8 8 Sensor-1 (S.T .D) Conveyor Unit (Single Lane) KKE-1206 5 6 9 9 9 9 10 10 10 10 7 8 8 5 9 9 9 6 Borad Length S.T .D 9 8 7 10 10 10 10 1 8 1 10 10 10 10 4 2 3 2 4 3 10 10 10 10 No. Part No. Part Name Q'ty Remarks …
7
8
Guide / Brkt. Sensor
Conveyor Unit (Single Lane)
KKE-1010
8
19
18
10
14
16
14
14
13
12
5
5
4
9
5
2
5
14
16
7
14
16
7
14
13
6
14
14
13
14
6
4
4
18
4
3
14
16
12
14
11
14
13
11
17
15
1
24
23
24
24
22
24
23
22
19
L>R
20
15
17
21
14
16
7
14
6
14
16
12
14
11
27
25
27
26
3
(R>L)
2
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KKT-M9113-00 BRKT.,STOPPER 1
2
KKT-M9121-00 FRAME,CONVEYOR L 1 L=1250
KKT-M9121-50 FRAME,CONVEYOR L 1 L=1540 EX. Conv. Flow attention
3
KKT-M9121-00 FRAME,CONVEYOR L 1 L=1250
KKT-M9121-60 FRAME,CONVEYOR L 1 L=1540 EX. Conv. Flow attention
4 KKT-M9122-00 PLATE 1B,GUIDE 4
5 KKT-M9123-00 PLATE 2,GUIDE 4
6 KKT-M9124-00 PLATE 2,GUIDE 2 EX. Conveyor
7 KKT-M9125-00 GUIDE 1-1 2 EX. Conveyor
8 KKT-M912A-00 BRKT.,SENSOR 1
9 KKT-M9146-00 GUIDE.HNS. 1
10 KKT-M9147-00 GUIDE.HNS. 1
11 KKE-M9124-00 PLATE 2,GUIDE 2 EX. Conveyor
12 KKE-M9125-00 GUIDE 1-1 2 EX. Conveyor
13 91312-03006 BOLT HEX.SOCKET HEAD 24 M3X6
14 91312-03008 BOLT HEX.SOCKET HEAD 48 M3X8
15 91312-05012 BOLT HEX.SOCKET HEAD 4 M5X12
16 92902-03200 WASHER PLAIN 12
17 92902-04200 WASHER PLAIN 2
18 91312-04008 BOLT HEX.SOCKET HEAD 5 M4X8
19 91312-04010 BOLT HEX.SOCKET HEAD 2 M4X10
20 KKT-M9113-10 BRKT.,STOPPER 1
21 KKT-M912A-10 BRKT.,SENSOR 1
22 KGA-M9113-00 GUIDE 1,END 2
23 KGA-M9114-00 GUIDE 2,END 2
24 91312-04012 BOLT HEX.SOCKET HEAD 5 M4X10
25 KKT-M9149-00 PLATE,AMP R 1
26 KKT-M9149-10 PLATE,AMP L 1
27 91312-06012 BOLT HEX.SOCKET HEAD 4 M6X12
8
8
Sensor-1 (S.T.D)
Conveyor Unit (Single Lane)
KKE-1206
5
6
9
9
9
9
10
10
10
10
7
8
8
5
9
9
9
6
Borad Length S.T.D
9
8
7
10
10
10
10
1
8
1
10
10
10
10
4
2
3
2
4
3
10
10
10
10
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KKT-M652P-00 SENSOR L1 ENT ASSY 1 ENT
2
KKT-M652A-01 SEN,WORK OUT ASSY 1 Fiber & AMP
KKT-M652A-A0 SENSOR AMP ASSY AMP TCN27 R L
3
KKT-M652C-01 SEN.L1 WAIT POS ASSY 1 Fiber & AMP
KKT-M652C-A0 SENSOR AMP ASSY AMP TCN10 R L,TCN13 R L
4
KKT-M652E-01 SEN.POS1 ASSY 1 Fiber & AMP
KKT-M652E-A0 SENSOR AMP ASSY AMP TCN14 R L
5 KKT-M652R-00 SENSOR L1 EXIT ASSY 1 EXIT
6 91312-03008 BOLT HEX.SOCKET HEAD 8 M3X8
7 98502-03004 SCREW PAN HEAD 8 M3X4
8 97602-03310 SCREW,PAN HEAD W/W 4
9 KHW-M9157-00 HOLDER,SENSOR 4
10 KHM-M654C-01 SENSOR,FIBER 2 4
9
8
Sensor-2 (700mm O/P)
Conveyor Unit (Single Lane)
KKE-1206
1
5
5
10
10
10
7
10
10
9
11
11
11
11
11
1
9
7
10
10
10
11
11
11
11
11
8
9
9
3
10
10
8
Borad Length 700mm
11
11
11
11
3
6
4
2
4
6
2
3
11
11
11
11
11
11
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KKT-M652P-00 SENSOR L1 ENT ASSY 1 ENT
2
KKT-M652A-01 SEN.WORK OUT ASSY 1 Fiber & AMP
KKT-M652A-A0 SENSOR AMP ASSY 1 AMP TCN27 R L
3
KKT-M652C-01 SEN.L1 WAIT POS ASSY 1 Fiber & AMP
KKT-M652C-A0 SENSOR AMP ASSY 1 AMP TCN10 R L TCN13 R L
4
KKT-M652E-01 SEN.POS1 ASSY 1 Fiber & AMP
KKT-M652E-A0 SENSOR AMP ASSY 1 AMP TCN14 R L
5 KKT-M652R-00 SENSOR L1 EXIT ASSY 1 EXIT
6
KKT-M652F-01 SEN.POS2 ASSY 1 Fiber & AMP
KKT-M652F-A0 SENSOR AMP ASSY 1 AMP TCN18 R L
7 91312-03008 BOLT HEX.SOCKET HEAD 8 M3X8
8 98502-03004 SCREW PAN HEAD 8 M3X4
9 97602-03310 SCREW,PAN HEAD W/W 4
10 KHW-M9157-00 HOLDER,SENSOR 4
11 KHM-M654C-01 SENSOR,FIBER 2 4
