GEM Manual for DEK Printers Equipment Variables
Issue 2.0 June 9th, 2011 page 106 of 156
NAME ECID DESCRIPTION Type Value Range
RunGEMRemote 41 Allows control of the Run With GEM Remote
parameter. When enabled, only the host can
start the printer and the operator is given an
appropriate message.
U1
0 = Disable
1 = Enable
Start Modification >>>
MaterialVerif 42 Used to specify whether the material verification
feature is enabled or disabled
U1
0 = Disabled
1 = Enabled
MaterialVerifState 43 Used to drive the material verification state
machine. This is a model shared between the
host and the Printer. It is used to synchronise
verification activity
U1
0 = Disabled
1 = Unread
2 = Reading Tag
3 = Verification Pending
4 = Invalid
5 = Valid
6 = Overridden
7 = Verification Complete
8 = Error
SCValidatedMaterial 44 Used to store the UID of the material last
validated by the host. The host should set this
value prior to attempting to set the material
verification state
A64 Up to 64 character string
RCPOWCode 45 Controls if local products will be overwritten if
a product with the same name is uploaded
B1 0 = False (overwrites are
rejected)
1 = True (overwrites are
allowed)
CompoundProductFiles 46 Controls if the individual files for a process
program will be combined into a single data
transfer.
B1 0 = False (only the PR1
file will be transferred)
1 = True (all files will be
transferred in one block)
Make 50 Printer make. Always returns “DEK” (read-
only)
A20
“DEK”
Model 51 The model of the printer (read-only) A20 For example “Galaxy”
StencilCleaningSystem 53 The currently selected cleaner module (read-
only)
U1
0 = None
1 = Blue
2 = Vortex
3 = Cyclone
ApplicatorType 54 The currently selected applicator module (read-
only)
U1
0 = Squeegees
1 = ProFlow (classic)
2 = Ball Placement
3 = ProFlow Tx
4 = ProFlow ATx
ConveyorType 55 The fitted conveyor type (read-only) U1
0 = Standard
1 = HTC
2 = RTC
TransportMode 56 The current rail transport mode U1
0=LeftToRight
1=RightToLeft
2=RightToRight
3=LeftToLeft
4=NoTransfer/Shuttle
MachineUnits 57 The current machine units U1
0=Metric
1=Imperial
UplineProtocol 58 The current up-line FMI protocol U1 0=NoFMI
1=MIU
2=Manual
DownlineProtocol 59 The current downline FMI protocol U1 0=NoFMI
1=MIU
2=Manual
TransferPeriod 60 FMI transfer period (s) U2
0 – 999, 20
GEM Manual for DEK Printers Equipment Variables
Issue 2.0 June 9th, 2011 page 107 of 156
NAME ECID DESCRIPTION Type Value Range
PasteDispensePosition 61 The position the paste dispenser uses U1 0=Front
1=Rear
2=Auto
ToolingHardware 62 The currently selected tooling type (read-only) U1
0=Magnetic
2=Vacuum
6=FormFlex
7=GridLok
FiducialReference 63 The current fiducial reference U1
0=Left
1=Right
ProductBarcodeHardw
are
64 The status of the product barcode scanner (read-
only)
U1
0=Not Fitted
1=Fitted
RemoteBarcodeHardw
are
65 The status of the remote barcode scanner (read-
only)
U1
0=Not Fitted
1=Fitted
AdvancedProflow
66 Status of the Advanced ProFlow option U1
0=Disabled
1=Enabled
PressureHardware
67 The currently selected pressure hardware (read-
only)
U1
0=NotFitted
1=Fitted
PasteDispenser 68 The status of the automatic paste dispenser
(read-only)
U1
0=NotFitted
1=Fitted
ScreenSize 69 The current screen type selection (read-only) U1
0=256
1=Fuji
2=249
3=Sanyo
4=Library
RollHeightHardware 70 The current selection of the Paste Roll Height
Monitor (PRHM) hardware (read-only)
U1
0=NotFitted
1=Fitted
RHMOnFailureAction
71 The current setting for failure action on the
PRHM
U1
0=Warn
1=Pause
RollHeightMonitor 72 The current status of the PRHM option U1
0=Disabled
1=Enabled
ConsumableAction 73 The current setting for the action to perform
when a consumable is low
U1
0=Warn
1=Pause
2=Suspend
VacuumHoldTime
74 The time the vacuum is applied to the tolling
before the quality of the vacuum seal is checked
(s)
F8
0.0 – 5.0 sec, 0
TwoDiMovementTunin
g
75 The settling time used in 2D Inspection per site
(ms)
U2
CleanerVacuum
76 The current status of the cleaner vacuum option
(read-only)
U1
0=Standard
1=Vacuum
PasteTrails
77 The current status of the paste trails option U1
0=Disabled
1=Enabled
TransportWaitMode 78 The current setting for the transport wait mode U1
0=Standard
1=Hold At Print
ClampType
80 The current selection for the board clamp type
(read-only)
U1
0=Board Clamps
1=Snuggers
2=Foil Less Clamps
3=Over The Top Snuggers
ToolingMonitoring
81 The rate (in boards) that the Tooling Deviation
Monitoring option is used
U2
0 – 200. 0 = disabled
FiducialMonitoring
83 The current selection for the Fiducial
Monitoring option
U1
0=Smart
1=Normal
FiducialSearch
84 The current selection for the Fiducial Search
option
U1
0=Disabled
1=Custom
RemoteBoardStopHard
ware
85 The current selection for the Remote Board Stop
hardware
(read-only)
U1
0=NotFitted
1=Fitted
BoardStopXOffset
86 The current camera board stop X offset (read-
only)
F8
GEM Manual for DEK Printers Equipment Variables
Issue 2.0 June 9th, 2011 page 108 of 156
NAME ECID DESCRIPTION Type Value Range
CameraIdlePosition 87 The current selection for the Camera Idle
Position option (read-only)
U1
0=Home
1=Behind Rail
UnloadBoardStart
88 The current selection for the Unload Board Start
option
U1
0=Transport
1=Separation
MaintenanceMonitorin
g
95 The current state of the Maintenance Monitoring
option
U1
0=Disabled
1=Enabled
MachineLocation
96 Free format entry to describe the location of the
machine (read-only)
A20
AutoRailWidth
97 The current selection for the Automatic Rail
Width option (read-only)
U1 0=Disabled
1=Enabled
ProductDirectory
98 The path to the local folder where the product
files are stored (read-only)
A260
DataFileLocation 99 The path to the local folder where data and log
files are stored (read-only)
A260
DownlineBoardStop
101 The current selection of the HTC Downline
Board Stop option
U1
0=Never
1=Always
2=Auto
FrontRToLSpeed
104 The speed of the front rail belt when running
from right to left (read-only)
U2
FrontLToRSpeed
105 The speed of the front rail belt when running
from left to right (read-only)
U2
RearRToLSpeed
106 The speed of the rear rail belt when running
from right to left (read-only)
U2
RearLToRSpeed 107 The speed of the rear rail belt when running
from left to right (read-only)
U2
AltFrontRToLSpeed
108 The alternate speed of the front rail belt when
running from right to left (read-only)
U2
AltFrontLToRSpeed
109 The alternate speed of the front rail belt when
running from left to right (read-only)
U2
AltRearRToLSpeed
110 The alternate speed of the rear rail belt when
running from left to right (read-only)
U2
AltRearLToRSpeed
111 The alternate speed of the rear rail belt when
running from right to left (read-only)
U2
<<< End Modification
