EUKYX
3-50199-4100
3.3 Conveyor
Error ID Error Name, Description, Cause, and Remedy
42a203 Time-out of Shuttle Conveyor in Input side
Time-out is occurred while Delivery Position from Input Machine is being moved.
Please confirm whether there is no error in Unit, no interference or not.
42a204 Time-out of Shuttle Conveyor in Input side
Time-out is occurred while Transfer position is being moved to Inner Machine.
Please confirm whether there is no error in Unit, no interference or not.
42a301 Shutter Conveyor Error in Input side
Error is made while Shuttle Conveyor is working.
-----
42b101 Shutter Conveyor Error in Output side
Decrease Sensor is detected before starting to operate.
Please remove PCB from Shuttle Conveyor.
42b102 Shutter Conveyor Error in Output side
Decrease Sensor is not detected before starting to operate.
PCB to output is not found.
1. Please confirm whether PCB is detected by Sensor.
2. There is a possibility that PCB is dropping. Please confirm whether Conveyor
Width is fit or not.
42b103 Shutter Conveyor Error in Output side
Stop Sensor is detected before starting to operate.
Please remove PCB from Shuttle Conveyor.
42b104 Shutter Conveyor Error in Output side
Stop Sensor is not detected before starting to operate.
PCB to output is not found.
1. Please confirm whether PCB is detected by Sensor.
2. There is a possibility that PCB is dropping.
Please confirm whether Conveyor Width is fit or not.
42b105 Shutter Conveyor Error in Output side
PCB is detected from Decrease Sensor after finishing completely.
Please remove PCB from Shuttle Conveyor.
42b106 Shutter Conveyor Error in Output side
PCB is not detected from Decrease Sensor after finishing completely.
Please confirm whether PCB is detected properly. And confirm whether Sensor did not
break down.
42b107 Shutter Conveyor Error in Output side
PCB is detected from Stop Sensor after finishing completely.
Please remove PCB from Shuttle Conveyor.
42b108 Shutter Conveyor Error in Output side
PCB is not detected from Stop Sensor after finishing completely.
Please confirm whether PCB is detected properly. And confirm whether Sensor did not
break down.
42b109 Shutter Conveyor Error in Output side
PCB is detected from Shuttle Conveyor.
Please remove PCB from Conveyor.
EUKYX
3-51199-4100
3.3 Conveyor
Error ID Error Name, Description, Cause, and Remedy
42b10a Shutter Conveyor Error in Output side
PCB is not detected from Shuttle Conveyor.
Please confirm whether PCB is detected properly. And confirm whether Sensor did not
break down.
42b10b Shutter Conveyor Error in Output side
PCB has not got to shuttle Conveyor from Inner Machine.
PCB from Input Machine is not transferred.
Please confirm whether PCB on the conveyor for Input machine is caught
42b10c Shutter Conveyor Error in Output side
PCB is still on Shuttle Conveyor.
Output for Output Machine has not completed.
Please confirm PCB position.
42b10d Shutter Conveyor Error in Output side
PCB on Shuttle Conveyor is gone.
It is possible to operate continuously.
Please confirm whether PCB went off its position if PCB is not removed on purpose.
42b10e Shutter Conveyor Error in Output side
PCB on Shuttle Conveyor is changed.
PCB is inserted while not possible to be inserted. Please remove inserted PCB.
42b10f Shutter Conveyor Error in Output side
The Sensor of Shuttle Conveyor is detected from both sides.
There is a possibility that two pieces of PCB are inserted. Please remove an uncertain PCB.
42b201 Time-out of Shuttle Conveyor in Output side
Time-out is occurred during insert mode from inner Machine.
There is a possibility that PCB is stopped on conveyor.
1. Please confirm PCB position.
2. Please confirm whether Conveyor Width is fit.
3. Please setup Input Conveyor Timer Value of System settings, and adjust insert
time.
42b202 Time-out of Shuttle Conveyor in Output side
Time-out is occurred during Output Mode for Output Machine.
PCB is stopped between Conveyors. Check out PCB position.
1. Please confirm whether Transit position from shuttle conveyor is proper.
2. Please confirm whether Conveyor Width is fit.
42b203 Time-out of Shuttle Conveyor in Output side
Time-out is occurred while Transfer position from Inner Machine is being moved.
Please confirm whether there is no error in Unit, no interference or not.
42b204 Time-out of Shuttle Conveyor in Output side
Time-out is occurred while Delivery Position is being moved to Output Machine.
Please confirm whether there is no error in Unit, no interference or not.
42b301 Shuttle Conveyor Error in Output side.
Error is made while Shuttle Conveyor is working.
-----
EUKYX
3-52199-4100
3.3 Conveyor
Error ID Error Name, Description, Cause, and Remedy
42b401 Transfer check
PCB is detected on the conveyor. Please remove it.
-----
42b501 Transfer check
Going down in PCB stopper(L) was not completed within the predetermined time.
-----
42b502 Transfer check
Going down in PCB stopper(R) was not completed within the predetermined time.
-----
42b503 Transfer check
Going down in PCB stopper(AL) was not completed within the predetermined time.
-----
42b504 Transfer check
Going down in PCB stopper(AR) was not completed within the predetermined time.
-----
42b505 Transfer check
Going down in PCB stopper(BL) was not completed within the predetermined time.
-----
42b506 Transfer check
Going down in PCB stopper(BR) was not completed within the predetermined time.
-----
42b601 Transfer check
Going down in the backup base(L) was not completed within the predetermined time.
-----
42b602 Transfer check
Going down in the backup base(R) was not completed within the predetermined time.
-----
42b603 Transfer check
Going down in the backup base(AL) was not completed within the predetermined time.
-----
42b604 Transfer check
Going down in the backup base(AR) was not completed within the predetermined time.
-----
42b605 Transfer check
Going down in the backup base(BL) was not completed within the predetermined time.
-----
42b606 Transfer check
Going down in the backup base(BR) was not completed within the predetermined time.
-----
