4 7 Sub Stopper / Exit Stopper Conveyor Unit KKE-1010 3 4 4 7 5 14 10 10 16 4 4 1 1 12 13 13 12 2 9 8 9 6 EXIT SUB 1 15 (R>L) (R>L) L>R No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date 1 KKE-M…
3
7
Main Stopper
Conveyor Unit (Dual Stage)
KKE-1206
14
1
27
3
5
9
L>R
OLD
28
9
5
4
9
L>R
OLD
12
13
6
8
14
18
1
27
21
16
3
11
21
20
23
5
22
9
10
15
15
21
8
12
24
18
2
28
26
15
15
9
23
5
4
17
19
14
13
22
11
7
21
(R>L)
MAIN-1
(R>L)
MAIN-2-2
MAIN-2-1
25
15
15
18
L>R
L>R
2
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1
KKE-M9161-01 BRKT., CYLINDER 1 NG MJ30157-2012/9/3
KKE-M9161-00 BRKT., CYLINDER 1
2
KKE-M9162-01 BRKT., CYLINDER 2 NG MJ30157-2012/9/3
KKE-M9162-00 BRKT., CYLINDER 2
3
KKE-M9163-01 BRKT., STOPPER 1 NG MJ30157-2012/9/3
KKE-M9163-00 BRKT., STOPPER 1
4
KKE-M9164-01 BRKT., STOPPER 2 NG MJ30157-2012/9/3
KKE-M9164-00 BRKT., STOPPER 2
5
KKE-M9165-02 BRKT., STOPPER 3 OK MK00071-2013/10/30
KKE-M9165-01 BRKT., STOPPER 3 NG MJ30157-2012/9/3
KKE-M9165-00 PLATE, STOPPER 3
6 KKE-M9167-00 PLATE, STOPPER 1
7 KKE-M9168-00 PLATE, STOPPER 2
8
KKE-M9169-01 SHAFT, STOPPER 3 L=11mm NG MJ30157-2012/9/3
KKE-M9169-00 SHAFT, STOPPER 3 L=10mm
9 KKE-M916B-00 GUIDE 3
10 KKE-M653A-00 CYLINDER, MAIN 1 ASSY. 1
11 KHW-M916C-00 SPACER 6
12 KHW-M916G-00 COLLAR, JOINT 3
13 KHW-M916H-00 JOINT, CYL. 3
14 90990-08J027 SCREW, PAN HEAD 6
15 $UEF4BU-M3 JOINT 6
16 90112-2AJ006 BOLT HEX. SOCKET HEAD 2
17 90112-2AJ005 BOLT HEX. SOCKET HEAD 4
18 91312-03006 BOLT HEX. SOCKET HEAD 6
19 91312-04006 BOLT HEX. SOCKET HEAD 4
20 91312-04006 BOLT HEX. SOCKET HEAD 2
21
91312-04010 BOLT HEX. SOCKET HEAD 5 MAIN 1
91312-04010 BOLT HEX. SOCKET HEAD 4 MAIN 2-1, 2-2
22
91312-04010 BOLT HEX. SOCKET HEAD 4 MAIN 2-1, 2-2
OK MG60074-2010/6/17
91312-04012 BOLT HEX. SOCKET HEAD 1 MAIN 1
92012-04010 BOLT, BUTTON HEAD
4
MAIN 2-1, 2-2
92012-04012 BOLT, BUTTON HEAD 1 MAIN 1
23 92902-04600 WASHER, PLAIN 6
24 91312-04012 BOLT HEX. SOCKET HEAD 2
25 KKE-M653B-00 CYLINDER, MAIN 2-1 ASSY. 1 MAIN 2-1
26
KKE-M653C-10 CYLINDER, MAIN 2-2 ASSY. 1 MAIN 2-2 OK MFX0146-2009/12/17
KKE-M653C-00 CYLINDER, MAIN 2-2 ASSY. 1
27
KKE-M9161-11 BRKT., CYLINDER 1 NG MJ30157-2012/9/3
KKE-M9161-10 BRKT., CYLINDER 1
28
KKE-M9162-11 BRKT., CYLINDER 2 NG MJ30157-2012/9/3
KKE-M9162-10 BRKT., CYLINDER 2
4
7
Sub Stopper / Exit Stopper
Conveyor Unit
KKE-1010
3
4
4
7
5
14
10
10
16
4
4
11
12
13
13
12
2
9
8
9
6
EXIT SUB
1
15
(R>L)(R>L)
L>R
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KKE-M9271-00 BRKT., CYLINDER 1
2
KKE-M9281-20 BRKT., CYLINDER 1 OK MF90029-2009/9/7
KKE-M9281-00 BRKT., CYLINDER 1
3 KKE-M653D-00 CYLINDER SUB ST ASSY 1
4 KHW-M9274-A0 SPEED CONTROLLER 4
5 KKE-M9275-00 BRKT., SENSOR 1
6 KHW-M9272-00 STOPPER, EXIT 1
7 KHY-M9273-00 CYLINDER 1
8 KHW-M9282-00 STOPPER, SUB 1
9 KHY-M9284-00 PLATE, STOPPER 2
10 91312-04006 BOLT HEX. SOCKET HEAD 4
11 91312-04006 BOLT HEX. SOCKET HEAD 2
12
91312-05012 BOLT HEX. SOCKET HEAD 4 OK MFX0124-2009/11/30
91312-05010 BOLT HEX. SOCKET HEAD 4
13
91312-05016 BOLT HEX. SOCKET HEAD 4 OK MFX0124-2009/11/30
91312-05012 BOLT HEX. SOCKET HEAD 4
14 92902-04200 WASHER, PLAIN 2
15 KKE-M9271-10 BRKT., CYLINDER 1 L>R
16 KKE-M9275-10 BRKT., SENSOR 1 L>R
5
7
Clamp Board-1
Conveyor Unit
KKE-1206
29
19
15
15
18
13
14
21
21
1
33
5
27
16
4
8
17
31
28
30
7
21
20
20
26
32
32
9
21
20
20
26
9
3
21
21
21
22
21
26
27
10
11
12
14
13
29
19
16
15
15
27
2
4
8
31
28
30
7
17
18
11
1
6
5
21
21
32
32
12
35
20
26
27
26
9
11
11
24
24
23
23
34
12
35
27
25
9
11
11
21
3
25
27
10
11
12
11
(R>L)
Both the conveyors flow same parts.
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KKE-M9262-00 PLATE, BASE S 2
2 KKE-M9268-00 BRKT., CYL. 1
3 KKE-M926C-00 PLATE, BOARD CLAMP 2
4 KKE-M926F-00 COLLAR, FLOATING 2
5 KKE-M926G-00 PLATE 2, LINK 2
6 KKE-M926H-00 PLATE 1 1
7 KHW-M9167-00 BRKT., CYL. 2
8 KHW-M916E-00 BUSH 2
9
KHW-M9261-01 PLATE1, LINK 4 OK MHY0029-2011/12/23
KHW-M9261-00 PLATE1, LINK 4
10 KHW-M9264-B0 LINK B ASSY. 2
11 KHW-M9265-00 SPACER 8
12 KHW-M926A-00 COLLAR 4
13 KHW-M926B-00 COLLAR, JOINT 2
14 KHW-M926E-00 NUT 2
15
KKE-M926S-A0 SPEED CONTROLLER 4 OK MG40107-2010/4/28
KHW-M9285-00 SPEED CONTROLLER 4
16 KHY-M9263-00 CYLINDER 2
17 KHY-M926F-00 JOINT, CYL. BRKT 2
18 KHY-M926H-00 JOINT, CYL. 2
19 KHY-M926M-00 STOPPER, CYLINDER 2
20 KV7-M9266-01 GUIDE 6
21 90169-02JB04 SCREW, BINDING HEAD 24
22 91312-04006 BOLT HEX. SOCKET HEAD 2
23 90563-04J170 SPACER BOLT 2
24 91312-04005 BOLT HEX. SOCKET HEAD 2
25 91312-04010 BOLT HEX. SOCKET HEAD 2
26 91312-04012 BOLT HEX. SOCKET HEAD 10
27 91312-04014 BOLT HEX. SOCKET HEAD 8
28 91312-04016 BOLT HEX. SOCKET HEAD 2
29
91312-04012 BOLT HEX. SOCKET HEAD 2 OK MG60074-2010/6/17
92012-04012 BOLT, BUTTON HEAD 2
30 92902-04200 WASHER, PLAIN 2
31 95302-06600 NUT, HEXAGON 2
32 98902-03005 SCREW, BINDING HEAD 8
33 KKE-M9269-00 BRKT., CYL. 1
34 KKE-M926J-00 PLATE 1 1
35 KHW-M9264-A0 LINK A ASSY. 2
