GEM Manual for DEK Printers Event Messages
Issue 2.0 June 9th, 2011 page 132 of 156
EVENT - CEID
DESCRIPTION
40009 Rear print speed.
40020 Maintenance monitoring initialised
40021 Monthly service due
40022 Six monthly service due
40023 Yearly service due
40029 Paste roll height monitoring abandoned
40030 Insufficient paste roll height
40031 Insufficient print medium dispensed
40042 Vortex cassette expired
40055 ProFlow cassette low
40057 Fast print speed selected
40058 Normal print speed selected
40060 Board unstarved
40061 Board unblocked
40062 Board starved
40063 Board blocked
40064 Clean started
40065 Clean complete
40066 2D Inspection started
40067 2D Inspection complete
40068 Paste dispense started
40069 Paste dispense complete
40070 Paper level low
40073 Event log nearly full
40078 Password attempt succeeded
40079 Password attempt failed
40126 Fiducial setup entered
40127 Fiducial setup ended
40128 Diagnostics ended
40129 Adjust entered
40130 Adjust ended
40131 Adjust while running entered
40132 Adjust while running ended
40151 Verification succeeded (see DVID 2034)
40153 Verification value reset (see DVID 2034)
40154 Verification value restored (see DVID 2034)
40155 Batch/lot ID changed
40156 Product ID verification succeeded
40177 Traceability Data Available
Start Modification >>>
40201 Current Material UID Changed
40202 Tag Read Succeeded - Material Identity
40203 Tag Read Failed - Material Identity
40204 Material Verification State Changed
40205 Material Verification Succeeded
40206 Material Verification Invalid
40207 Material Verification Overridden
GEM Manual for DEK Printers Event Messages
Issue 2.0 June 9th, 2011 page 133 of 156
EVENT - CEID
DESCRIPTION
<<< End Modification
9.10 Specific Material Movement Events
EVENT - CEID
DESCRIPTION
31258 Paste dispensing.
31259 Paste cartridge empty.
31268 Screen unloaded.
31269 Screen loaded.
31270 Tool change started.
31271 Tool change completed.
31274 Board received.
31276 Printed board ready.
31319 Board delivered / removed.
40024 Vortex cassette replaced.
40071 Paper roll replaced
9.11 Host Specific Information Events
EVENT - CEID
DESCRIPTION
31400 Process program directory request.
31401 Process program request.
31402 Erase process program request.
31403 Rename process program request.
31404 Load process program request.
31405 Download process program request.
31406 Upload process program request.
31407 Download configuration request.
31408 Upload configuration request.
31409 Upload management data request.
31410 Clear management batch data request.
31411 Clear management session data request.
31412 Upload event log.
31413 Clear event log request.
31414 Comms - Start request.
31415 Comms - Stop request.
31416 Update mode request
31417 Communication error.
31418 Parameter information uploaded.
31419 Parameter information downloaded.
31420 Upload parameter.
31421 Comms - Status request.
31422 Comms - Rebuild process program list.
31423 Paste dispense rate adjusted.
31424 Print speed adjusted.
31425 Front squeegee pressure adjusted.
31426 Rear squeegee pressure adjusted.
GEM Manual for DEK Printers Event Messages
Issue 2.0 June 9th, 2011 page 134 of 156
EVENT - CEID
DESCRIPTION
31427 Print gap adjusted.
31428 Separation speed adjusted.
31429 Cleaning rate adjusted.
31430 X forward offset adjusted.
31431 Y forward offset adjusted.
31432 Theta forward offset adjusted.
31433 X reverse offset adjusted.
31434 Y reverse offset adjusted.
31435 Theta reverse offset adjusted.
31436 Paste dispensed after host command.
31437 Screen cleaned after host command.
31438 Comms enabled.
31439 Comms disabled.
31442 Paste kneaded after host command.
31443 Paste conditioned after host command.
31458 Proflow pressure adjusted.
40010 Comms - Adjust front print speed.
40011 Comms - Adjust rear print speed.
40041 Request to start
Start Modification >>>
40325 Host Command Start Failed
40326 Host Command Stop Failed
40327 Host Command Pause Failed
40328 Host Command Erase Log Failed
40329 Host Command Erase Batch Failed
40330 Host Command Erase Session Failed
40331 Host Command Rename Product Failed
40332 Host Command Adjust Product Failed
40333 Host Command Clean 1 Failed
40334 Host Command Clean 2 Failed
40335 Host Command Paste Failed
40336 Host Command PP-Select Failed
40337 Host Command Change Screen Failed
40338 Host Command Knead Paste Failed
40365 Blocked Load of Invalid Product Format
40366 Blocked Download of Invalid Product Format
<<< End Modification
9.12 Limits Monitoring Events
EVENT - CEID
DESCRIPTION
31000-31200 Status Variables see section 5.5
32000-33000 Discrete Variables see section 5.5
