EUKYX

3-69199-4100

3.5 Tray Feeder (Block2)

Error ID Error Name, Description, Cause, and Remedy

441818 Pre-check Error of Tray Feeder(Block2)

Magazine(Lower) is not done Positioning yet.

Please confirm the Magazine position and Magazine lock lever.

441819 Pre-check Error of Tray Feeder(Block2)

Elevator axis safety relay

-----

44181a Pre-check Error of Tray Feeder(Block2)

Magazine(Upper) Rack Shutter on the operator side is open.

-----

44181b Pre-check Error of Tray Feeder(Block2)

Magazine(Upper) Rack Shutter on the Traverse side is open.

-----

44181c Pre-check Error of Tray Feeder(Block2)

Magazine(Upper) is not done Positioning yet.

Please confirm the Magazine position and Magazine lock lever.

44181d Pre-check Error of Tray Feeder(Block2)

-----

441820 Pre-check Error of Tray Feeder(Block2)

Zeroing incomplete

-----

444001 Tray Feeder Sequence Error (Block2)

Tray feeder sequence timeout

-----

448302 Elevator Unit Exchange (Attach) (Block2)

Elevator Unit is not detected.

Please set up Tray Unit in Exchange location.

448303 Elevator Unit Exchange (Attach) (Block2)

Connector of Feeder base is not positioned correctly.

Please Operate it after connecting connector of Feeder Base.

448304 Elevator Unit Exchange (Attach) (Block2)

Connector of Tray is not positioned correctly.

Operate it after connecting connector of Tray.

448305 Elevator Unit Exchange (Attach) (Block2)

Time-out of Clamp operating of Elevator Unit.

-----

448306 Elevator Unit Exchange (Attach) (Block2)

Feeder Base is not in Upward position.

Please set Feeder Cart, and then press READY switch to rise it on Feeder Base.

448402 Elevator Unit Exchange (Detach) (Block2)

Time-out of Unclamp operating of Elevator Unit.

-----

EUKYX

3-70199-4100

3.5 Tray Feeder (Block2)

Error ID Error Name, Description, Cause, and Remedy

448403 Elevator Unit Exchange (Detach) (Block2)

Feeder Base is not in Upward position.

Please set Feeder Cart, and then press READY switch to rise it on Feeder Base.

448405 Elevator Unit Exchange (Detach) (Block2)

There were error when Tray receded.

-----

448406 Elevator Unit Exchange (Detach) (Block2)

There were error when elevator1(Down) receded.

-----

448407 Elevator Unit Exchange (Detach) (Block2)

There were error when elevator2(Up) receded.

-----

448408 Elevator Unit Exchange (Detach) (Block2)

There were error when traverse receded.

-----

448501 Tray(Block2)

Time-out of waiting for initialization

Please confirm AE-LINK wiring and Power wiring.

448502 Tray(Block2)

Can not communicate Driver.

Please confirm AE-LINK wiring and Power wiring.

448503 Tray(Block2)

Communication Status Error(Stand by)

Please confirm AE-LINK wiring and Power wiring.

448504 Tray(Block2)

Communication Status Error(Alarm)

Please confirm AE-LINK wiring and Power wiring.

448505 Tray(Block2)

Communication Status Error(OT)

Please confirm AE-LINK wiring and Power wiring.

448506 Tray(Block2)

Communication Status Error(Connection O)

Please confirm AE-LINK wiring and Power wiring.

448507 Tray(Block2)

Communication Status Error(Driver Alarm)

Please confirm AE-LINK wiring and Power wiring.

448508 Tray(Block2)

Communication Status Error(SV-net stopping)

Please confirm AE-LINK wiring and Power wiring.

448509 Tray(Block2)

Communication Status Error(Out of Connection number)

Please confirm AE-LINK wiring and Power wiring.

EUKYX

3-71199-4100

3.5 Tray Feeder (Block2)

Error ID Error Name, Description, Cause, and Remedy

44850A Tray(Block2)

Communication Status Error(SV-VET Error)

Please confirm AE-LINK wiring and Power wiring.

44850B Tray(Block2)

Failed to read the number of Axes

Please confirm AE-LINK wiring and Power wiring.

44850C Tray(Block2)

Driver-axis is not connected.

Please confirm AE-LINK wiring and Power wiring.

44850D Tray(Block2)

Elevator1-axis is not connected.

Please confirm AE-LINK wiring and Power wiring.

44850E Tray(Block2)

Elevator2-aixs in not connected.

Please confirm AE-LINK wiring and Power wiring.

448510 Tray(Block2)

Motor Breaker Trip Error

-----

448 511 Tray(Block2)

Elevator Unit is not connected.

Please connect Elevator unit in Unit exchange menu.

448512 Tray(Block2)

All connectors of Elevator Unit are not connected.

Please confirm the connection to all connector of Elevator Unit

448513 Tray(Block2)

Failed to start-up Communication of SV-NET.

Please confirm AE-LINK wiring and Power wiring.

448514 Tray(Block2)

Failed to turn on Tray.(Time-out)

-----

448515 Tray(Block2)

(At finishing Auto Run) Tray operation(Block2) is not completed within a specified time.

Please Push Emergency Stop button.

448516 Tray(Block2)

To discriminate the connected tray cart is failed.

Please press READY switch on Feeder Base again. Please contact to the service when to

output the error is continuous.

448517 Tray(Block2)

Timeout in discriminating the tray cart.

Please press READY switch on Feeder Base again. Please contact to the service when to

output the error is continuous.

448601 Tray (Servo Error) (Block2)

Error of Power Driver, Over-current

Please confirm Motor wiring, Exchange Motor and Driver.
