EUKYX

3-75199-4100

3.7 PEC Recognition

Error ID Error Name, Description, Cause, and Remedy

460101 P.E.C. Inspection

P.E.C. Mark #1 (Global)

-----

460102 P.E.C. Inspection

P.E.C. Mark #2 (Global)

-----

460103 P.E.C. Inspection

P.E.C. Mark #3 (Global)

-----

460104 P.E.C. Inspection

P.E.C. Mark #1 (Image)

-----

460105 P.E.C. Inspection

P.E.C. Mark #2 (Image)

-----

460106 P.E.C. Inspection

P.E.C. Mark #3 (Image)

-----

460107 P.E.C. Inspection

P.E.C. Mark #1 (Local)

-----

460108 P.E.C. Inspection

P.E.C. Mark #2 (Local)

-----

460109 P.E.C. Inspection

P.E.C. Mark #3 (Local)

-----

46010a P.E.C. Inspection

Land P.E.C. Mark #1

-----

46010b P.E.C. Inspection

Land P.E.C. Mark #2

-----

46010c P.E.C. Inspection

Land P.E.C. Mark #3

-----

46010d P.E.C. Inspection

Failed in P.E.C. Recognition

Please perform methods to the following

1. Revise PCB positioning.

2. Confirm whether the Mark position of PCB Recognition is correct.

3. Confirm the direction of PCB is correct.

EUKYX

3-76199-4100

3.7 PEC Recognition

Error ID Error Name, Description, Cause, and Remedy

46010e P.E.C. Inspection

Failed in Land recog

Please perform methods to the following.

1. Check Mark on the PCB

2. Revise PCB positioning

46010f P.E.C. Inspection

P.E.C. Mark #1 (Unit)

----

46 0110 P.E.C. Inspection

P.E.C. Mark #2 (Unit)

----

46 0111 P.E.C. Inspection

P.E.C. Mark #3 (Unit)

----

460201 2D bar code Error

Failed in reading 2D bar code

Please perform to the following

1. The condition of PCB Positioning

2. Specify the position of 2D bar code

3. Detect the dirty of 2D bar code

EUKYX

3-77199-4100

3.8 Automatic Adjustment

Error ID Error Name, Description, Cause, and Remedy

490603 Conveyor Width Automatic Adjustment

PCB exists on the L conveyor.

-----

490604 Conveyor Width Automatic Adjustment

PCB exists on the R conveyor.

-----

49 0617 Conveyor Width Automatic Adjustment

Software limit

-----

490690 Conveyor Width Automatic Adjustment

Auto Setup Error(Others).

-----

490701 Nozzle set up

Nozzle Stocker is not set.

Please check whether it is correctly set to the stocker base.

490702 Nozzle set up

Motor Error Detection.

-----

490703 Nozzle set up

Nozzle Stocker Shutter open/close failed.

There is no float going up of a nozzle, or please check whether there is any connection etc.

in opening and closing.

490704 Nozzle set up

The up/down movement of Nozzle Stocker failed.

Please confirm whether Upper/Lower Cylinder has no error.

490705 Nozzle set up

Nozzle placing was not found in the stocker.

Check whether there is any difference in stocker arrangement data and real arrangement.

490707 Nozzle set up

There is no free space for nozzle storing. Please confirm the arrangement data.

Please confirm the Stocker arrangement data.

490708 Nozzle set up

There are neither a free space nor a nozzle for nozzle exchange.

Please set up an insufficient nozzle in Nozzle stocker.

490709 Nozzle set up

Nozzle exchange abnormal data was found.

Please confirm the nozzle arrangement and the Stocker arrangement data.

49070a Nozzle set up

Nozzle stocker position teaching failed.

Please teach the Nozzle stocker position again on the instruction screen.

49070c Nozzle set up

Nozzle level teach error Detection.

Please execute the nozzle level teaching again on the nozzle level teach screen, and

confirm there is no unexpected value.
