ASM OIS/SIS Databases 14.0 (R16-2) / Interface Description 12/2016 Edition

30475

Z Axis, component at nozzle missing

30476

Z Axis, component at nozzle although no component expected

30477

Z Axis, component too small

30478

Z Axis, component too large

30622

Nozzle missing

30700

Error moving Z axis down

30701

Error moving Z axis up

30744

Component cannot be placed because skinning time has expired

30749

High component is on the nozzle

30750

Nozzle was not properly engaged when picking up nozzle

30780

Component present on nozzle before pickup

30781

Component not present on nozzle after pickup

30782

Component not present on nozzle before placement

30783

Component still present on nozzle after placement

30784

Component not present before dipping

30785

Component not present after dipping

30786

Component not present on nozzle before rejection

30787

Component still present on nozzle after rejection

30788

Component not present on nozzle before recycling

30789

Component still present on nozzle after recycling

30794

Placement aborted. The component has not touched the board

31830

Cannot pick up component

31831

Vision error occurred

31834

Component height measurement failed

31837

Foil torn. Machine was stopped to protect Z axis

33211

Measurement result has bad quality

33214

Cannot measure component. Please change to component teaching gui

33325

Field of view of camera is too small for measurement

33326

One feature is too small for measurement with SIPLACE Vision

33333

3D sensor: Components of this type cannot be measured

33334

3D sensor: Gull wing and ball connections cannot be measured

simultaneously

33335

3D sensor: Too few connections for measurement with the 3D sensor

33338

SIPLACE Vision scaling outside tolerance

33340

Component rotation angle outside tolerance

33341

Measured offset in X and Y outside feed tolerance

33342

Measured offset in X outside feed tolerance

33343

Measured offset in Y outside feed tolerance

33344

Measured lead length outside tolerance

ASM OIS/SIS Databases 14.0 (R16-2) / Interface Description 12/2016 Edition

33345

Measured blob area outside tolerance

33346

Position cannot be determined

33347

Component inspection failed

33348

Size check failed

33350

Flipped component detected

33351

Quality is too low for optical centering

33352

No component in front of the camera or component not bright enough

33354

Measured size outside tolerance

33355

Measured size in X outside tolerance

33356

Measured size in Y outside tolerance

33357

Measured structure size outside tolerance

33358

Position (approximate) cannot be determined

33359

Angle (approximate) cannot be determined

33360

Position (fine) cannot be determined

33361

Not all features of the component were detected

33362

Not all ball features of the component were detected

33363

Features outside positional tolerance

33364

Ball features outside positional tolerance

33365

Nozzle dirty

33366

Nozzle duct blocked

33367

Nozzle worn

33370

Component picked up at wrong angle

33371

Measurement with 3D sensor failed

33372

Measurement with 3D sensor: Not all connections were found

33373

Measurement with 3D sensor: At least one connection is damaged

33374

Measurement with 3D sensor: Coplanarity outside tolerance

33375

Measurement with 3D sensor: Distance between component and sensor too

small

33376

Measurement with 3D sensor: Distance between component and sensor too

great

33377

Measurement with 3D sensor: Component tilted too much

33380

Lead length inspection failed

33381

Measured lead length outside of tolerance

33382

Colinearity check: Lead positions outside of tolerance

33383

Measured lead width outside of tolerance

33387

Coarse position cannot be determined

33398

Glue dot inspection was unsuccessful

33399

Glue dot not within the target region

34403

Placement stopped

ASM OIS/SIS Databases 14.0 (R16-2) / Interface Description 12/2016 Edition

34404

Fatal error on a segment

34428

Cannot create dip job

34429

Component combination is not allowed due to size restrictions

34430

Nozzle combination is not allowed due to size restrictions

34432

Fatal error, maximum number of retries reached

34433

Fatal error, maximum number of retries reached

34439

Component present before pick up

34440

Component not present after pickup

34441

Component too small after pickup

34442

Component too large after pickup

34443

Component cannot be picked up

34450

No component available for placement

34451

Component too small before placement

34452

Component too large before placement

34453

Nozzle not empty after placement

34456

Component cannot be placed

34460

Component cannot be measured

34468

Cannot recycle component

34469

Cannot recycle component

34470

Cannot recycle component

34474

A nozzle change is needed, but not permitted during production. Too

many segments are disabled

34475

Failed to create job for returning nozzle

34476

Failed to create job for picking up nozzle

34477

Failed to create job for centering nozzle

34479

Cannot dip component

34480

Cannot calibrate nozzle changer

34481

Pickup position cannot be reached

34482

Placement position cannot be reached

34483

Dip position cannot be reached

34496

Glue cannot be applied to the component

34499

Component sensor covered before pickup

34602

Cannot address carrier

34603

Cannot address magazine

34810

Cannot pick up component

34902

An error occurred when picking up a component

34903

Division deactivated after component pickup errors

34915

Division not available. Reel has been removed

34920

X feeder: Error on removing foil
