EUKYX
3-101199-4100
3.8 Automatic Adjustment
Error ID Error Name, Description, Cause, and Remedy
49710a Before setup P.C.B. detected
PCB was detected on Positioning Conveyor of B Lane(Input position).
Can not execute Conveyor width setup with the state of P.C.B. on Conveyor.
1. Remove P.C.B.
2. Please confirm that P.C.B. is existing in Machine.
49710b Before setup P.C.B. detected
PCB was detected on Positioning Conveyor of B Lane(Output position).
Can not execute Conveyor width setup with the state of P.C.B. on Conveyor.
1. Remove P.C.B.
2. Please confirm that P.C.B. is existing in Machine.
49710c Before setup P.C.B. detected
PCB was detected on Output conveyor of B Lane.
Can not execute Conveyor width setup with the state of P.C.B. on Conveyor.
1. Remove P.C.B.
2. Please confirm that P.C.B. is existing in Machine.
49710d Before setup P.C.B. detected
PCB is detected from Shuttle Conveyor in Input side.
Can not execute Conveyor width setup with the state of P.C.B. on Conveyor.
1. Remove P.C.B.
2. Please confirm that P.C.B. is existing in Machine.
49710e Before setup P.C.B. detected
PCB is detected from Shuttle Conveyor in Output side.
Can not execute Conveyor width setup with the state of P.C.B. on Conveyor.
1. Remove P.C.B.
2. Please confirm that P.C.B. is existing in Machine.
49710f Before setup P.C.B. detected
Stopper descent has not been complete.
1. Please check if stopper is broken.
2. Please check if PCB is caught in stopper.
497110 Before setup P.C.B. detected
PCB was detected on A Lane.
Can not execute Conveyor width setup with the state of P.C.B. on Conveyor.
1. Remove P.C.B.
2. Please confirm that P.C.B. is existing in Machine.
497111 Before setup P.C.B. detected
PCB was detected on B Lane.
Can not execute Conveyor width setup with the state of P.C.B. on Conveyor.
1. Remove P.C.B.
2. Please confirm that P.C.B. is existing in Machine.
497201 Error in Support pin setup
Failed in recognizing Support Pin which will be pick-up.
Open the cover and set all support pins in Stock area. Then, Please edit Stock area.
EUKYX
3-102199-4100
3.8 Automatic Adjustment
Error ID Error Name, Description, Cause, and Remedy
497202 Error in Support pin setup
Illegal support pin exists in the place where support pin will be set.
Open the cover and set all support pins in Stock area.Then, Please edit Stock area.
497203 Error in Support pin setup
Failed in pick-up support pin
There is a possibility that Support pin is falling.
Open the cover and set all support pins in Stock area. Then, edit Stock area.
497204 Error in Support pin setup
Failed in detecting support pin after set it.
There is a possibility that Support pin is falling.
Open the cover and set all support pins in Stock area. Then, edit Stock area.
497205 Error in Support pin setup
Error in detect before operation.
Please check the state of Head.
497206 Error in Support pin setup
Operation Error
There is a possibility that Support pin is falling. Open the cover and set all support pins in
Stock area. Then, edit Stock area.
497210 Error in Support pin setup
There is not enough support pin for arrangement.
Open the cover and set support pins of appropriate number in Stock area. Then, edit Stock
area.
497211 Error in Support pin setup
There is not sufficient space to evacuate surplus support pins.
Please arrange support pins of the number used exactly.
497212 Error in Support pin setup
Failure in exchanging data
-----
EUKYX
3-103199-4100
3.9 Head Relation
3.9 Head Relation
Error ID Error Name, Description, Cause, and Remedy
4a0101 Motor positioning error
Motor positioning error
All origin return, and, please start again.
4a0102 Motor positioning error
Other axis positioning timeout
-----
4a0201 Motor positioning timeout
Motor positioning timeout
-----
4a0301 Motor start condition error
Motor start condition error
-----
4a0401 Motor mode set error
Motor mode set error
-----
4a0501 Motor mode set timeout
Motor mode set timeout
-----
4a0601 Motor start command error
Motor start command error
-----
4a0701 Motor start command timeout
Motor start command timeout
-----
4a2101 Valve Changes error
Valve switching error
-----
4a2201 Air Vacuum Change error
Air vacuum switching error
-----
