Left Side (Gantry 1) Right Side (Gantry 2)
6-Nozzle Collect & Place Head 12-Nozzle Collect & Place Head
Nozzle Changer
Changeover Table with
20 feeder locations for
Tapes, Sticks and Bulk
Reject Bin
Reject Bin
Matrix Tray
Changer
Changeover Table with
9 feeder locations for
Tapes, Sticks and Bulk
Nozzle Changer
3-Section Conveyor with automatic
width adjustment for PCBs from
50 x 50 mm
2
up to 610 x 460 mm
2
( 2" x 2" up to 24.5" x 18" )
PCB Transport
Direction
1.20 m
Possible Machine Configuration
Shunting Radius for
Changeover Table
1.20 m
PCB Transport Direction
