GEM Manual for DEK Printers Additional Capabilities
Issue 2.0 June 9th, 2011 page 150 of 156
10.5 Material Verification
The transfer material can be configured for verification when the applicator is either a paste dispenser
or refillable ProFlow device.
If the applicator is a paste dispenser the equipment reads the unique identifier contained in the RFID
tag. The tag is affixed to the material cartridge.
If the applicator unit is a refillable ProFlow device the equipment reads the unique identifier of the tag
fixed to the ProFlow head and also a sequential number stored in the data area of the tag. The
sequential number is written to the tag by an external device when the ProFlow head is recharged with
material. The unique identifier and sequential number are concatenated to produce an ID unique to that
head and material charge.
The following table lists the equipment variables associated with material verification. Full
information about these equipment variables can be found in section 7.
NAME TYPE ID DESCRIPTION
MaterialVerif EC 42 An equipment constant used to specify whether the
material verification feature is enabled or disabled
MaterialVerifState EC 43 An equipment constant used to drive the material
verification state machine. This is a model shared
between the host and the Printer. It is used to synchronise
verification activity.
SCValidatedMaterial EC 44 An equipment constant used to store the UID of the
material last validated by the host. The host should set
this value prior to attempting to set the material
verification state
Material RFID Tag Read
Failed
CE 40200 A collection event used to notify the host that the tag
read attempt has failed
Current Material UID
Changed
CE 40201 A collection event used to notify the host that the UID of
the currently fitted material has changed
CurrentMaterialUID SV 1047 A status variable that normally represents the unique
identification value of the currently loaded material
cartridge or ProFlow charge. However in the event that
the tag read fails it is set to one of the following values:
“0” – Cartridge not detected in dispenser
“-1” – Cartridge present but unable to detect the RFID
tag.
“-2” – Tag read failed due to hardware error.
ValidMaterialUID SV 1048 Represents the unique identification value of the last
validated material cartridge or ProFlow charge
<<< End Modification
GEM Manual for DEK Printers Appendix A
Issue 2.0 June 9th, 2011 page 151 of 156
11 Appendix A
11.1 REMOTE COMMANDS
This appendix details the valid commands and parameters that may be sent using the Remote
Command SECS II transaction, S2F41.
The commands and parameter names passed in S2F41 are ASCII, while the parameter values
are numeric or ASCII depending upon the command. The following table lists the valid
commands RCMD for both S2F21 and S2F41.
S2F41 RCMD (ASCII) S2F21 DESCRIPTION
START 0 Start processing with the currently loaded process program.
STOP 1 Stop processing at the end of the current print cycle.
ERASE_LOG 2 Delete all event log data.
ERASE_BATCH 3 Clear all batch data in the management information file.
ERASE_SESSION 4 Clear all session data in the management information file.
RENAME_PRODUCT
5 Rename process program to parameter value.
See parameter table below.
ADJUST_PARAMETER 6 Set process program parameter to new value.
See parameter table below.
CLEAN 7 Clean screen type 1 according to current process program
parameters.
CLEAN_2 none Clean screen type 2 according to current process program
parameters.
PASTE 8 Add paste automatically.
PP-SELECT none Select process program for execution.
See parameter table below.
CHANGE_SCREEN none Load or unload the screen using the method specified by the
parameter. See parameter table below.
KNEAD_PASTE none Use the next board that arrives to perform a paste knead cycle.
PAUSE none Pause print cycle operation running printer. Remote command
START (S2F41) or 0(S2F21) will resume printing. Remote
command STOP (S2F41) or 1(S2F21) will stop processing at
the end of the print cycle.
GEM Manual for DEK Printers Appendix A
Issue 2.0 June 9th, 2011 page 152 of 156
Remote Command Parameters:
PP
-SELECT Parameters
CPNAME (ASCII) DESCRIPTION CPVAL type min-max
RECEIVED_FILE_NAME Name of the process program to use. ASCII
RENAME_PRODUCT Parameters
CPNAME (ASCII) DESCRIPTION CPVAL type min-max
OLD_FILE_NAME The old name of the process program. ASCII
NEW_FILE_NAME The new name of the process program. ASCII
ADJUST_PARAMETER Parameters
CPNAME (ASCII) S2F21 DESCRIPTION CPVAL
type
Range Resol.
ADJUST_PASTE 0 Adjusts paste dispense rate. F8, none 0-100 1
ADJUST_SPEED 1 Adjusts both front and rear print
speeds.
F8, mm/s 2-150 1
ADJUST_FRONT_PRESS 2 Adjusts forward print pressure. F8, Kg 0-20 0.2
ADJUST_REAR_PRESS 3 Adjusts reverse print pressure. F8, Kg 0-20 0.2
ADJUST_GAP 4 Adjusts print gap. F8, mm 0-6 0.025
ADJUST_SEPARATE 5 Adjusts separation speed. F8, mm/s 0.1–20 0.1
ADJUST_CLEAN 6 Adjusts clean screen rate. F8, none
0−100 1
ADJUST_FWD_X 7 Adjusts forward X offset. F8, mm
±1
0.004
ADJUST_FWD_Y 8 Adjusts forward Y offset. F8, mm
±1
0.004
ADJUST_FWD_T 9
Adjusts forward θ offset.
F8, arcsec
±1000
2
ADJUST_REV_X 10 Adjusts reverse X offset. F8, mm
±1
0.004
ADJUST_REV_Y 11 Adjusts reverse Y offset. F8, mm
±1
0.004
ADJUST_REV_T 12
Adjusts reverse θ offset.
F8, arcsec
±1000
2
ADJUST_PROFLOW_PRESS - Adjusts Proflow print pressure. F8, Kg 0-20
0.2
ADJUST_INSP_RATE - Adjusts post print inspection
rate.
F8, none 0-100
1
ADJUST_BATCH_LIMIT - Adjusts batch limit.
0 = continuous operation.
U4, none 0-99999
1
ADJUST_FRONT_SPEED - Adjusts front print speed. F8, mm/s 2-150
1
ADJUST_REAR_SPEED - Adjusts rear print speed. F8, mm/s 2-150
1
CHANGE_SCREEN Parameters
CPNAME =
“CHANGE_METHOD”
DESCRIPTION CPVAL type
CPVAL = “AUTO” Exchange the screen in the printer (if present) with one in the
autochanger. Load the new screen to the position specified
by the process program.
ASCII
CPVAL = “MAN_LOAD” Load the screen in the printer to the position specified by the
process program.
ASCII
