EUKYX
3-88199-4100
3.8 Automatic Adjustment
Error ID Error Name, Description, Cause, and Remedy
49 611c Conveyor Width W1 Error
-----
Reserved Function of driver. Please make inquiries when error is detected.
49 611d Conveyor Width W1 Error
-----
Reserved Function of driver. Please make inquiries when error is detected.
49 611e Conveyor Width W1 Error
-----
Reserved Function of driver. Please make inquiries when error is detected.
49 611f Conveyor Width W1 Error
System Error in Conveyor Width W1.
System Error of internal driver. Driver error is supposed if this problem happens frequently.
496120 Conveyor Width W1 Error
Communication Error in Conveyor Width W1.
1. Confirm connection to communication cable.
2. Confirm Power supply(24V).
3. Confirm the communication setting of PCI board.
4. Confirm the address of driver and communication rate setting.
496201 Conveyor Width W2 Error
Drive Alarm during Conveyor Width W2 axial operation.
Confirm reset Method of detailed Sub-system error counts of Alarm.
496202 Conveyor Width W2 Error
Conveyor Width W2-axis could not start
A state in which the operating command is not normally accepted.
1. Confirm connection to communication cable.
2. Confirm Power supply(24V).
3. Confirm the communication setting of PCI board.
4. Confirm the address of driver and communication rate setting.
496210 Conveyor Width W2 Error
System setup of Conveyor Width W2 is not completed.
Driver has not completed the parameter setup yet. It is a situation in which a correct setup
has not been received by Communication Error.
Check the Communication Mode, wiring, Power supply of Driver.
49 6 211 Conveyor Width W2 Error
Zeroing Error in Conveyor Width W2
LS, discontinuous zeroing movement, was detected.
Check out the dirt, error of sensor and error in Motor body etc.
496212 Conveyor Width W2 Error
Out-of-Control in Conveyor Width W2
Motor Out-of-Control which is over the width of Out-of-Control detecting occurred. Please
execute all zeroing again, and the restart production.
Please set motor speed slow if it happens frequently. Also, in a case of structure motor
Error.
EUKYX
3-89199-4100
3.8 Automatic Adjustment
Error ID Error Name, Description, Cause, and Remedy
496213 Conveyor Width W2 Error
Error in Motor Power voltage of Conveyor Width W2
Motor power voltage dropped. Check out the Power supply line(48V Line)
496214 Conveyor Width W2 Error
STP input in Conveyor Width W2 was detected
STP input is detected. The function to stop motor by Hard signal.
496215 Conveyor Width W2 Error
Over-current in Conveyor Width W2
Error in Motor output line. Check out the motor wiring,
496216 Conveyor Width W2 Error
Limit Sensor(+) was detected in Conveyor Width W2.
+LS signal was detected for moving for (+).
Please check the dirt of +LS sensor, disconnection.
49 6217 Conveyor Width W2 Error
Limit Sensor(-) was detected in Conveyor Width W2.
-LS signal was detected for moving for (-).
Please check the dirt of -LS sensor, disconnection.
496218 Conveyor Width W2 Error
Motor Disconnection of Conveyor Width W2 was detected.
Disconnection to motor was detected.(Only stop mode)
Check the motor wiring.
496219 Conveyor Width W2 Error
Control Power Voltage of Conveyor Width W2 has an error
Control power for driver dropped. Check out the Power supply line.(24V Line)
49621a Conveyor Width W2 Error
-----
Reserved Function of driver. Please make inquiries when error is detected.
49621b Conveyor Width W2 Error
-----
Reserved Function of driver. Please make inquiries when error is detected.
49621c Conveyor Width W2 Error
-----
Reserved Function of driver. Please make inquiries when error is detected.
49621d Conveyor Width W2 Error
-----
Reserved Function of driver. Please make inquiries when error is detected.
49621e Conveyor Width W2 Error
-----
Reserved Function of driver. Please make inquiries when error is detected.
49621f Conveyor Width W2 Error
System Error in Conveyor Width W2.
System Error of internal driver. Driver error is supposed if this problem happens frequently.
EUKYX
3-90199-4100
3.8 Automatic Adjustment
Error ID Error Name, Description, Cause, and Remedy
496220 Conveyor Width W2 Error
Communication Error in Conveyor Width W2.
1. Confirm connection to communication cable.
2. Confirm Power supply(24V).
3. Confirm the communication setting of PCI board.
4. Confirm the address of driver and communication rate setting.
496310 Error of Shuttle Conveyor width W1 in Input side
System setup of Conveyor Width W1 is not completed.
Driver has not completed the parameter setup yet. It is a situation in which a correct setup
has not been received by Communication Error.
Check the Communication Mode, wiring, Power supply of Driver.
49 6 311 Error of Shuttle Conveyor width W1 in Input side
Zeroing Error in Conveyor Width W1
LS, discontinuous zeroing movement, was detected.
Check out the dirt, error of sensor and error in Motor body etc.
496312 Error of Shuttle Conveyor width W1 in Input side
Out-of-Control in Conveyor Width W1
Motor Out-of-Control which is over the width of Out-of-Control detecting occurred. Please
execute all zeroing again, and the restart production.
Please set motor speed slow if it happens frequently. Also, in a case of structure motor
Error.
496313 Error of Shuttle Conveyor width W1 in Input side
Error in Motor Power voltage of Conveyor Width W1
Motor power voltage dropped. Check out the Power supply line(48V Line)
496314 Error of Shuttle Conveyor width W1 in Input side
STP input in Conveyor Width W1 was detected
STP input is detected. The function to stop motor by Hard signal.
496315 Error of Shuttle Conveyor width W1 in Input side
Over-current in Conveyor Width W1
Error in Motor output line. Check out the motor wiring,
496316 Error of Shuttle Conveyor width W1 in Input side
Limit Sensor(+) was detected in Conveyor Width W1.
+LS signal was detected for moving for (+).
Please check the dirt of +LS sensor, disconnection.
49 6317 Error of Shuttle Conveyor width W1 in Input side
Limit Sensor(-) was detected in Conveyor Width W1.
-LS signal was detected for moving for (-).
Please check the dirt of -LS sensor, disconnection.
496318 Error of Shuttle Conveyor width W1 in Input side
Motor Disconnection of Conveyor Width W1 was detected.
Disconnection to motor was detected.(Only stop mode)
Check the motor wiring.
496319 Error of Shuttle Conveyor width W1 in Input side
Control Power Voltage of Conveyor Width W1 has error
Control power for driver dropped. Check out the Power supply line.(24V Line)
