EUKYX 1-9 199-4100 1.3 Items for Periodic Maintenance Device Name Inspection Cleaning, and Lubricating Spot Wor k Maintenance Cycle Daily Week ly Mont hly Ever y 3 Months Ever y 6 Months Ye a r l y 4.6 Cutter Section Cut…

100%1 / 363
EUKYX
1-8199-4100
1.3 Items for Periodic Maintenance
1.3 Items for Periodic Maintenance
The items (inspection, cleaning, lubrication, etc.) that require periodic maintenance are classified
and described based on each individual devices.
Refer to ”2. Maintenance Check List” in "Chapter 1" for the maintenance based on frequency
of use.
The * -marks represent that the items require maintenance only for the first time.
Follow “Required“ maintenance cycle for the subsequent use.
Device Name
Inspection Cleaning,
and Lubricating Spot
Work
Maintenance Cycle
Daily Weekly Monthly
Every
3 Months
Every
6 Months
Yearly
4.1
Air Source
Main Air Pressure Inspection Required
Air Blowing Pressure Inspection Required
Z Clamp Pressure Inspection Required
Drain Cleaning Required
Filter Cleaning Required
4.2
Vacuum System
Vacuum Pressure Inspection Required
Filter Cleaning Required
4.3
Component
Recognition
Camera Section
Component Recognition
Camera
Cleaning Required
Component Storage Box Cleaning Required
Hanenite Cleaning Required
Fiducial Mark Cleaning Required
QFP Glass Plate Jig Cleaning Required
Teaching Plate Cleaning Required
4.4
Feeder Base
Driving Section
Worm Gear Lubrication Required
4.5
Feeder Cart
Section
Groove on Feeder Base Cleaning Required
Upper Surface of Feeder
Base
Cleaning Required
Reel Box Cleaning Required
Scrap Box Cleaning Required
Upper Surface of
Suppressor
Cleaning Required
Reference
Notice
EUKYX
1-9199-4100
1.3 Items for Periodic Maintenance
Device Name
Inspection Cleaning,
and Lubricating Spot
Work
Maintenance Cycle
Daily Weekly Monthly
Every
3 Months
Every
6 Months
Yearly
4.6
Cutter Section
Cutter Box Cleaning Required
Linear Guide Lubrication Required
Flat Ring Change Required
Fluorine Sheet Change Required
Urethane Clamp Change Required
Needle Bearing Lubrication Required
4.7
Head Section
High-Speed
Flexible Head
Nozzle U/D Ball Screw
(NL-Axis)
Cleaning,
Lubrication
Required
Head U/D Ball Screw
(HL-Axis)
Cleaning,
Lubrication
Required
Head U/D Linear Guide
(HL-Axis)
Cleaning,
Lubrication
Required
Diffusion Plate Cleaning Required
Side View Camera (Light
Emitter and Receiver)
Cleaning Required
Nozzle Change Cam Face
(Lower Side)
Cleaning,
Lubrication
Required
Center Spline Lubrication Required
Cam Follower
Cleaning,
Lubrication
Required
Vacuum Filter Change Required
Vacuum Nozzle Cleaning Required
Vacuum Nozzle Inspection Required
Nozzle Filter Change Required
4.7
Multi-
Functional
Head
Ball Screw
(3 locations)
Lubrication Required
Linear Guide
(3 locations)
Lubrication Required
Vacuum Filter Change Required
Pan (3 locations) Cleaning Required
Vacuum Nozzle Cleaning Required
Vacuum Nozzle Inspection Required
EUKYX
1-10199-4100
1.3 Items for Periodic Maintenance
Device Name
Inspection Cleaning,
and Lubricating Spot
Work
Maintenance Cycle
Daily Weekly Monthly
Every
3 Months
Every
6 Months
Yearly
4.8
X/Y Beam
Section
X-Axis Linear Guide Inspection Required
X-Axis Linear Guide
Cleaning,
Lubrication
*
Required
Y-Axis Linear Guide Inspection Required
Y-Axis Linear Guide
Cleaning,
Lubrication
*
Required
X-Axis Cable Side Face
Cleaning,
Lubrication
Required
X-Axis Cable Fixing Places Inspection Required
X-Axis Ball Screw
Cleaning,
Lubrication
*
Required
X-Axis Linear Scale Cleaning Required
Y-Axis Cable Side Face
Cleaning,
Lubrication
Required
Y-Axis Cable Fixing Places Inspection Required
Y-Axis Linear Scale Cleaning Required
4.9
PCB
Positioning
Section
Upper Surface of Backup
Table
Cleaning Required
Ball Screw
Cleaning,
Lubrication
*
Required
Ball Bush
Cleaning,
Lubrication
Required
4.10
Conveyor
Section
Linear Guide
Cleaning,
Lubrication
*
Required
Ball Screw
Cleaning,
Lubrication
*
Required
Support Pin Detection
Sensors
Cleaning, Required
PCB Detection Sensor Cleaning, Required
PCB Detection Sensor Fiber Cleaning Required
4.11
Nozzle Stocker
Section
Nozzle Storage
Section
Cleaning Required
Nozzle Stocker
Sliding Area
Cleaning,
Lubrication
Required
Shutter Flange Pin Sliding
Section
Cleaning,
Lubrication
Required
4.11
Nozzle Stocker
Section
Multi-
functional
stocker
Cam follower
Inspection,
Cleaning
Required
4.12 Control
box
Section
Filter Cleaning Required
4.13 Fan
Ventilating Fan Cleaning Required
