EUKYX
3-146199-4100
3.13 Auto Teaching
Error ID Error Name, Description, Cause, and Remedy
602903 Teaching PCB height measured Sensor
Time-out of Communication with Recog.
-----
602904 Teaching PCB height measured Sensor
Could not measure Sensor position Offset correctly.
Please retry to adjust PCB height measured Sensor.
602905 Teaching PCB height measured Sensor
Error of measuring PCB height Sensor
-----
602906 Teaching PCB height measured Sensor
Time-out of measuring PCB height Sensor.
-----
602907 Teaching PCB height measured Sensor
The result of PCB height measured Sensor is out of Permission values.
Please retry to adjust PCB height measured Sensor.
602908 Teaching PCB height measured Sensor
Error of processing in Zero Shift of PCB height measured Sensor.
-----
603001 XY Origin teach
Failed to recognize Origin Correction Mark
Modify the teaching position and execute teaching again.
604001 Automatic Teaching on producing operation.
Failed to recognize a nozzle in Head rotation center offset teaching.
-----
604002 Automatic Teaching on producing operation.
Error in recognition command response in Head rotation center offset teaching.
-----
604003 Automatic Teaching on producing operation.
Could not recognize the Standard Mark.
-----
604101 Teaching Placement-Height
Error is detected before starting Detection on the Linear Sensor.(There is a possibility that
the Side view camera is broken , or Odd Noz is placed)
-----
604102 Teaching Placement-Height
Time-out of [OFF] signal of Side view camera
-----
604103 Teaching Placement-Height
Error in DD-axis
-----
604104 Teaching Placement-Height
Error in NS-axis
-----
604105 Teaching Placement-Height
Error in DD/NS-axis
-----
EUKYX
3-147199-4100
3.13 Auto Teaching
Error ID Error Name, Description, Cause, and Remedy
604106 Teaching Placement-Height
Time-out of DD/NS-axis
-----
604107 Teaching Placement-Height
Error in calculating drive wave of HL-axis
-----
604108 Teaching Placement-Height
Error in calculating drive wave of NL-axis
-----
604109 Teaching Placement-Height
Time-out of starting HL/NL-axis movement
-----
60410a Teaching Placement-Height
Time-out of starting HL-axis movement
-----
60410b Teaching Placement-Height
Time-out of starting NL-axis movement
-----
60410c Teaching Placement-Height
Time-out of finishing HL/NL-axis movement
-----
60410d Teaching Placement-Height
Failed in measuring real time of side view camera.
-----
60410e Teaching Placement-Height
ODD Noz is placed on Head, or error is detected during side view camera.
-----
60410f Teaching Placement-Height
Flange of Nozzle is not detected within the predetermine range.(Not E/NR)
Please remeasure the height teach after teaching the head rotation on the angle axis.
60 4110 Teaching Placement-Height
Flange of Nozzle is not detected within the predetermine range.(E/NR)
Please remeasure the height teach after teaching the head rotation on the angle axis.
60 4111 Teaching Placement-Height
The height of Flange of Nozzle is not changed.(Nozzle pressed is not detected.)
-----
60 4112 Teaching Placement-Height
Program Error
-----
60 4113 Teaching Placement-Height
Offset is 1mm less than the set value.
-----
60 4114 Teaching Placement-Height
Offset is 1mm more than the set value.
-----
EUKYX
3-148199-4100
3.13 Auto Teaching
Error ID Error Name, Description, Cause, and Remedy
60 4115 Teaching Placement-Height
The value of Flowmeter is higher than 5.0V.
-----
60 4116 Teaching Placement-Height
The value of Flowmeter is lower than 4.7V.
-----
60 4117 Teaching Placement-Height
There is no measured data of Noz 1. It is necessary to measure Noz1 first.
-----
60 4118 Teaching Placement-Height
Cannot measure it for XY-coord is not defined.
-----
60 4119 Teaching Placement-Height
Error in Flowing Quantity
-----
604201 Chute(For adjustment when shipping up) Teaching Height
Error is detected before starting Detection on Side view camera.(There is a possibility that
Side view camera is broken, or Odd Noz is placed.)
-----
604202 Chute(For adjustment when shipping up) Teaching Height
Time-out of [OFF] signal of Side view camera
-----
604203 Chute(For adjustment when shipping up) Teaching Height
Error in DD-axis
-----
604204 Chute(For adjustment when shipping up) Teaching Height
Error in NS-axis
-----
604205 Chute(For adjustment when shipping up) Teaching Height
Error in DD/NS-axis
-----
604206 Chute(For adjustment when shipping up) Teaching Height
Time-out of DD/NS-axis
-----
604207 Chute(For adjustment when shipping up) Teaching Height
Error in calculating drive wave of HL-axis
-----
604208 Chute(For adjustment when shipping up) Teaching Height
Error in calculating drive wave of NL-axis
-----
604209 Chute(For adjustment when shipping up) Teaching Height
Time-out of starting HL/NL-axis movement
-----
60420a Chute(For adjustment when shipping up) Teaching Height
Time-out of starting HL-axis movement
-----
