GEM Manual for DEK Printers Additional Capabilities
Issue 2.0 June 9th, 2011 page 138 of 156
10.1 Send Current Process Program Identity
Host to Equipment
The equipment will receive a Process Program ID Request message, Stream 7 Function 7.
The equipment will respond at any time with a Process Program ID Data message Stream 7 Function 8,
containing the filename of the process program currently loaded into the printer. If an error occurs the
response message will contain a zero length string.
Host requests current process program identity:
Comments Host Equipment Comments
Host requests current process
program ID.
S7F7 -->
<-- S7F8
Current process program ID.
Host to Equipment Message Structure:
Stream 7 Function 7
Header Only
Equipment to Host Message Structure:
Stream 7 Function 8
L,1
1. <PPID> up to 8 byte ASCII string
Error Response
L,0
GEM Manual for DEK Printers Additional Capabilities
Issue 2.0 June 9th, 2011 page 139 of 156
10.2 Upload Management Information
Host to Equipment
The equipment will receive a Data Transfer Request message Stream 6 Function 7, requesting
Management Information. The equipment will respond with a Data Transfer Data message Stream 6
Function 8, containing the Management Information as detailed below or if it cannot process the
message or an error occurs containing a zero length string.
Host requests that the equipment transfer the management information file to the host:
Comments Host Equipment Comments
Host requests upload of
Management Information.
S6F7 -->
<-- S6F8
<-- S6F8
[IF] equipment System Status = READY
upload Management information
[ELSE] file is not transferred
<L,0>
[END_IF]
Host to Equipment Message Structure:
Stream 6 Function 7
<DATAID> 0 = MANAGEMENT DATA, 2 byte signed integer
Equipment to Host Message Structure:
Stream 6 Function 8
L,3
1. <DATAID> 0 = MANAGEMENT DATA 2 byte signed integer
2. <CEID> 0 = HOST REQUEST 2 byte signed integer
3. L,2
1. <DSID> 0 = MANAGEMENT DATA 2 byte signed integer
2. L,n
1. L,2
1. <DVNAME 1>
2. <DVVAL 1>
.
.
n. L,2
1. <DVNAME n>
2. <DVVAL n>
