EUKYX
3-157199-4100
3.13 Auto Teaching
Error ID Error Name, Description, Cause, and Remedy
604706 Teaching Height of Traverse Chute
Time-out of DD/NS-axis
-----
604707 Teaching Height of Traverse Chute
Error in calculating drive wave of HL-axis
-----
604708 Teaching Height of Traverse Chute
Error in calculating drive wave of NL-axis
-----
604709 Teaching Height of Traverse Chute
Time-out of starting HL/NL-axis movement
-----
60470a Teaching Height of Traverse Chute
Time-out of starting HL-axis movement
------
60470b Teaching Height of Traverse Chute
Time-out of starting NL-axis movement
------
60470c Teaching Height of Traverse Chute
Time-out of finishing HL/NL-axis movement
------
60470d Teaching Height of Traverse Chute
Failed in measuring real time of side view camera.
------
60470e Teaching Height of Traverse Chute
Error in measuring Side view camera
------
60470f Teaching Height of Traverse Chute
Flange of Nozzle is not detected within the predetermine range.(Not E/NR)
Please remeasure the height teach after teaching the head rotation on the angle axis.
604710 Teaching Height of Traverse Chute
Flange of Nozzle is not detected within the predetermine range.(E/NR)
Please remeasure the height teach after teaching the head rotation on the angle axis.
60 4711 Teaching Height of Traverse Chute
The height of Flange of Nozzle is not changed.(Nozzle pressed is not detected.)
------
604712 Teaching Height of Traverse Chute
Program Error
------
604713 Teaching Height of Traverse Chute
Offset is 1mm less than the set value.
------
604714 Teaching Height of Traverse Chute
Offset is 1mm more than the set value.
------
EUKYX
3-158199-4100
3.13 Auto Teaching
Error ID Error Name, Description, Cause, and Remedy
604715 Teaching Height of Traverse Chute
The value of Flowmeter is higher than 5.0V.
------
604716 Teaching Height of Traverse Chute
The value of Flowmeter is lower than 4.7V.
------
604717 Teaching Height of Traverse Chute
There is no measured data of Noz 1. It is necessary to measure Noz1 first.
------
604718 Teaching Height of Traverse Chute
Cannot measure it for XY-coord is not defined.
------
604719 Teaching Height of Traverse Chute
Error in Flowing Quantity
------
EUKYX
3-159199-4100
3.14 Test
3.14 Test
Error ID Error Name, Description, Cause, and Remedy
610101 Operation error
Operation error has occurred.
-----
