199-4100 Chapt er 5 T roubleshooting on Component Picks and Placement This chapter describes the scope of troubleshooting on component picks and placement. 1. Classication of Failure and the Countermeasures 2. T roubles…
EUKYX
4-14199-4100
3. Recognition Error IDs and Remedial Procedures
Recognition
Error ID
Description of Recognition Error
1b000000 Others.
0c000001 It can't be decoded to a character.
0c000000 Others.
0ce00000 Others.
1c000000 Others.
0d000000 Others.
0d000001 Cannot recognize Support pin existence.
0d100000 Others.
0d100001 Cannot recognize Support pin Jig
0de00000 Others.
1d000000 Others.
0f100001 Vision System Start processing error.(internal data construction)
0f100002 Vision System Start processing error.(internal data construction)
0f100101 Vision System Start processing error.(internal data construction)
0f100102 Vision System Start processing error.(internal data construction)
0f100103 Vision System Start processing error.(internal data construction)
0f100201 Vision System Start processing error.(internal data construction)
0f100301 Vision System Start processing error.(internal data construction)
0f100401 Vision System Start processing error.(internal data construction)
0f100000 Vision System Start processing error.(internal data construction)
0f200001 Vision System Start processing error.(Display)
0f200000 Vision System Start processing error.(Display)
0f300001 Vision System Start processing error.(Light)
0f300002 Vision System Start processing error.(Light)
0f300000 Vision System Start processing error.(Light)
0f400001 Vision System Start processing error.(Acquire)
0f400002 Vision System Start processing error.(Acquire)
0f400003 Vision System Start processing error.(Acquire)
0f400004 Vision System Start processing error.(Acquire)
0f400000 Vision System Start processing error.(Acquire)
0f500001 Vision System Start processing error.(Counter board)
0f500000 Vision System Start processing error.(Counter board)
199-4100
Chapter 5
Troubleshooting on Component Picks and Placement
This chapter describes the scope of troubleshooting on
component picks and placement.
1. Classication of Failure and the Countermeasures
2. Troubleshooting on Pickup Errors
3. Troubleshooting on Placement Errors
EUKYX
EUKYX
5-1199-4100
1. Classification of Failure and the Countermeasures
1. Classification of Failure and the Countermeasures
1.1 Classification of Failure
The machine processes can be classified into Processes A, B, C, D, and E as shown below.
Refer to “4. Surface Mounting Mechanism” in "Chapter 1 (Vol. 1: Guide)" for the outline of
actions.
Process A : The placement head moves to the feeder base and picks up a component.
Process B : The head moves to the area where the component recognition camera is installed
and a component recognition process is taken there.
Process C : The placement angle is corrected while the head is moving to the PCB
positioning section.
Process D : The component is placed on the PCB.
Process E : The component-placed PCB is discharged.
1
2
3
Feeder Base Section
Component Recognition Camera
PCB Positioning Section
Process A
Process B
Process C
Process D
Process E
F4E1
Based on these processes, failures can be divided roughly into the following two types.
Failure before Component Placement :
This type of failure occurs mainly in Processes A, B, and C.
Failure after Component Placement :
This type of failure occurs mainly at Processes D and E.
Reference
