25 13 4 26 2 23 14 15 8 24 5 8 21 21 21 21 6 6 1 19 25 13 3 18 26 10 22 15 14 22 15 14 9 7 16 21 21 12 12 22 17 1 1 1 1 23 9 14 15 22 20 1 A-T able 6 4 3 X-axis-Sub Assy Moving-axis KKE-1206 No. Part No. Part Name Q&apos…
2
4
X-axis-I/O Box / Plate A, B
Moving-axis
KKE-1206
19
8
21
21
28
18
22
18
18
2
18
22
23
10
18
17
17
4
14
18
18
18
11
18
18
17
17
6
6
18
1
20
18
13
5
7
3
20
25
26
27
26
27
26
27
26
27
25
24
24
24
24
17
18
18
17
17
19
16
9
16
18
10
A-Table
A-Table
A-Table
A-Table
3
3
28
5
5
5
OLD
OLD
17
15
12
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KKE-M2231-00 FRAME, HEAD SERVO 1
2 KKE-M2235-00 COVER, I/O 1
3
KKE-M2236-01 STAY, DUCT 1 B-Table NG MG70168-2010/8/20
KKE-M2236-50 STAY, DUCT 1 A-Table NG MG70168-2010/8/20
KKE-M2236-00 STAY, DUCT 1
4 KKE-M2237-00 STAY, 3 1
5
KKE-M2238-01 BRACKET R 1 B-Table
KKE-M2238-50 BRACKET R 1 A-Table
6 KKE-M2239-00 PLATE, 1 2
7 KKE-M223A-00 STAY, R HNS. 1
8 KKE-M223B-00 STAY, L HNS. 1
9 KKE-M223C-00 STAY, B HNS. 1
10
KKE-M223H-00 STAY, CAMERA HNS. B 1 B-Table
KKE-M223G-00 STAY, CAMERA HNS. A 1 A-Table
11 KKE-M223M-00 STAY, JOINT 1 B-Table
12 KKE-M223P-00 PLATE, I/O 1
13 KKE-M223R-00 COVER 1
14 KKE-M223S-00 STAY, VAC HNS. 1
15
KKE-M220F-02 CAMERA SELECTOR 2 OK MH30084-2011/3/16
KKE-M220F-01 CAMERA SELECTOR 2 OK MGY0023-2010/12/23
KKE-M220F-00 CAMERA SELECTOR 2
16
90990-01J059 BOLT HEX. SOCKET HEAD 4 OK MHX0024-2011/12/22
90990-01J050 BOLT HEX. SOCKET HEAD 4
17 91312-03006 BOLT HEX. SOCKET HEAD 13
18 91312-04006 BOLT HEX. SOCKET HEAD 23
19 91312-04010 BOLT HEX. SOCKET HEAD 6
20 91312-05014 BOLT HEX. SOCKET HEAD 8
21 91312-05020 BOLT HEX. SOCKET HEAD 4
22 97602-03306 SCREW, PAN HEAD W/W 3
23 98902-03004 SCREW, BINDING HEAD 2 B-Table
24
KKE-M2213-S2 PLATE XB AXIS SET 1 B-Table (Hole position change) NG MH80010-2011/12/28
KKE-M2213-S1 PLATE XB AXIS SET 1 B-Table OK MG20082-2010/2/16
KKE-M2213-S0 PLATE XB AXIS SET 1 B-Table
KKE-M2213-S7 PLATE XA AXIS SET 1 A-Table (Hole position change) NG MH80010-2011/12/28
KKE-M2213-S6 PLATE XA AXIS SET 1 A-Table OK MG20082-2010/2/16
KKE-M2213-S5 PLATE XA AXIS SET 1 A-Table
25 KV7-M2231-00 SPACER R, NUT 4
26 KHN-M22F8-00 WASHER,SWR08 16
27 91312-08025 BOLT HEX. SOCKET HEAD 16
28
KKE-M2238-10 BRACKET L 1 B-Table
KKE-M2238-60 BRACKET L 1 A-Table
25
13
4
26
2
23
14
15
8
24
5
8
21
21
21
21
6
6
1
19
25
13
3
18
26
10
22
15
14
22
15
14
9
7
16
21
21
12
12
22
17
11
11
23
9
14
15
22
20
1
A-Table
6
4
3
X-axis-Sub Assy
Moving-axis
KKE-1206
No. Part No. Part Name Q'ty Remarks
Compati. Revision No.-date
1
KKE-M2211-00 FRAME B, X AXIS 1 B-Table
KKE-M2211-50 FRAME A, X AXIS 1 A-Table
2 KHY-M2240-00 SLEEVE, BRG. 1
3 KKE-M2241-00 HOLDER, MOTOR X 1
4 KHY-M2242-00 HOLDER, BRG. 1
5 KKE-M2271-00 BALL SCREW 1
6 KHY-M2276-S0
X-AXIS GUIDE SET 1
7
KHN-M2221-00 SUPPORT UNIT
1
8
KKE-M2261-A0 HOLDER, HEAD B ASSY. 1 B-Table
KKE-M2262-A0 HOLDER, HEAD A ASSY. 1 A-Table
9 KHY-M224H-00 DAMPER 2
10 KHN-M224D-00 SPACER 1
11 KHN-M2248-00 SPACER 2
12 KHN-M22F4-00 WASHER, SWR04 16
13 KHN-M22F6-00 WASHER, SWR06 8
14 KHN-M224J-00 COLLAR A 4
15 KHN-M224K-00 COLLAR B 4
16 KGS-M2628-00 LOCK NUT 1
17 KG2-M9173-00 LOCK NUT 1
18 KM0-M2220-00 COUPLING, X-AXIS 1
19 KHY-M220D-00 TAPE, X-AXIS 2
20 90990-26J008 BEARING 1
21 91312-04014 BOLT HEX. SOCKET HEAD 44
22 92012-04025 BOLT, BUTTON HEAD 4
23
91312-05014 BOLT HEX. SOCKET HEAD 4 OK MH30121-2011/3/30
91312-05016 BOLT HEX. SOCKET HEAD 4
24 91312-05018 BOLT HEX. SOCKET HEAD 4
25 91312-06025 BOLT HEX. SOCKET HEAD 8
26 92A08-04304 SCREW, SET 2
4
4
Y-axis-Cover / Org Sensor
Moving-axis
KKE-1206
1
2
5
7
7
7
10
3
3
3
3
10
26
26
28
28
27
OLD
OLD
27
30
30
29
29
7
9
9
9
9
7
7
8
5
6
4
5
5
4
6
8
7
7
5
8
8
8
8
31
31
31
31
2
4
6
10
7
5
7
5
1
6
4
5
10
7
7
12
11
32
33
35
34
25
25
25
25
13
14
14
13
11>36
12
19
15
20
16
18
21
20
17
16
21
19
20
15
20
23
25
24
25
23
L
22
23
22
25
32
33
32
34
24
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KKE-M26T4-00 COVER, LINEAR 1 2
2 KKE-M26T4-50 COVER, LINEAR 2 2
3 KKE-M26T5-00 COVER, LINEAR 3 4
4
90K41-001400 LABEL, CAUTION 4 NG MJ30200-2012/4/20
90K41-000720 LABEL, ALERT 4
5
90K41-001320 LABEL, CAUTION 4 NG MJ30200-2012/4/20
90K41-000860 STICKER, CAUTION 8
6
90K41-001570 LABEL, CAUTION 4 NG MJ30200-2012/4/20
90K41-000990 STICKER, CAUTION 4
7
90990-46J010 BOLT, THIN HEAD 16 M5x8 OK MG20118-2010/2/25
90990-46J010 BOLT, THIN HEAD 12
8 90990-46J011 BOLT, THIN HEAD 16 M3x5
9 91380-04005 BOLT HEX. SOCKET HEAD 4
10 91380-05010 BOLT HEX. SOCKET HEAD 12
11
KKE-M2659-00 BRACKET, HANDLE 1 OK MG30129-2010/3/24
KKE-M2659-00 BRACKET, HANDLE 2
12 KH2-M1324-01 GRIP 2
13 91312-05010 BOLT HEX. SOCKET HEAD 4
14 91312-05014 BOLT HEX. SOCKET HEAD 4
15 KKE-M652A-00 SENSOR YAB ORG ASSY 2
16 KKE-M652B-00 SENSOR YAB OT ASSY 2
17 KKE-M2691-00 STAY, SENSOR 1
18 KKE-M2691-50 STAY, SENSOR 1
19 91312-04008 BOLT HEX. SOCKET HEAD 16
20 97602-03306 SCREW, PAN HEAD W/W 8
21 92902-03600 WASHER, PLAIN 4
22 KKE-M2682-00 DOG, ORIGIN 2
23
KKE-M2683-01 DOG, SECOND LIMIT 2 L=18mm OK H013880-2010/2/2
KKE-M2683-00 DOG, SECOND LIMIT 2 L=15mm
24
KKE-M2658-01 STOPPER 2 Long type Bearing NG H017386-2012/11/1
KKE-M2658-00 STOPPER 2
25 91312-05008 BOLT HEX. SOCKET HEAD 48
26
Delete (Spare parts) MG20020-2010/2/8
KKE-M2621-00 COVER,SENSOR 4 MG10100-2010/1/27
27
Delete (Spare parts) MG20020-2010/2/8
KKE-M2622-00 STAY,COVER 4 MG10100-2010/1/27
28
Delete (Spare parts) MG20020-2010/2/8
91312-03006 BOLT HEX. SOCKET HEAD 8 MG10100-2010/1/27
29
Delete (Spare parts) MG20020-2010/2/8
91312-04010 BOLT HEX. SOCKET HEAD 18 MG10100-2010/1/27
30
Delete (Spare parts) MG20020-2010/2/8
92902-04200 WASHER, PLAIN 18 MG10100-2010/1/27
31 KKE-M2623-00 COVER, SCALE 4 NG MG20020-2010/2/8
32
KKE-M2625-01 COVER,Y-AXIS 2-1 1 Long type Bearing NG H017386-2012/11/1
KKE-M2625-00 COVER 2 2 NG MG20020-2010/2/8
33
KKE-M2626-01 COVER,Y-AXIS 3-1 1 Long type Bearing NG H017386-2012/11/1
KKE-M2626-00 COVER 3 1 NG MG20020-2010/2/8
34
KKE-M2626-51 COVER,Y-AXIS 3-2 1 Long type Bearing NG H017386-2012/11/1
KKE-M2626-50 COVER 4 1 NG MG20020-2010/2/8
35 KKE-M2625-50 COVER,Y-AXIS 2-2 1 Long type Bearing NG H017386-2012/11/1
36 KKE-M2659-10 BRACKET, HANDLE 1 OK MG30129-2010/3/24
