EUKYX 1-13 199-4100 2.3 Monthly Maintenance 2. 3 Monthly Maintenance Gre ase Symb ols N M1 : MO L YN OC GREASE A P 1 Objec t Unit Inspec tion, Cleaning, and Lubricating Spot Wor k Grease Required T ool Check 4.3 Componen…
EUKYX
1-12199-4100
2.2 Weekly Maintenance
2.2 Weekly Maintenance
Object Unit
Inspection, Cleaning,
and Lubricating Spot
Work Grease Required Tool Check
4.1
Air Source
Drain
Cleaning
----- Container
4.3
Component
Recognition Camera
Section
Fiducial Mark
Cleaning
----- Lens Cleaning Cloth
4.5
Feeder Cart Section
Groove on Feeder Base
Cleaning
----- Vacuum Cleaner
4.6
Cutter Section
Cutter Box Inside
Cleaning
----- Vacuum Cleaner
4.7
Head Section
High-Speed Flexible
Head
Vacuum Nozzle
Cleaning
----- Lens Cleaning Cloth,
Air Gun, Rag
4.9
PCB Positioning
Section
Upper Surface of
Feeder Base Cleaning
----- Vacuum Cleaner
4.10
Conveyor Section
Support Pin Detection
Sensors
Cleaning
----- Rag
PCB Detection Sensor,
PCB Detection Sensor
Fiber
Cleaning
----- Rag
EUKYX
1-13199-4100
2.3 Monthly Maintenance
2.3 Monthly Maintenance
Grease Symbols
NM1
: MOLYNOC GREASE AP1
Object Unit
Inspection, Cleaning,
and Lubricating Spot
Work Grease Required Tool Check
4.3
Component
Recognition
Camera Section
Teaching Plate
Cleaning
----- Rag
QFP Glass Plate Jig
Cleaning
----- Lens Cleaning Cloth
4.7
Head Section
High-Speed
Flexible Head
Diffusion Plate
Cleaning
----- Lens Cleaning Cloth
4.11
Nozzle Stocker
Section
Nozzle Stocker for
High-Speed Nozzle
Nozzle Storage Section
Cleaning
----- Vacuum Cleaner
4.11
Nozzle Stocker
Section
Nozzle Stocker for
Multi-Functional
Nozzle
Nozzle Storage Section Cleaning ----- Vacuum Cleaner
Cam Follower
Cleaning,
Lubrication
NM1
EUKYX
1-14199-4100
2.4 Quarterly Maintenance
2.4 Quarterly Maintenance
Grease Symbols
MP1 : DAPHNE GREASE MP NO. 1
DE1 : DAPHNE EPONEX GREASE No. 3
NM1 : MOLYNOC GREASE AP1
Lubrication must be made on the *-marked items after initial month and every 3 months for the
subsequent use.
Object Unit
Inspection, Cleaning,
and Lubricating Spot
Work Grease Required Tool Check
4.1
Air Source
Filter
Cleaning
----- Air Filter Case Jig
4.2
Vacuum System
Filter
Cleaning
-----
4.4
Feeder Base
Driving Section
Worm Gear
Lubrication
NM1
4.6
Feeder Cart
Section (Cutter)
Linear Guide Lubrication MP1
Needle Bearing
Lubrication
MP1
4.7
Head Section
High-speed
Flexible Head
Nozzle U/D Ball Screw
(NL-Axis)
Cleaning,
Lubrication
MP1
Head U/D Ball Screw
(HL-Axis)
Cleaning,
Lubrication
MP1
Head U/D Linear Guide
(HL-Axis)
Cleaning,
Lubrication
MP1
Center Spline
Lubrication
MP1
Cam Follower Cleaning,
Lubrication
MP1
Nozzle Change Cam Face
(Upper Side)
Cleaning,
Lubrication
MP1
Vacuum Filter Change -----
Vacuum Nozzle Inspection -----
4.7
Head Section
Multi-Functional
Head
Ball Screw (3 locations) Lubrication MP1
Linear Guide
(3 locations)
Lubrication
MP1
Vacuum Filter
Change
----- Filter Attachment /
Detachment Jig
Vacuum Nozzle Inspection -----
4.8
X/Y Beam Section
* X-Axis Linear Guide Cleaning,
Lubrication
MP1
* Y-Axis Linear Guide Cleaning,
Lubrication
MP1
X-Axis Ball Screw Cleaning,
Lubrication
DE3
4.9
PCB Positioning
Section
* Ball Screw Cleaning,
Lubrication
MP1
Ball Bush Cleaning,
Inspection
MP1
4.10
Conveyor Section
* Linear Guide Cleaning,
Lubrication
MP1
Ball Screw Cleaning,
Lubrication
MP1
