GEM Manual for DEK Printers Machine GEM Compliance
Issue 2.0 June 9th, 2011 page 11 of 156
GEM Requirement
I G
Acknowledge Terminal Message Event
Acknowledge terminal message (CEID 31441)
Alarm Events
Cover opened (CEID 31253)
Cover closed (CEID 31254)
Head left partly open (CEID 31314)
Head moved to safe state (CEID 31315)
Spooling Events
Spooling activated (CEID 31453)
Spooling deactivated (CEID 31454)
Spool transmission failure (CEID 31455)
Equipment Error Events
System power down (CEID 10003)
Pneumatic power down (CEID 31201)
Front squeegee error (CEID 31202)
Rear squeegee error (CEID 31203)
Rising table error (CEID 31204)
Print carriage error (CEID 31205)
Paste carriage error (CEID 31206)
Camera X axis error (CEID 31207)
Camera Y axis error (CEID 31208)
Rail width error (CEID 31209)
Screen XF error (CEID 31210)
Screen XR error (CEID 31211)
Screen Y error (CEID 31212)
Paste cartridge tilt error (CEID 31213)
Screen changer drive error (CEID 31214)
Board stop stuck (CEID 31215)
Board clamp stuck (CEID 31216)
Board stuck in rails (CEID 31217)
Unable to find fiducial (CEID 31218)
Rail lifted error (CEID 31219)
Print pressure error (CEID 31220)
File error (CEID 31221)
Unable to recover (CEID 31222)
Recovery started (CEID 31223)
Recovered (CEID 31224)
Upline transfer error (CEID 31225)
Downline transfer error (CEID 31226)
Dual shuttle fault (CEID 31227)
Screen changer fault (CEID 31230)
Lid bolt fault (CEID 31232)
Alignment out of range (CEID 31233)
Comms error (CEID 31417)
Barcode read failure (CEID 31303)
Barcode mismatch (CEID 31304)
GEM Manual for DEK Printers Machine GEM Compliance
Issue 2.0 June 9th, 2011 page 12 of 156
GEM Requirement
I G
Screen couplings failed (CEID 31305)
Motion control timeout (CEID 31306)
Camera X failed to position (CEID 31307)
Camera Y failed to position (CEID 31308)
Stencil aperture blocked (CEID 31309)
Stencil smeared (CEID 31310)
Paste on pad inspection error (CEID 31311)
Bridging detected by inspection system (CEID 31312)
Alignment error detected by inspection system (CEID 31313)
Event log disk file full (CEID 31321)
Proflow error (CEID 31322)
CAN node down (CEID 31340)
CAN node recovered (CEID 31341)
CAN bus down (CEID 31342)
CAN bus recovered (CEID 31433)
Volume alarm (CEID 31460)
Dongle error (CEID 40006)
Cleaner detached from camera (CEID 40146)
Recovered cleaner detached from camera (CEID 40147)
Ball escape detected (CEID 40150)
Verification item failed (CEID 40152)
Product ID verification failed (CEID 40157)
Start Modification >>>
Material RFID Tag Read Failed (CEID 40200)
RFID Node Error (CEID 40208)
Cleaner Vacuum Sense Error (CEID 40320)
<<< End Modification
Equipment Specific Information Events
System power on (CEID 10002)
Line power on (CEID 31251)
Line power off (CEID 31252)
Printer ready (CEID 31255)
Head raised (CEID 31256)
Head closed (CEID 31257)
Cycle aborted (CEID 31260)
Cycle completed (CEID 31261)
Cleaning screen (CEID 31262)
Parameter adjusted (CEID 31263)
Setup started (CEID 31264)
Setup ended (CEID 31272)
Start print cycle (CEID 31273)
End print cycle (CEID 31275)
Board printed (CEID 31277)
Operator log on (CEID 31278)
Operator log off (CEID 31279)
Clear batch count (CEID 31280)
Start maintenance (CEID 31281)
End maintenance (CEID 31282)
GEM Manual for DEK Printers Machine GEM Compliance
Issue 2.0 June 9th, 2011 page 13 of 156
GEM Requirement
I G
Pressure re-calibrated (CEID 31283)
Offset recalibrated (CEID 31284)
X,Y scale recalibrated (CEID 31285)
Theta recalibrated (CEID 31286)
Configuration change (CEID 31287)
Start diagnostics (CEID 31288)
End diagnostics (CEID 31289)
Camera reference reset (CEID 31291)
Vision height reset (CEID 31293)
Print height reset (CEID 31294)
Software updated (CEID 31296)
New event log (CEID 31297)
No cleaner paper (CEID 31301)
No cleaner solvent (CEID 31302)
Inspection cycle complete (CEID 31316)
Clock change request (CEID 31317)
Clock changed (CEID 31318)
User has enabled the Autoflex tooling (CEID 31330)
User has disabled the Autoflex tooling (CEID 31331)
System has enabled Autoflex tooling (CEID 31332)
System has disabled Autoflex tooling (CEID 31333)
Tooling data changed (CEID 31334)
Remote barcode received (CEID 31457)
options.enb file attribute error (CEID 31459)
Evaluation dongle detected (CEID 40004)
Valid dongle detected (CEID 40005)
Dongle changed (CEID 40007)
Front print speed (CEID 40008)
Rear print speed (CEID 40009)
Configuration Parameter modified (CEID 31345)
Adjust Parameter modified (CEID 31347)
Fiducial setup entered (CEID 40126)
Fiducial setup ended (CEID 40127)
Diagnostics ended (CEID 40128)
Adjust entered (CEID 40129)
Adjust ended (CEID 40130)
Adjust while running entered (CEID 40131)
Adjust while running ended (CEID 40132)
Item verification succeeded (CEID 40151)
Verification value reset (CEID 40153)
Verification value restored (CEID 40154)
Batch/lot ID changed (CEID 40155)
Product ID verification succeeded (CEID 40156)
Traceability data available (CEID 40177)
Start Modification >>>
Current Material UID Changed (CEID 40201)
Tag Read Succeeded - Material Identity (CEID 40202)
Tag Read Failed - Material Identity (CEID 40203)
Material Verification State Changed (CEID 40204)
Material Verification Succeeded (CEID 40205)
