7.2 Equipment Constants
The equipment constants are defined in the table below:
Note: Default values are shown bold.
NAME ECID DESCRIPTION Type Value Range
GemConfigConnect 1 Select establish communications type. U1
1 = S1F13
DeviceName 2 Equipment name as defined by the host. A20 20 characters
GemEstabCommDelay 3 Time between each S1F13 poll. U2
0-60-1800 s
GemPollDelay 4 Time between each S1F1 poll. U2
0-60-1800 s
GemInitCommState 5 Initial communications state. U1 1 = Enable
0 = Disable
GemInitControlState 6 Initial control state. U1
1 = OFF-LINE
2 = ON-LINE
GemOfflineSubstate 7 Set default control sub-state when equipment is
OFF-LINE.
U1
1 = Equipment Off-Line
2 = Attempt On-Line
3 = Host Off-Line
GemOnlineFailed 8 Default sub-state following ON-LINE failure. U1
1 = Equipment Off-Line
2 = Host Off-Line
GemOnlineSubstate 9 Default sub-state when entering ON-LINE state. U1
4 = Local
5 = Remote
received_mode 10 Set System Mode. This constant is volatile and
defaults to Auto on machine power up.
U1
1 = Auto
2 = Single
3 = Pass Through
InspectRate 11 Number of print cycles between board
inspections. 0 indicates no inspection
F8
0 – 100
BatchLimit 12 Number of boards to be printed in a production
batch. O indicates no batch limit
U4
0 - 99999
process_adjustments 13 Enables/disables adjustment of the current
printing process while the machine is running.
U1
0 = Enabled
1 = Operator disabled
2 = Remote command
disabled
3 = Both disabled
MaxSpoolTransmit 14 The maximum number of messages that the
equipment will transmit from the spool in
response to a S6F23”Transmit spooled
Messages” request. If MaxSpoolTransmit is set
to zero, no limit is placed on the messages sent
from the spool. Multi-block inquire/grant
messages are not counted in this total.
U4
Minimum = 0
Maximum = value of
SpoolCountActual
OverWriteSpool 15 Tells the printer to overwrite data in the spool
area or stop spooling whenever the spool area
limits are exceeded.
B1
1 = TRUE to overwrite
spooled data
0 = FALSE to stop
spooling when limits are
exceeded.
spooling_enabled 16 Allows the equipment to default to a condition
where spooling is disabled completely. This is
provided for older Hosts that do not support
S6F23. This EC is set to TRUE = 1 on receipt of
S2F43 defining messages to be spooled.
B1
0 = FALSE spooling
disabled
If the Host sets this EC to
FALSE any data in the
spool will be purged.
Reserved 17-39 Not used by the 265.
TimeFormat 40 The setting of this ECV controls whether the
equipment shall send the Data Items STIME and
TIME in 12-byte or 16-byte format. It also
controls the format of START_TIME. to be 6 or
7 bytes.
B1 0 = 12 byte format
1 = 16 byte format
>1 reserved
GEM Manual for DEK Printers Equipment Variables
Issue 2.0 June 9th, 2011 page 106 of 156
NAME ECID DESCRIPTION Type Value Range
RunGEMRemote 41 Allows control of the Run With GEM Remote
parameter. When enabled, only the host can
start the printer and the operator is given an
appropriate message.
U1
0 = Disable
1 = Enable
Start Modification >>>
MaterialVerif 42 Used to specify whether the material verification
feature is enabled or disabled
U1
0 = Disabled
1 = Enabled
MaterialVerifState 43 Used to drive the material verification state
machine. This is a model shared between the
host and the Printer. It is used to synchronise
verification activity
U1
0 = Disabled
1 = Unread
2 = Reading Tag
3 = Verification Pending
4 = Invalid
5 = Valid
6 = Overridden
7 = Verification Complete
8 = Error
SCValidatedMaterial 44 Used to store the UID of the material last
validated by the host. The host should set this
value prior to attempting to set the material
verification state
A64 Up to 64 character string
RCPOWCode 45 Controls if local products will be overwritten if
a product with the same name is uploaded
B1 0 = False (overwrites are
rejected)
1 = True (overwrites are
allowed)
CompoundProductFiles 46 Controls if the individual files for a process
program will be combined into a single data
transfer.
B1 0 = False (only the PR1
file will be transferred)
1 = True (all files will be
transferred in one block)
Make 50 Printer make. Always returns “DEK” (read-
only)
A20
“DEK”
Model 51 The model of the printer (read-only) A20 For example “Galaxy”
StencilCleaningSystem 53 The currently selected cleaner module (read-
only)
U1
0 = None
1 = Blue
2 = Vortex
3 = Cyclone
ApplicatorType 54 The currently selected applicator module (read-
only)
U1
0 = Squeegees
1 = ProFlow (classic)
2 = Ball Placement
3 = ProFlow Tx
4 = ProFlow ATx
ConveyorType 55 The fitted conveyor type (read-only) U1
0 = Standard
1 = HTC
2 = RTC
TransportMode 56 The current rail transport mode U1
0=LeftToRight
1=RightToLeft
2=RightToRight
3=LeftToLeft
4=NoTransfer/Shuttle
MachineUnits 57 The current machine units U1
0=Metric
1=Imperial
UplineProtocol 58 The current up-line FMI protocol U1 0=NoFMI
1=MIU
2=Manual
DownlineProtocol 59 The current downline FMI protocol U1 0=NoFMI
1=MIU
2=Manual
TransferPeriod 60 FMI transfer period (s) U2
0 – 999, 20
GEM Manual for DEK Printers Equipment Variables
Issue 2.0 June 9th, 2011 page 107 of 156
NAME ECID DESCRIPTION Type Value Range
PasteDispensePosition 61 The position the paste dispenser uses U1 0=Front
1=Rear
2=Auto
ToolingHardware 62 The currently selected tooling type (read-only) U1
0=Magnetic
2=Vacuum
6=FormFlex
7=GridLok
FiducialReference 63 The current fiducial reference U1
0=Left
1=Right
ProductBarcodeHardw
are
64 The status of the product barcode scanner (read-
only)
U1
0=Not Fitted
1=Fitted
RemoteBarcodeHardw
are
65 The status of the remote barcode scanner (read-
only)
U1
0=Not Fitted
1=Fitted
AdvancedProflow
66 Status of the Advanced ProFlow option U1
0=Disabled
1=Enabled
PressureHardware
67 The currently selected pressure hardware (read-
only)
U1
0=NotFitted
1=Fitted
PasteDispenser 68 The status of the automatic paste dispenser
(read-only)
U1
0=NotFitted
1=Fitted
ScreenSize 69 The current screen type selection (read-only) U1
0=256
1=Fuji
2=249
3=Sanyo
4=Library
RollHeightHardware 70 The current selection of the Paste Roll Height
Monitor (PRHM) hardware (read-only)
U1
0=NotFitted
1=Fitted
RHMOnFailureAction
71 The current setting for failure action on the
PRHM
U1
0=Warn
1=Pause
RollHeightMonitor 72 The current status of the PRHM option U1
0=Disabled
1=Enabled
ConsumableAction 73 The current setting for the action to perform
when a consumable is low
U1
0=Warn
1=Pause
2=Suspend
VacuumHoldTime
74 The time the vacuum is applied to the tolling
before the quality of the vacuum seal is checked
(s)
F8
0.0 – 5.0 sec, 0
TwoDiMovementTunin
g
75 The settling time used in 2D Inspection per site
(ms)
U2
CleanerVacuum
76 The current status of the cleaner vacuum option
(read-only)
U1
0=Standard
1=Vacuum
PasteTrails
77 The current status of the paste trails option U1
0=Disabled
1=Enabled
TransportWaitMode 78 The current setting for the transport wait mode U1
0=Standard
1=Hold At Print
ClampType
80 The current selection for the board clamp type
(read-only)
U1
0=Board Clamps
1=Snuggers
2=Foil Less Clamps
3=Over The Top Snuggers
ToolingMonitoring
81 The rate (in boards) that the Tooling Deviation
Monitoring option is used
U2
0 – 200. 0 = disabled
FiducialMonitoring
83 The current selection for the Fiducial
Monitoring option
U1
0=Smart
1=Normal
FiducialSearch
84 The current selection for the Fiducial Search
option
U1
0=Disabled
1=Custom
RemoteBoardStopHard
ware
85 The current selection for the Remote Board Stop
hardware
(read-only)
U1
0=NotFitted
1=Fitted
BoardStopXOffset
86 The current camera board stop X offset (read-
only)
F8
