ASM OIS/SIS Databases 14.0 (R16-2) / Interface Description 12/2016 Edition
14
4.5.1 OIS Tables
4.5.1.1 STATETEXT Table
STATETEXT OIS name Data type Byte CI I P
Identification number of the State sState smallint 2
Name of the State strName nvarchar(32) 64
4.5.1.2 FEEDERTYPE Table
FEEDERTYPE OIS name Data type Byte CI I P
SIPLACE Pro number for feeder type
(available with station software version 701
and higher)
lFeederType int 4
SIPLACE Pro name for feeder type strFeederTypeName nvarchar(128) 256
4.5.1.3 BOARD Table
BOARD OIS name Data type Byte CI I P
Identification number of the Station
(Reference to Table STATION)
lId int 4
Date/time at which this event occurred. Station
time
dtTime datetime 8
Manufactured production lot strRecipe nvarchar(128) 256
Name of the setup strSetup nvarchar(128) 256
Name of the PCB strBoard nvarchar(128) 256
Station internal local number of manufactured
PCB
lBoardNumber int 4
Conveyor belt 1 / 2 ucConveyor tinyint 1
Cycle time of PCB sDuration smallint 2
Time when production of lot started dtRecipeStart datetime 8
Time when setup used for manufacture started dtSetupStart datetime 8
PCB barcode strBarcode nvarchar(256) 512
PCB status (see definition below) ucStatus tinyint 1
Time when the data is written. Server Time dtCreated datetime 8
Number of panels within the board lPanel int 4
Conveyor sub-lane lSubConveyor int 4
Board side ucBoardSide tinyint 1
Unique ID for Line Job strLineJobGuid nvarchar(36) 72
Sequence ID (internal use) lIdSequence int 4
ASM OIS/SIS Databases 14.0 (R16-2) / Interface Description 12/2016 Edition
15
Internal ID to mark entries referring to a "Board
Station Composite" object (for internal use
only)
lBoardCompositeId int 4
Internal GUID containing a unique GUID of the
board (for internal use only)
strPCBGuid nvarchar(80) 160
Build time of the board for the first processing
area in milliseconds
Only available for stations with station software
>= 704
lBuildTimePA1 int 4
Build time of the board for the second
processing area in milliseconds
Only available for stations with station software
>= 704
lBuildTimePA2 int 4
Reference to Panel tables entries lIdPanel int 4
Definition of ucStatus
The status of each PCB has been enhanced as of station software versions 605 and 701. As of
these versions, the status is interpreted as a bit array. The enhancement allows backward
compatibility.
1st bit: True = PCB was aborted.
False = PCB was produced.
2nd bit: True = PCB was produced with auto recovery.
False = PCB was produced normally without auto recovery.
3rd bit: -
4th bit: True = PCB is in transport through mode.
False = PCB was produced.
Definition of lSubConveyor
The lSubconveyor entry has been added to distinguish between the right and the left sub-lane if the
placement machine runs in quad lane mode. If the placement machine is not in quad lane mode
this value is always "0".
Possible values of lSubConveyor:
0: No sub-lane
1: Right sub-lane
2: Left sub-lane
Definition of ucBoardSide
The ucBoardSide indicates whether the top or bottom side of the board has been processed.
Possible values of ucBoardSide:
0: Undefined
1: Top side
2: Bottom side
ASM OIS/SIS Databases 14.0 (R16-2) / Interface Description 12/2016 Edition
16
4.5.1.4 EVENT Table
EVENT OIS name Data type Byte CI I P
Identification number of the station
(Reference to Table STATION)
lId int 4
Date/time at which this event occurred. Station time dtTime datetime 8
Serial number of manufactured PCB lBoardNumber int 4
Conveyor belt 1 / 2 ucConveyor tinyint 1
Processing area 1 / 2 ucProcessingArea tinyint 1
Event number sEvent smallint 2
Time when the data is written. Server Time. dtCreated datetime 8
Processing mode ucProcessingMode tinyint 1
Sequence ID (internal use) lIdSequence int 4
Internal ID to mark entries referring to a "Board
Station Composite" object (for internal use only)
lBoardCompositeId int 4
Conveyor sub-lane ucSubConveyor
byte 1
4.5.1.5 USEREVENT Table
USEREVENT OIS name Data type Byte CI I P
Identification number of the Station
(Reference to Table STATION)
lId int 4
Date/time at which this event occurred. Station time dtTime datetime 8
Serial number of manufactured PCB lBoardNumber int 4
Conveyor belt 1 / 2 ucConveyor tinyint 1
Processing area 1 / 2 ucProcessingArea tinyint 1
User event number sEvent smallint 2
Time when the data is written. Server Time dtCreated datetime 8
Processing mode ucProcessingMode tinyint 1
Sequence ID (internal use) lIdSequence int 4
Internal ID to mark entries referring to a "Board
Station Composite" object (for internal use only)
lBoardCompositeId int 4
Conveyor sub-lane ucSubConveyor tinyint 1
