EUKYX
3-119199-4100
3.10 Others
Error ID Error Name, Description, Cause, and Remedy
4b4202 Feeder Alarm
Alarm Code:E4 - Positioning Completion Timeout
(Foreign substances in the sprocket wheel)
Confirm whether or not the tape is being jammed on the path.
Confirm the reel to operate smoothly.
Confirm whether or not some components and dust are being caught in the sprocket.
4b4203 Feeder Alarm
Alarm Code:E6 - Lane Change Timeout Error
If the error occurs frequently, replace the feeder.
(It may be caused by trouble of the control P.C.B..)
4b4204 Feeder Alarm
Alarm Code:E7 - Servo ON Timeout
If the error occurs frequently, replace the feeder.
(It may be caused by trouble of the control P.C.B..)
4b4205 Feeder Alarm
Alarm Code:E5 - Redundant Order Error (A feeding error may occur.)
Confirm whether or not the tape is being jammed on the path.
Confirm the reel to operate smoothly.
Confirm whether or not some components and dust are being caught in the sprocket.
Confirm whether or not some components and dust are being caught in the tape feeding
gear.
4b4301 Feeder Section(Miss-pickup)
A pickup error occurred due to feeder operation problem.
Please check the feeder and the component.
-----
4b4401 Error in confirming connection of Feeder
Error in confirming connection of Feeder
Please check connection of Feeder
4b4501 Feeder Alarm(One side Lane Alarm abnormal stop)
Cannot send Tape because alarm is found in one side Lane of Dual Feeder.
Please execute recovery process, and then operate it again.
4b4601 Feeder error (feeding time-out)
Feeder error (feeding time-out)
-----
4b4701 SV-NET Communication
Internal Error.
Please restart the machine.
4b4801 2D bar code Time-out
Time-out of Sequence
-----
4b4802 2D bar code Time-out
Time-out of Communication
-----
EUKYX
3-120199-4100
3.10 Others
Error ID Error Name, Description, Cause, and Remedy
4b4901 Feeder Feeding Pitch Correction Error
Feeder Feeding Pitch is out of position, but Auto Correction for it failed.
Please do teaching pick-up position.
4b4a01 Recycle Conveyor is taken off.
Do not take off Recycle Conveyor, please.
-----
4b4a02 Recycle Conveyor is taken off.
There is a possibility that Noz bent. Do not take off Recycle Conveyor during Disposal.
Please open the Cover, then confirm whether Noz did not bend.
4b4b01 Cutter Error
(At finishing Auto Run) Cutter operation (Rear) is not completed within a specified time.
Please push Emergency Stop button.
4b4b02 Cutter Error
(At finishing Auto Run) Cutter operation(Front) is not completed within a specified time.
Please push Emergency Stop button.
4b4c01 Flux dispensing Error
Flux dispensing sequence error
-----
4b4c02 Flux dispensing Error
Cannot detect components existence after dispensing flux. Error in flux sensor.
-----
4b4d01 Flux dispensing unit Error
Flux dispensing Unit stopped in emergency.
-----
4b4d02 Flux dispensing unit Error
Flux dispensing Unit is not set.
Please set flux dispensing unit to the determined place.
4b4d03 Flux dispensing unit Error
Motor alarm.
Please detach flux dispensing unit, and confirm whether there is a factor of load or not.
4b4d04 Flux dispensing unit Error
Flux dispensing was not completed within predetermined time.
1. Please confirm rotation with [rotation] button.
2. Please confirm whether the volume of rotary speed is not 0.
3. Please confirm whether Rotation Photosensor is responsive.
4. Please confirm whether timing belt has some problems.
4b4e01 Flux material shortage
No flux on the drum. Please supply Flux.
-----
4b4f01 No cmpnt after flux dispensing(Sensor)
Could not detect cmpnt on nozzle tip. There is a possibility that picked-up cmpnt is fallen on
the drum.
Please detach flux dispensing unit, and then remove components on the drum.
EUKYX
3-121199-4100
3.10 Others
Error ID Error Name, Description, Cause, and Remedy
4b5001 No cmpnt after flux dispensing(Recog)
Could not detect cmpnt on nozzle tip. There is a possibility that picked-up cmpnt is fallen on
the drum.
Please detach flux dispensing unit, and then remove components on the drum.
4b5101 Recycle conveyor error
It was impossible to detect the Cmpnt passing the passing check sensor.
Please remove all the components on the recycle conveyor.
4b5102 Recycle conveyor error
Cmpnt remains on the recycle conveyor(Block1).
Please restart Auto Opn after removing the remained cmpnt.
4b5103 Recycle conveyor error
Cmpnt remains on the recycle conveyor(Block2).
Please restart Auto Opn after removing the remained cmpnt.
4b5201 Impossible disposal(Disposal box)
It is impossible to send cmpnt to disposal box for discard because it is too large.
Please carry out disposal after inserting the recycle conveyor.
4b5301 Disposal error
Error in the disposal
Please retry to dispose. Please remove the cmpnt in the head and restart up if there is still
an error.
4b5401 Library tape width check
The tape width in library and the feeder are not in agreement.
Please check the library and feeder.
-----
4b5501 Library Feed Pitch check
Library Feed Pitch differs from Feeder. Please check Library and Feeder.
-----
4b5601 Head type error
The set type and the installed type for head1 are different.
Please restart it after matching a set type to the head type.
Please check the DIP switch on installed PCB on the head after shut down.
There is possibility that communication system has error.
4b5602 Head type error
The set type and the installed type for head2 are different.
Please restart it after matching a set type to the head type.
Please check the DIP switch on installed PCB on the head after shut down.
There is possibility that communication system has error.
4b5701 Library cmpnt carriage type error
There are errors of the cmpnt carriage type of the library.
Please check the library, and then do Chng. program.
4b5801 Joint detect
A joint is detected.
Please perform consistency check.
