3
DEK Horizon 8EE
Machine Standard Configuration
Transport System
Specification
Type
Single piece with 3mm round transport belts, front rail fixed
Width Adjustment
Programmable motorized rear rail
Transport Direction
Left to right
Right to left
Left to left
Right to right
Substrate Handling Size (minimum)
50mm (X) x 40.5mm (Y)
Substrate Handling Size (maximum)
510mm (X) x 508.5mm (Y)
Substrate Thickness
0.2mm to 6mm
Substrate Weight (maximum)
1kg
Substrate Warpage
Up to 7mm including substrate thickness
Substrate Fixture
Patented over the top clamps
Substrate Handling Features
Soft rail lift / land
Board clamp regulator
Substrate Underside Clearance
Programmable 3mm to 42mm
Process Parameters
Specification
Print Pressure
0kg to 20kg
Print Speed
2mm/sec to 300mm/sec
Print Gap
0mm to 6mm
Substrate Separation
Speed: 0.1mm/sec to 20mm/sec
Distance: 0mm to 20mm
Print Modes
Print / Print
Print / Flood
Flood / Print
Adhesive
Paste Knead
Programmable: number; period; on demand
Vision
Specification
Vision System
SFF
Fiducial Recognition
Automatic fiducial teach and find incorporating 0.3mm fiducial capture
Fiducials
2 or 3
Fiducial Types
Synthetic fiducial library or unique pattern recognition
Fiducial Size
0.3mm to 3mm*
Fiducial Locations
Anywhere on substrate
Fiducial Error Recovery
Auto lighting adjustment
Auto fiducial search
Camera Lighting
Software controlled programmable LED lighting
*0.1mm to 3mm available via RFQ
4
DEK Horizon 8EE
Machine Standard Configuration
Operating Environment
Specification
Temperature
10° to 35° C (50° to 95° F)
Humidity
30% to 70% relative humidity (non-condensing)
Services
Specification
Voltage
100 Volts to 240 Volts +/- 10%. Single phase 50/60Hz
Maximum Current at 115V
15 Amps with vacuum pump
6 Amps without vacuum pump
Maximum Current at 230V
8 Amps with vacuum pump
3 Amps without vacuum pump
Over Current Protection
An external circuit breaker ≤ 20 Amps is required to be fitted in line with the
machine supply
Air Supply
To ISO 8573.1 Standard Quality Class 2.3.3
Pressure 5 bar to 8 bar
General usage 5 litres/minute at 5 bar to 8 bar
Maximum usage 226 litres/minute at 6 bar
Shipping Information
Specification
Approximate Weight
790kg boxed (dependent upon configured options selected with machine)
630kg unboxed (dependent upon configured options selected with machine)
Approximate Dimensions
2060mm x 1500mm x 1570mm (81.1” x 59” x 61.8”)
Certification
Specification
CE
98/37/EC
89/336/EEC
73/23/EEC
Subsequent amendments
Acoustic Noise Level
Less than 70dB 2003/1/EC
5
DEK Horizon 8EE
Machine Productivity Options
Process
Specification
Print Method
Paste roll height monitor
Stencil Frame
VectorGuard®
Stencil Positioning
Semi automatic loading incorporating squeegee drip tray*
Vacuum Assist for Under Stencil Cleaner
Venturi vacuum unit
* Need to remove drip tray when using ProActiv
Transport
Specification
Substrate Support
Vacuum tooling capability
Vacuum tooling sensor
Vacuum cups
Grid-Lok® Tooling
Substrate Fixture
Foil-less clamps
250mm over the top clamps
Snuggers (edge clamping)
Cycle Time Improvement
10 seconds to 8 seconds
Vision
Specification
HawkEye®750 Functionality
Enabled
Software & Communications
Specification
Statistical Process Control
On board, reported via operator interface (QC-CALC)
Handling & Cleaner Options
Specification
Under Stencil Cleaning
Blue large board cleaner (600mm)
Substrate Handling Size (maximum)
620mm (X) x 508.5mm (Y) – Long Board Option
Data Capture
Specification
Product Data Capture
ProDEK closed loop
Other
Specification
MMI
Left hand side
