EUKYX
3-150199-4100
3.13 Auto Teaching
Error ID Error Name, Description, Cause, and Remedy
604301 Chute(For Head exchange) teaching Height
Error is detected before starting Detection on Side view camera.(There is a possibility that
Side view camera is broken, or Odd Noz is placed.)
-----
604302 Chute(For Head exchange) teaching Height
Time-out of [OFF] signal of Side view camera
-----
604303 Chute(For Head exchange) teaching Height
Error in DD-axis
-----
604304 Chute(For Head exchange) teaching Height
Error in NS-axis
-----
604305 Chute(For Head exchange) teaching Height
Error in DD/NS-axis
-----
604306 Chute(For Head exchange) teaching Height
Time-out of DD/NS-axis
-----
604307 Chute(For Head exchange) teaching Height
Error in calculating drive wave of HL-axis
-----
604308 Chute(For Head exchange) teaching Height
Error in calculating drive wave of NL-axis
-----
604309 Chute(For Head exchange) teaching Height
Time-out of starting HL/NL-axis movement
-----
60430a Chute(For Head exchange) teaching Height
Time-out of starting HL-axis movement
-----
60430b Chute(For Head exchange) teaching Height
Time-out of starting NL-axis movement
-----
60430c Chute(For Head exchange) teaching Height
Time-out of finishing HL/NL-axis movement
-----
60430d Chute(For Head exchange) teaching Height
Failed in measuring real time of side view camera.
-----
60430e Chute(For Head exchange) teaching Height
Error in measuring Side view camera
-----
60430f Chute(For Head exchange) teaching Height
Flange of Nozzle is not detected within the predetermine range.(Not E/NR)
Please remeasure the height teach after teaching the head rotation on the angle axis.
EUKYX
3-151199-4100
3.13 Auto Teaching
Error ID Error Name, Description, Cause, and Remedy
604310 Chute(For Head exchange) teaching Height
Flange of Nozzle is not detected within the predetermine range.(E/NR)
Please remeasure the height teach after teaching the head rotation on the angle axis.
60 4 311 Chute(For Head exchange) teaching Height
The height of Flange of Nozzle is not changed.(Nozzle pressed is not detected.)
-----
604312 Chute(For Head exchange) teaching Height
Program Error
-----
604313 Chute(For Head exchange) teaching Height
Offset is 1mm less than the set value.
-----
604314 Chute(For Head exchange) teaching Height
Offset is 1mm more than the set value.
-----
604315 Chute(For Head exchange) teaching Height
The value of Flowmeter is higher than 5.0V.
-----
604316 Chute(For Head exchange) teaching Height
The value of Flowmeter is lower than 4.7V.
-----
604317 Chute(For Head exchange) teaching Height
There is no measured data of Noz 1. It is necessary to measure Noz1 first.
-----
604318 Chute(For Head exchange) teaching Height
Cannot measure it for XY-coord is not defined.
-----
604319 Chute(For Head exchange) teaching Height
Error in Flowing Quantity
-----
604401 Teaching Height of Stocker Master
Error is detected before starting Detection on Side view camera.(There is a possibility that
Side view camera is broken, or Odd Noz is placed.)
-----
604402 Teaching Height of Stocker Master
Time-out of [OFF] signal of Side view camera
-----
604403 Teaching Height of Stocker Master
Error in DD-axis
-----
604404 Teaching Height of Stocker Master
Error in NS-axis
-----
604405 Teaching Height of Stocker Master
Error in DD/NS-axis
-----
EUKYX
3-152199-4100
3.13 Auto Teaching
Error ID Error Name, Description, Cause, and Remedy
604406 Teaching Height of Stocker Master
Time-out of DD/NS-axis
-----
604407 Teaching Height of Stocker Master
Error in calculating drive wave of HL-axis
-----
604408 Teaching Height of Stocker Master
Error in calculating drive wave of NL-axis
-----
604409 Teaching Height of Stocker Master
Time-out of starting HL/NL-axis movement
-----
60440a Teaching Height of Stocker Master
Time-out of starting HL-axis movement
-----
60440b Teaching Height of Stocker Master
Time-out of starting NL-axis movement
-----
60440c Teaching Height of Stocker Master
Time-out of finishing HL/NL-axis movement
-----
60440d Teaching Height of Stocker Master
Failed in measuring real time of side view camera.
-----
60440e Teaching Height of Stocker Master
Error in measuring Side view camera
-----
60440f Teaching Height of Stocker Master
Flange of Nozzle is not detected within the predetermine range.(Not E/NR)
Please remeasure the height teach after teaching the head rotation on the angle axis.
604410 Teaching Height of Stocker Master
Flange of Nozzle is not detected within the predetermine range.(E/NR)
Please remeasure the height teach after teaching the head rotation on the angle axis.
60 4 411 Teaching Height of Stocker Master
The height of Flange of Nozzle is not changed.(Nozzle pressed is not detected.)
-----
604412 Teaching Height of Stocker Master
Program Error
-----
604413 Teaching Height of Stocker Master
Offset is 1mm less than the set value.
-----
604414 Teaching Height of Stocker Master
Offset is 1mm more than the set value.
-----
