EUKYX
3-118199-4100
3.10 Others
Error ID Error Name, Description, Cause, and Remedy
4b3904 Bad Mark Sensor Adj Error
Failed to recog the Black of Bad Mark.
-----
4b3905 Bad Mark Sensor Adj Error
Condition Error. Please adjust the while of Bad Mark first.
-----
4b3906 Bad Mark Sensor Adj Error
Failed in Level retreat.
-----
4b3907 Bad Mark Sensor Adj Error
Time-out of head moving.
-----
4b3908 Bad Mark Sensor Adj Error
Level retreat starts-up Error
-----
4b3909 Bad Mark Sensor Adj Error
Head moving specification Error
-----
4b390a Bad Mark Sensor Adj Error
Head moving starts Error
-----
4b390b Bad Mark Sensor Adj Error
Parameter Error
-----
4b4001 Damaged cover tape / Cover tape jammed in the storage / Splicing section peeling off
Alarm Code:E0 - (1)Damaged cover tape/ (2)Cover tape jammed in the storage/ (3)Splicing
section peeling off
(1) Confirm whether or not the cover tape is set correctly
(2) Please remove the cover tape from the storage section.
(3) Please check the splicing condition if the work performed correctly in the process.
4b4101 Cover tape peeling off error (Get caught up)
Alarm Code:E1 - Cover tape peeling off error (Get caught up)
(1) Confirm whether or not the cover tape is set correctly.
(2) Confirm whether or not some sticky material has adhered to the suppressor.
(3) Confirm the splicing condition if the work performed correctly in the process.
4b4201 Feeder Alarm
Alarm Code:E2 - Origin Position Checking Error
(Excessively out of the origin during servo ON)
If the error occurs frequently, replace the feeder.
(It may be caused by trouble of the control P.C.B..)
EUKYX
3-119199-4100
3.10 Others
Error ID Error Name, Description, Cause, and Remedy
4b4202 Feeder Alarm
Alarm Code:E4 - Positioning Completion Timeout
(Foreign substances in the sprocket wheel)
Confirm whether or not the tape is being jammed on the path.
Confirm the reel to operate smoothly.
Confirm whether or not some components and dust are being caught in the sprocket.
4b4203 Feeder Alarm
Alarm Code:E6 - Lane Change Timeout Error
If the error occurs frequently, replace the feeder.
(It may be caused by trouble of the control P.C.B..)
4b4204 Feeder Alarm
Alarm Code:E7 - Servo ON Timeout
If the error occurs frequently, replace the feeder.
(It may be caused by trouble of the control P.C.B..)
4b4205 Feeder Alarm
Alarm Code:E5 - Redundant Order Error (A feeding error may occur.)
Confirm whether or not the tape is being jammed on the path.
Confirm the reel to operate smoothly.
Confirm whether or not some components and dust are being caught in the sprocket.
Confirm whether or not some components and dust are being caught in the tape feeding
gear.
4b4301 Feeder Section(Miss-pickup)
A pickup error occurred due to feeder operation problem.
Please check the feeder and the component.
-----
4b4401 Error in confirming connection of Feeder
Error in confirming connection of Feeder
Please check connection of Feeder
4b4501 Feeder Alarm(One side Lane Alarm abnormal stop)
Cannot send Tape because alarm is found in one side Lane of Dual Feeder.
Please execute recovery process, and then operate it again.
4b4601 Feeder error (feeding time-out)
Feeder error (feeding time-out)
-----
4b4701 SV-NET Communication
Internal Error.
Please restart the machine.
4b4801 2D bar code Time-out
Time-out of Sequence
-----
4b4802 2D bar code Time-out
Time-out of Communication
-----
EUKYX
3-120199-4100
3.10 Others
Error ID Error Name, Description, Cause, and Remedy
4b4901 Feeder Feeding Pitch Correction Error
Feeder Feeding Pitch is out of position, but Auto Correction for it failed.
Please do teaching pick-up position.
4b4a01 Recycle Conveyor is taken off.
Do not take off Recycle Conveyor, please.
-----
4b4a02 Recycle Conveyor is taken off.
There is a possibility that Noz bent. Do not take off Recycle Conveyor during Disposal.
Please open the Cover, then confirm whether Noz did not bend.
4b4b01 Cutter Error
(At finishing Auto Run) Cutter operation (Rear) is not completed within a specified time.
Please push Emergency Stop button.
4b4b02 Cutter Error
(At finishing Auto Run) Cutter operation(Front) is not completed within a specified time.
Please push Emergency Stop button.
4b4c01 Flux dispensing Error
Flux dispensing sequence error
-----
4b4c02 Flux dispensing Error
Cannot detect components existence after dispensing flux. Error in flux sensor.
-----
4b4d01 Flux dispensing unit Error
Flux dispensing Unit stopped in emergency.
-----
4b4d02 Flux dispensing unit Error
Flux dispensing Unit is not set.
Please set flux dispensing unit to the determined place.
4b4d03 Flux dispensing unit Error
Motor alarm.
Please detach flux dispensing unit, and confirm whether there is a factor of load or not.
4b4d04 Flux dispensing unit Error
Flux dispensing was not completed within predetermined time.
1. Please confirm rotation with [rotation] button.
2. Please confirm whether the volume of rotary speed is not 0.
3. Please confirm whether Rotation Photosensor is responsive.
4. Please confirm whether timing belt has some problems.
4b4e01 Flux material shortage
No flux on the drum. Please supply Flux.
-----
4b4f01 No cmpnt after flux dispensing(Sensor)
Could not detect cmpnt on nozzle tip. There is a possibility that picked-up cmpnt is fallen on
the drum.
Please detach flux dispensing unit, and then remove components on the drum.
