Placed P.C.B. is not detected. Please confirm whether P.C.B. is detected correctly or not.
425101 Detection of Input conveyor sensor
Decrease sensor was detected before starting
Remove P.C.B. from Input Conveyor.
425102 Detection of Input conveyor sensor
Decrease sensor was not detected before starting
Placing P.C.B. is not found internal machine.
1. Please put P.C.B. on the sensor
2. Because there is a possibility of P.C.B. falling, please confirm the width of
conveyor.
425103 Detection of Input conveyor sensor
Stop sensor was detected before starting
Remove P.C.B. from Input Conveyor.
EUKYX
3-42199-4100
3.3 Conveyor
Error ID Error Name, Description, Cause, and Remedy
425104 Detection of Input conveyor sensor
Stop sensor was Not detected before starting
Placing P.C.B. is not found internal machine.
1. Please put P.C.B. on the sensor
2. Because there is a possibility of P.C.B. falling, please confirm the width of
conveyor.
425105 Detection of Input conveyor sensor
P.C.B. on decrease sensor was detected after movement completion
Remove P.C.B. from Input Conveyor.
425106 Detection of Input conveyor sensor
P.C.B. on decrease sensor was not detected after movement completion
Please check whether P.C.B. is detected correctly.
Confirm whether the sensor doesn’t have Error.
425107 Detection of Input conveyor sensor
P.C.B. on stop sensor was detected after movement completion
Remove P.C.B. from Input Conveyor.
425108 Detection of Input conveyor sensor
P.C.B. on stop sensor was not detected after movement completion
Please check whether P.C.B. is detected correctly.
Check whether the sensor doesn’t have Error.
425109 Detection of Input conveyor sensor
P.C.B. on Input conveyor was detected
Remove P.C.B. from Conveyor.
42510a Detection of Input conveyor sensor
P.C.B. on Input conveyor was not detected
Please check whether P.C.B. is detected correctly. Check whether the sensor doesn’t have
Error.
42510b Detection of Input conveyor sensor
2 P.C.B. pieces on conveyor exist.
1. Remove it if unnecessary P.C.B. exists, when checking P.C.B. on Conveyor.
2. Please return PCB to Stop sensor of input conveyor when PCB on input conveyor
is taken on positioning conveyor.
42510c Detection of Input conveyor sensor
P.C.B. on sensor was detected in the state of not placing P.C.B.
There is a possibility whether P.C.B. is inserted or P.C.B. arrived before detecting signals.
42510d Detection of Input conveyor sensor
Disengaged P.C.B. of Input conveyor
Possible to driver continuously.
Please confirm the state of P.C.B. if it is not removed purposely
42510e Detection of Input conveyor sensor
P.C.B. was not detected when placement was completed
P.C.B. from Input Machine is not received and sent.
Please confirm whether P.C.B. on Input conveyor is caught.
EUKYX
3-43199-4100
3.3 Conveyor
Error ID Error Name, Description, Cause, and Remedy
42510f Detection of Input conveyor sensor
P.C.B. was detected from Input conveyor sensor
P.C.B. is inserted though the mode that could not be inserted.
Please remove the inserted P.C.B..
425110 Detection of Input conveyor sensor
P.C.B. was detected from Input conveyor sensor
P.C.B. is inserted in P-OUT valid mode.
425111 Detection of Input conveyor sensor
There is a possibility of interference between output PCB and input PCB.
Passing PCB occurred during simultaneous transfer. Please confirm that output is running
without problems.
425201 Input conveyor timeout
Placement was not completed within predetermined time.
There is a possibility that P.C.B. is caught, or dropped from Conveyor.
Please check the transition with Input Machine.
425202 Input conveyor timeout
Output was not completed within predetermined time.
There is a possibility that P.C.B. is caught, or dropped from Conveyor.
Please check the above conveyor.
425301 Input conveyor Error
Error in Input conveyor
-----
426101 Detection of positioning conveyor sensor
Decrease sensor of input position was detected before starting.
There is an indefinite P.C.B. on Input position decelerating sensor.
Please remove P.C.B..
426102 Detection of positioning conveyor sensor
Decrease sensor of input position was not detected before starting.
There is no P.C.B. on conveyor.
1. Please put P.C.B. on Sensor
2. There is a possibility of P.C.B. fallen. Please check the width of Conveyor.
426103 Detection of positioning conveyor sensor
Stop sensor of input position was detected before starting.
There is an indefinite P.C.B. on Input position stop sensor. Please remove P.C.B..
426104 Detection of positioning conveyor sensor
Stop sensor of input position was not detected before starting.
There is no P.C.B. on conveyor.
1. Please put P.C.B. on Sensor
2. There is a possibility of P.C.B. fallen. Please check the width of Conveyor.
426105 Detection of positioning conveyor sensor
Decrease sensor of input position was detected after movement completion
There is an indefinite P.C.B. on Input position decelerating sensor. Please remove P.C.B..
426106 Detection of positioning conveyor sensor
Decrease sensor of input position was not detected after movement completion
Please check whether P.C.B. is detected correctly. Check whether the sensor doesn’t have
Error.
