EUKYX
3-114199-4100
3.10 Others
Error ID Error Name, Description, Cause, and Remedy
4b3010 Cutter Error
Cutter can not move because Feeder Base in not positioned correctly.
Please connect connector of Feeder base.
4b 3 011 Cutter Error
Failed in reading the number of connection axes.
Please confirm AE-LINK wiring and Power wiring.
4b3012 Cutter Error
Communication status Error
Please confirm AE-LINK wiring and Power wiring.
4b3013 Cutter Error
Communication status Error(Stand by)
Please confirm AE-LINK wiring and Power wiring.
4b3014 Cutter Error
Communication Status Error(Alarm)
Please confirm the wiring of driver in Feeder Base unit
4b3015 Cutter Error
Communication Status Error(OT)
Please confirm the wiring of Origin Sensor.
4b3016 Cutter Error
Communication Status Error(Connection O)
Please confirm AE-LINK wiring and Power wiring.
4b3017 Cutter Error
Communication Status Error(Driver Alarm)
Please confirm the wiring of driver in Feeder Base unit
4b3018 Cutter Error
Communication Status Error(SV-NET stopping)
Please confirm AE-LINK wiring and Power wiring.
4b3019 Cutter Error
Communication Status Error(Out of Connection number)
Please confirm AE-LINK wiring and Power wiring.
4b301a Cutter Error
Communication Status Error(SV-NET Error)
Please confirm AE-LINK wiring and Power wiring.
4b301b Cutter Error
Cutter-axis is not connected.
Please confirm AE-LINK wiring and Power wiring.
4b301c Cutter Error
Failed to start-up Communication of SV-NET
Please confirm AE-LINK wiring and Power wiring.
4b301d Cutter Error
Failed to reset Alarm of Cutter-axis
----
4b301e Cutter Error
It returned to its Origin because Alarm of Cutter-axis was detected during Positioning
Please check Feeder whose Number is close one indicated.
EUKYX
3-115199-4100
3.10 Others
Error ID Error Name, Description, Cause, and Remedy
4b301f Cutter Error
Cannot turn on the servo motor of cutter unit within a specified time.
----
4b3101 Cutter(Servo Error)
Error of Power Driver, Over-current
Check out motor wiring or exchange both motor and driver.
4b3102 Cutter(Servo Error)
Overload Alarm
(1) Confirm whether there is chocked up with cutter pieces.
(2) Please check it because there is a possibility that the fuse in cutter-axis is broken.
(3) Check out motor wiring or replace both motor and driver.
4b3103 Cutter(Servo Error)
Speed Alarm
Need to adjust motor gain again.
4b3104 Cutter(Servo Error)
Multi-rotation Error
Check motor wiring or exchange motor.
4b3105 Cutter(Servo Error)
The value of Deviation Counter was over the set value
Check the wiring of Origin sensor. Either, replace a driver.
Please check it because there is a possibility that the fuse in cutter-axis is broken.
4b3106 Cutter(Servo Error)
Power Drive detected temperature error.
Ambient Temperature is too high. Exchange driver.
4b3107 Cutter(Servo Error)
Sensor Error
Confirm the wiring of Motor Encoder. Either, exchange motor
4b3108 Cutter(Servo Error)
High Drive voltage
Insufficient power capacity. Exchange driver.
4b3109 Cutter(Servo Error)
Low drive voltage
Please confirm the operating Power wiring which is inserted to driver.
4b310a Cutter(Servo Error)
Reading Error on permanent memory
Exchange Driver
4b310b Cutter(Servo Error)
Reading Error on permanent memory
Exchange Driver
4b310c Cutter(Servo Error)
CPU Error
Exchange Driver
4b310d Cutter(Servo Error)
Parameter Error
Please confirm the changed Parameter
EUKYX
3-116199-4100
3.10 Others
Error ID Error Name, Description, Cause, and Remedy
4b310e Cutter(Servo Error)
Alarm code readout failed
-----
4b310f Cutter(Servo Error)
Low driving voltage(Block1)(Feeder Base [ON])
-----
4b 3110 Cutter(Servo Error)
Low driving voltage(Block2)(Feeder Base [ON])
-----
4b 3111 Cutter(Servo Error)
Low driving voltage(Block1)(Feeder Base [OFF])
-----
4b 3112 Cutter(Servo Error)
Low driving voltage(Block2)(Feeder Base [OFF])
-----
4b3201 Servo Motor Error
Error of processing Servo On
-----
4b3202 Servo Motor Error
Time-out of processing Servo On
-----
4b3203 Servo Motor Error
Error of processing Servo Off
-----
4b3204 Servo Motor Error
Time-out of processing Servo Off
-----
4b3205 Servo Motor Error
Time-out of processing Servo On(Block1)
Please restart the machine.
4b3206 Servo Motor Error
Time-out of processing Servo On(Block2)
Please restart the machine.
4b3301 Data Communication Error
failed in data expansion
There is a possibility of following errors
1. Communication Error
2. Data loss
Please contact the service when not repaired even if turns it on again.
4b3401 Nozzle check Error before Pickup(Detected before operating)
It stopped because the remains components on the nozzle or adhering matters on the side
view camera of Light Emitter/Receiver were detected.
The remains Component on a nozzle or flaw and soil on Light Emitter/Receiver of Side view
camera could be considered to adhere. Please clean it up.
