GEM Manual for DEK Printers Equipment Variables
Issue 2.0 June 9th, 2011 page 113 of 156
7.4.1 Limit List
The Limit Set Values are held in a list that is structured as follows:
<Limit List>
:
Structure: L, m ; m = Number of Limit sets
; with SPC output enabled.
1. L, 28 ; First Limit Set
1. Limit Blockage Ave ;Type F4
2. Limit Blockage Max ;Type F4
3. Limit blockage Max Site ID ;Type A20
4. Limit Blockage Min ;Type F4
5. Limit blockage Max Site ID ;Type A20
6. Limit Paste Ave ;Type F4
7. Limit Paste Max ;Type F4
8. Limit paste Max Site ID ;Type A20
9. Limit Paste Min ;Type F4
10. Limit paste Min Site ID ;Type A20
11. Limit Volume Ave ;Type F4
12. Limit Volume Max ;Type F4
13. Limit volume Max Site ID ;Type A20
14. Limit Volume Min ;Type F4
15. Limit volume Min Site ID ;Type A20
16. Limit Print X Ave ;Type F8
17. Limit Print X Max ;Type F8
18. Limit print X Max Site ID ;Type A20
19. Limit Print X Min ;Type F8
20. Limit print X Min Site ID ;Type A20
21. Limit Print Y Ave ;Type F8
22. Limit Print Y Max ;Type F8
23. Limit print Y Max Site ID ;Type A20
24. Limit Print Y Min ;Type F8
25. Limit print Y Min Site ID ;Type A20
26. Limit Smear ;Type F8
27. Limit Bridging ;Type F8
28. Limit ID ;Type A20
.
. ; all elements of the list are identically
m. ; structured
GEM Manual for DEK Printers Equipment Variables
Issue 2.0 June 9th, 2011 page 114 of 156
The items in the list are as follows:
No. Item Limits
Monitor
Description Type Range
1 Limit Blockage Ave Yes Stencil average percentage aperture blockage
for limit set.
F4 0-100 %
2 Limit Blockage Max Yes
Stencil maximum percentage aperture blockage
for limit set.
F4 0-100 %
3 Limit Blockage Max Site ID
No
Site ID that generated the maximum blockage
for limit set.
A20 Up to 20
characters max.
4 Limit Blockage Min Yes Stencil minimum percentage aperture blockage
for limit set.
F4 0-100 %
5 Limit Blockage Max Site ID
No
Site ID that generated the minimum blockage
for limit set.
A20 Up to 20
characters max.
6 Limit Paste Ave Yes Average paste present for limit set. F4 0-100 %
7 Limit Paste Max Yes Maximum paste present for limit set. F4 0-100 %
8 Limit Paste Max Site ID
No
Site ID that generated the maximum paste
present for limit set.
A20 Up to 20
characters max.
9 Limit Paste Min Yes Minimum paste present for limit set. F4 0-100 %
10 Limit Paste Min Site ID
No
Site ID that generated the minimum paste
present for limit set.
A20 Up to 20
characters max.
11 Limit Volume Ave Yes Average paste volume for limit set. F4 0-100 %
12 Limit Volume Max Yes Maximum paste volume for limit set. F4 0-100 %
13 Limit Volume Max Site ID
No
Site ID that generated the maximum volume for
limit set.
A20 Up to 20
characters max.
14 Limit Volume Min Yes Minimum paste volume for limit set. F4 0-100%
15 Limit Volume Min Site ID
No
Site ID that generated the minimum volume for
limit set.
A20 Up to 20
characters max.
16 Limit Print X Ave Yes Average paste-pad X error for limit set. F8
±1 mm
17 Limit Print X Max Yes Maximum paste-pad X error for limit set. F8
±1 mm
18 Limit Print X Max Site ID
No
Site ID that generated the maximum X error for
limit set.
A20 Up to 20
characters max.
19 Limit Print X Min Yes Minimum paste-pad X error for limit set. F8
±1 mm
20 Limit Print X Min Site ID
No
Site ID that generated the minimum X e
rror for
limit set.
A20 Up to 20
characters max.
21 Limit Print Y Ave Yes Average paste-pad Y error for limit set. F8
±1 mm
22 Limit Print Y Max Yes Maximum paste-pad Y error for limit set. F8
±1 mm
23 Limit Print Y Max Site ID
No
Site ID that generated
the maximum Y error for
limit set.
A20 Up to 20
characters max.
24 Limit Print Y Min Yes Minimum paste-pad Y error for limit set. F8
±1 mm
25 Limit Print Y Min Site ID
No
Site ID that generated the minimum Y error for
limit set.
A20 Up o 20
characters max.
26 Limit Smear Yes Stencil paste smear area for limit set. F8
±5 sq. mm
27 Limit Bridging Yes Board pad bridging for limit set. F8
±1 mm
28 Limit ID
No
The limit set name. A20 Up to 20
characters max.
Exception: A zero length list m = 0 indicates that no limit sets are enabled for SPC output.
7.4.2 Modified Parameter List
The Modified Parameter list is structured as follows:
<Modified Parameter List>:
Structure: L, m ; m = Number of Modified Parameter list
1. L,4
GEM Manual for DEK Printers Equipment Variables
Issue 2.0 June 9th, 2011 page 115 of 156
1. Parameter Id ;Type U4
2. Parameter Name ;Type A
3. Parameter’s Old Value ;Type A
4. Parameter’s Modified Value ;Type A
…
m.
List of Parameter Ids and names are listed in Appendix A.
7.4.3 Traceability Data
The traceability data is a list of items structured as follows:
Structure: L, m ; m = number of trace items
1. L,3
1. Item name ; Type A
2. Item value ; Type A
3. Item units ; Type A
Possible items are as follows:
Category Item Name Description and Comments
DateTime The date and time the record was created as the
product leaves the machine and the entry is
constructed before being written to the data file.
Product ID The product serial number or identifier. This is
normally the products’ barcode value.
State A string representing the overall state of the
product as it leaves the machine. This provides a
good board/bad board state.
Values “Pass” or “Fail”
State Detail A string that contains the detail of the state
reasoning. For example if the board were rejected
due to a failed inspection operation, it would
contain a message reflecting this.
Product Name The name of the product as defined within the
printer control software.
Batch ID The batch or lot ID associated with the products
being printed.
Machine Serial No. The identifier that uniquely represents the printer
machine.
Machine ID The identifier that represents the printer machine
type
Operator ID The identifier that represents the operator
currently logged into the printer control software.
Line ID An identifier that represents the line the printer
belongs to.
User Defined Field 1
User Defined Field 2
User Defined Field 3
User Defined Field 4
Fixed
User Defined Field 5
Any user-defined fields that are associated with
traceability, disabled user-defined fields are not
included. The title will be the index of the defined
field.
