EUKYX
3-43199-4100
3.3 Conveyor
Error ID Error Name, Description, Cause, and Remedy
42510f Detection of Input conveyor sensor
P.C.B. was detected from Input conveyor sensor
P.C.B. is inserted though the mode that could not be inserted.
Please remove the inserted P.C.B..
425110 Detection of Input conveyor sensor
P.C.B. was detected from Input conveyor sensor
P.C.B. is inserted in P-OUT valid mode.
425111 Detection of Input conveyor sensor
There is a possibility of interference between output PCB and input PCB.
Passing PCB occurred during simultaneous transfer. Please confirm that output is running
without problems.
425201 Input conveyor timeout
Placement was not completed within predetermined time.
There is a possibility that P.C.B. is caught, or dropped from Conveyor.
Please check the transition with Input Machine.
425202 Input conveyor timeout
Output was not completed within predetermined time.
There is a possibility that P.C.B. is caught, or dropped from Conveyor.
Please check the above conveyor.
425301 Input conveyor Error
Error in Input conveyor
-----
426101 Detection of positioning conveyor sensor
Decrease sensor of input position was detected before starting.
There is an indefinite P.C.B. on Input position decelerating sensor.
Please remove P.C.B..
426102 Detection of positioning conveyor sensor
Decrease sensor of input position was not detected before starting.
There is no P.C.B. on conveyor.
1. Please put P.C.B. on Sensor
2. There is a possibility of P.C.B. fallen. Please check the width of Conveyor.
426103 Detection of positioning conveyor sensor
Stop sensor of input position was detected before starting.
There is an indefinite P.C.B. on Input position stop sensor. Please remove P.C.B..
426104 Detection of positioning conveyor sensor
Stop sensor of input position was not detected before starting.
There is no P.C.B. on conveyor.
1. Please put P.C.B. on Sensor
2. There is a possibility of P.C.B. fallen. Please check the width of Conveyor.
426105 Detection of positioning conveyor sensor
Decrease sensor of input position was detected after movement completion
There is an indefinite P.C.B. on Input position decelerating sensor. Please remove P.C.B..
426106 Detection of positioning conveyor sensor
Decrease sensor of input position was not detected after movement completion
Please check whether P.C.B. is detected correctly. Check whether the sensor doesn’t have
Error.
EUKYX
3-44199-4100
3.3 Conveyor
Error ID Error Name, Description, Cause, and Remedy
426107 Detection of positioning conveyor sensor
Stop sensor of input position was detected after movement completion
There is an indefinite P.C.B. on Input position stop sensor. Please remove P.C.B..
426108 Detection of positioning conveyor sensor
Stop sensor of input position was not detected after movement completion
Please check whether P.C.B. is detected correctly. Check whether the sensor doesn’t have
Error.
426109 Detection of positioning conveyor sensor
Decrease sensor of output position was detected before starting.
There is an indefinite P.C.B. on Output position decelerating sensor. Please remove P.C.B..
42610a Detection of positioning conveyor sensor
Decrease sensor of output position was not detected before starting.
There is no P.C.B. on conveyor.
1. Please put P.C.B. on Sensor
2. There is a possibility of P.C.B. fallen. Please check the width of Conveyor.
42610b Detection of positioning conveyor sensor
Stop sensor of output position was detected before starting.
There is an indefinite P.C.B. on Output position stop sensor. Please remove P.C.B..
42610c Detection of positioning conveyor sensor
Stop sensor of output position was not detected before starting.
There is no P.C.B. on conveyor.
1. Please put P.C.B. on Sensor
2. There is a possibility of P.C.B. fallen. Please check the width of Conveyor.
42610d Detection of positioning conveyor sensor
Decrease sensor of output position was detected after movement completion
There is an indefinite P.C.B. on Output position stop sensor. Please remove P.C.B..
42610e Detection of positioning conveyor sensor
Decrease sensor of output position was not detected after movement completion
-----
42610f Detection of positioning conveyor sensor
Stop sensor of output position was detected after movement completion
There is an indefinite P.C.B. on Output position stop sensor. Please remove P.C.B..
426110 Detection of positioning conveyor sensor
Stop sensor of output position was not detected after movement completion
Please check whether P.C.B. is detected correctly. Check whether the sensor doesn’t have
Error.
426111 Detection of positioning conveyor sensor
P.C.B. on positioning conveyor was detected
Please remove P.C.B. from positioning conveyor.
426112 Detection of positioning conveyor sensor
NO P.C.B. on positioning conveyor
Confirm whether P.C.B. is not dropping. Confirm whether Sensor is not broken.
426113 Detection of positioning conveyor sensor
There is a possibility of interference between Output PCB and Input PCB.
Passing PCB occurred during simultaneous transfer. Please confirm that output is running
without problems.
EUKYX
3-45199-4100
3.3 Conveyor
Error ID Error Name, Description, Cause, and Remedy
426114 Detection of positioning conveyor sensor
PCB has now reached input position.
1. There is a possibility that PCB is inserted and is dropped from conveyor. Please
check the conveyor.
2. Please clear the PCB memory information in the edit screen if it is on the input
conveyor. Or, return the removed PCB."
426201 positioning conveyor timeout
Placement for input position was not completed within predetermined time.
1. There is a possibility that PCB is inserted between Input conveyor and Input
position or is dropped. Please confirm Input ~ positioning conveyor.
2. Please clear the PCB memory information in the edit screen if it is on the input
conveyor. Or, return the removed PCB.
3. Please check if cutout is on PCB. Please set cutout size in pattern program if
cutout is on PCB.
426202 positioning conveyor timeout
Output from input position was not completed within predetermined time.
1. There is a possibility that PCB is inserted between Input position and Output, or is
dropped. Please confirm positioning ~ output conveyor.
2. Please clear the PCB memory information in the edit screen if it is on the input
position. Or, return the removed PCB.
426203 positioning conveyor timeout
Placement for output position was not completed within predetermined time.
1. There is a possibility that PCB to take in the output position is inserted or dropped.
Please confirm input ~ positioning conveyor.
2. The state of PCB memory on the conveyor differs from the state of taking. Please
clear the PCB memory in the edit screen when if it is. Or, return the removed PCB.
3. Please check if cutout is on PCB. Please set cutout size in pattern program if
cutout is on PCB.
426204 positioning conveyor timeout
Output from output position was not completed within predetermined time.
1. There is a possibility that PCB is inserted between Input position and Output, or is
dropped. Please confirm positioning ~ output conveyor.
2. Please clear the PCB memory information in the edit screen if it is on the output
position. Or, return the removed PCB.
426205 positioning conveyor timeout
Positioning was not completed within the predetermined time.
There is a possibility that PCB is inserted. Please check the PCB on the conveyor.
426301 positioning conveyor Error
Error in positioning conveyor
-----
426302 positioning conveyor Error
Error in positioning change.
Please check the PCB on the conveyor.
427101 Detection of Output conveyor sensor
Decrease sensor was detected before starting.
There is an indefinite P.C.B. on Output conveyor. Please remove it.
