3. Maintenance Spots
3. Maintenance Spots
3.1 Whole View
Any operations with a cover(s) being removed are included.
After the maintenance work, be sure to attach the cover.
Front View of Machine
Air Source
Vacuum System
Feeder Cart Section
F4A6
(a) Refer to “4. Inspection, Cleaning, and Lubrication Spots” and the subsequent items for
the detailed information on the spots of each section to be maintained and how to
maintain them.
(b) As for the options, refer to each instruction manual of the specially specified devices for
the maintenance.
Notice
Reference
EUKYX
1-17199-4100
3.1 Whole View
(Front Side of Machine)
(Rear Side of Machine)
Nozzle Stocker Section
PCB Positioning Section
Head Section
XY Beam Section
Component Recognition
Camera Section
Cutter Section
Feeder Base Driving Section
F4A7
EUKYX
1-18199-4100
4. Inspection, Cleaning, and Lubrication Spots
4. Inspection, Cleaning, and Lubrication Spots
The following describes the maintenance tasks required for each individual units.
Refer to “2. Maintenance Check List” in this chapter for the maintenance items classified
based on frequency.
4.1 Air Source
4.1.1 Air Blow Pressure Inspection
Cycle : Every Day (Required Time : 1 minute)
Air Blowing Pressure
F4A8
Visually check that the pressure gauge reads the initial setting 0.05 MPa (0.5 kgf/cm
2
).
The pressure is factory-adjusted upon shipment of the machine.
Do not change the pressure unless necessary.
Reference
Procedure
Notice
