GEM Manual for DEK Printers Equipment Variables

Issue 2.0 June 9th, 2011 page 116 of 156

Category Item Name Description and Comments

Front Pressure The front squeegee / Proflow process defined

pressure value (not actual – SPC Data contains

actual)

Rear Pressure The rear squeegee process defined pressure value

(not actual – SPC data contains actual).

Front Print Speed The process defined front print speed (i.e. the rate

the front squeegee moves when performing the

print stroke). The SPC data contains the actual

value.

Rear Print Speed The process defined rear print speed (i.e. the rate

the rear squeegee moves when performing the

print stroke). The SPC data contains the actual

value.

Print Front Limit The maximum limit the front print stroke can be

started from

Print Rear Limit The maximum limit the rear print stroke can be

started from

Forward X Offset The offset applied in X to the screen when

performing the forward print stroke

Reverse X Offset The offset applied in X to the screen when

performing the rear print stroke

Forward Y Offset The offset in Y applied to the screen during the

front print stroke

Reverse Y Offset The offset in Y applied to the screen during the

rear print stroke

Reverse Theta Offset The angle at which the screen is positioned for the

reverse print stroke

Forward Theta Offset The angle at which the screen is positioned for the

forward print stroke

Separation Speed The rate at which the board is separated from the

screen/stencil.

Separation Distance The distance the separation speed applies to

before separating normally.

Print Gap The gap left between the board and stencil/screen

when printing.

Clean Rate 1 / Cyclone Clean Rate /

Blue Clean Rate

The number of print cycles that the clean 1,

cyclone or blue cleaner operation occurs.

Clean Rate 2 The number of print cycles that the clean 2

operation occurs.

Vortex Clean Rate The number of print cycles that the Vortex clean

operation occurs.

Paste While Clean Indicates if a dispense operation is performed

when a clean operation occurs.

Paste Dispense Rate The number of prints that occur before the paste

dispenser performs a dispense operation.

Alternative Dispense Rate The number of prints that occur before the

alternative dispense operation is performed.

Proflow System Pressure The pressure that was applied to the Proflow unit

when printing

Ball Place App Speed The rate at which the ball placement applicator

moves

Ball Place App Dist The distance the ball placement applicator moves

Ball Place Tbl Dwn Speed The rate at which the table moves down when

using ball placement

Process Parameters

Ball Place Hopper Pressure The pressure applied to the ball placement hopper

X Pre Align Dev Deviation in the x axis for the pre print alignment

Y Pre Align Dev Deviation in the y axis for the pre print alignment

SPC

Theta Pre Align Dev Deviation in the theta angle for the pre print

alignment

GEM Manual for DEK Printers Equipment Variables

Issue 2.0 June 9th, 2011 page 117 of 156

Category Item Name Description and Comments

Board Stretch The board length.

Pre Board Stretch Deviation in the pre print board length stretch

Pre Fid 1 X Align Dev Pre fiducial 1 deviation in the x alignment

Pre Fid 1 Y Align Dev Pre fiducial 1 deviation in the y alignment

Pre Fid 2 X Align Dev Pre fiducial 2 deviation in the x alignment

Pre Fid 2 Y Align Dev Pre fiducial 2 deviation in the y alignment

Pre Fid 3 X Align Dev Pre fiducial 3 deviation in the x alignment

Pre Fid 3 Y Align Dev Pre fiducial 3 deviation in the y alignment

X Align Dev Deviation in the X axis alignment

Y Align Dev Deviation in the Y axis alignment

Theta Align Dev Deviation in the theta alignment

Board 1 Fid Score The score of the first defined fiducial on the

board.

Screen 1 Fid Score The score of the first defined fiducial on the

screen.

Board 2 Fid Score The score of the second defined fiducial on the

board.

Screen 2 Fid Score The score of the second defined fiducial on the

screen.

Board 3 Fid Score The score of the third defined fiducial on the

board.

Screen 3 Fid Score The score of the third defined fiducial on the

screen.

Front X Act Rel Move Front X actuator relative movement

Rear X Act Rel Move Rear X actuator relative movement

Act Y Rel Move Y Actuator relative movement

Actual Front Pressure The measured front squeegee / Proflow pressure.

Actual Rear Pressure The measured rear squeegee pressure.

Actual Separation Speed The measured separation speed when performing

the print operation.

Actual Temperature The measured internal temperature

Actual Humidity The measured relative humidity

Cycle Time The number of seconds taken to perform the print

operation.

Table Position The height of the table when at print position.

Post Fid 1 X Align Dev Post fiducial 1 deviation in the x alignment

Post Fid 1 Y Align Dev Post fiducial 1 deviation in the x alignment

Post Fid 2 X Align Dev Post fiducial 2 deviation in the x alignment

Post Fid 2 Y Align Dev Post fiducial 2 deviation in the y alignment

Post Fid 3 X Align Dev Post fiducial 3 deviation in the x alignment

Post Fid 3 Y Align Dev Post fiducial 3 deviation in the y alignment

Front X Act Pos Front X actuator absolute position

Rear X Act Pos Rear X actuator absolute position

Act Y Pos Y actuator absolute position

Actual Front Print Speed The measured print speed variation for the front

squeegee.

Actual Rear Print Speed The measured print speed variation for the rear

squeegee.

Hawkeye Area Error The number of Hawkeye sites in error

Hawkeye Area Warning The number of Hawkeye sites in warning

Hawkeye Feat Error The number of Hawkeye features in error

Hawkeye Feat Warning The number of Hawkeye features in warning

Product Index The name of the verification index that passed the

product identifier validation

Screen ID The value of the identifier (barcode) that is

currently being used for the stencil or screen.

Verification Data

Stencil Screen Index The name of the verification index that passed the

screen or stencil identifier validation

GEM Manual for DEK Printers Equipment Variables

Issue 2.0 June 9th, 2011 page 118 of 156

Category Item Name Description and Comments

Print Medium ID The value of the identifier (barcode) that is

currently being used for the print medium (manual

paste etc..)

Print Medium Index The name of the verification index that passed the

Print Medium identifier validation

Print Medium Cartridge ID The value of the identifier (barcode) that is

currently being used for the print medium

cartridge (paste dispenser etc..)

Print Medium Cartridge Index The name of the verification index that passed the

Print Medium Cartridge identifier validation

Tooling ID The value of the identifier (barcode) that is

currently being used for the tooling (magnetic,

custom etc..)

Tooling Index The name of the verification index that passed the

Tooling identifier validation

Vortex Cassette ID The value of the identifier (barcode) that is

currently being used for the vortex cleaner

cassette.

Vortex Cassette Index The name of the verification index that passed the

Vortex Cassette identifier validation

Cleaner Solvent ID The value of the identifier (barcode) that is

currently being used for the cleaner solvent.

Cleaner Solvent Index The name of the verification index that passed the

Cleaner Solvent identifier validation

Cleaner Paper ID The value of the identifier (barcode) that is

currently being used for the cleaner paper.

Cleaner Paper Index The name of the verification index that passed the

Cleaner Paper identifier validation

Front Squeegee Holders ID The value of the identifier (barcode) that is

currently being used for the front squeegee

holders.

Front Squeegee Holders Index The name of the verification index that passed the

Front Squeegee Holders identifier validation

Rear Squeegee Holders ID The value of the identifier (barcode) that is

currently being used for the rear squeegee holders.

Rear Squeegee Holders Index The name of the verification index that passed the

Rear Squeegee Holders identifier validation

Front Squeegee Blades ID The value of the identifier (barcode) that is

currently being used for the front squeegee blades.

Front Squeegee Blades Index The name of the verification index that passed the

Front Squeegee Blades identifier validation

Rear Squeegee Blades ID The value of the identifier (barcode) that is

currently being used for the rear squeegee blades.

Rear Squeegee Blades Index The name of the verification index that passed the

Rear Squeegee Blades identifier validation

Proflow Cassette ID The value of the identifier (barcode) that is

currently being used for the Proflow cassette.

Proflow Cassette Index The name of the verification index that passed the

Proflow Cassette identifier validation

Proflow Head ID The value of the identifier (barcode) that is

currently being used for the Proflow head unit.

Proflow Head Index The name of the verification index that passed the

Proflow Head identifier validation
