GEM Manual for DEK Printers Machine GEM Compliance
Issue 2.0 June 9th, 2011 page 8 of 156
GEM Requirement
I G
ProductBarcodeHardware (ECID 64)
RemoteBarcodeHardware (ECID 65)
AdvancedProFlow (ECID 66)
PressureHardware (ECID 67)
PasteDispenser (ECID 68)
ScreenSize (ECID 69)
RollHeightHardware (ECID 70)
RHMOnFailureAction (ECID 71)
RollHeightMonitor (ECID 72)
ConsumableAction (ECID 73)
VacuumHoldTime (ECID 74)
2DiMovementTuning (ECID 75)
CleanerVacuum (ECID 76)
PasteTrails (ECID 77)
TransportWaitMode (ECID 78)
Reserved (ECID 79)
ClampType (ECID 80)
ToolingMonitoring (ECID 81)
Reserved (ECID 82)
FiducialMonitoring (ECID 83)
FiducialSearch (ECID 84)
RemoteBoardStopHardware (ECID 85)
BoardStopXOffset (ECID 86)
Reserved (ECID 87)
CameraIdlePosition (ECID 88)
UnloadBoardStart (ECID 89)
Reserved (ECID’s 90 – 94)
MaintenanceMonitoring (ECID 95)
MachineLocation (ECID 96)
AutoRailWidth (ECID 97)
ProductDirectory (ECID 98)
DataFileLocation (ECID 99)
Reserved (ECID 100)
DownLineBoardStop (ECID 101)
Reserved (ECID’s 102 - 103)
FrontRtoLSpeed (ECID 104)
FrontLtoRSpeed (ECID 105)
RearRtoLSpeed (ECID 106)
RearLtoRSpeed (ECID 107)
AltFrontRtoLSpeed (ECID 108)
AltFrontLtoRSpeed (ECID 109)
AltRearRtoLSpeed (ECID 110)
AltRearLtoRSpeed (ECID 111)
<<< End Modification
Status Variables (SVIDs)
GemAlarmsEnabled (SVID 1001)
GemAlarmsSet (SVID 1002)
GemAlarmState (SVID 1003)
GEM Manual for DEK Printers Machine GEM Compliance
Issue 2.0 June 9th, 2011 page 9 of 156
GEM Requirement
I G
clock (SVID 1004)
GemControlState (SVID 1005)
process_state (SVID 1006)
GemEventsEnabled (SVID 1007)
humidity (SVID 1008)
model_number (SVID 1009)
previous_command (SVID 1010)
GemPreviousControlState (SVID 1011)
last_process_state (SVID 1012)
GemPreviousCeid (SVID 1013)
software_version (SVID 1015)
temperature (SVID 1016)
current_time (SVID 1017)
system_mode (SVID 1018)
PPExecName (SVID 1019)
batch_count (SVID 1020)
time_last_print (SVID 1022)
spc_data_mode (SVID 1023)
screen_status (SVID 1024)
software_version_param (SVID 1025)
SpoolCountActual (SVID 1026)
SpoolCountTotal (SVID 1027)
SpoolFullTime (SVID 1028)
SpoolStartTime (SVID 1029)
Start Modification >>>
CurrentMaterialUID (SVID 1047)
ValidMaterialUID (SVID 1048)
PPChangeName (SVID 1050)
PPChangeStatus (SVID 1051)
PPError (SVID 1052)
PPFormat (SVID 1053)
<<< End Modification
Discrete Data Variables (DVIDs)
GemAlarmId (DVID 2001)
pp_old_file_name (DVID 2002)
pp_change_status (DVID 2003)
measured_cycle_time (DVID 2004)
throughput_cycle_time (DVID 2005)
ecid_changed (DVID 2007)
front_print_pressure (DVID 2008)
rear_print_pressure (DVID 2009)
print_speed (DVID 2010)
table_separation_speed (DVID 2011)
board_stretch_error (DVID 2012)
Xerr (DVID 2013)
Yerr (DVID 2014)
theta_err (DVID 2015)
Squeegee (DVID 2016)
GEM Manual for DEK Printers Machine GEM Compliance
Issue 2.0 June 9th, 2011 page 10 of 156
GEM Requirement
I G
current_screen_bar_code (DVID 2017)
old_time (DVID 2018)
new_time (DVID 2019)
product_bar_code (DVID 2020)
board_fiducial_1_score (DVID 2021)
board_fiducial_2_score (DVID 2022)
board_fiducial_3_score (DVID 2023)
screen_fiducial_1_score (DVID 2024)
screen_fiducial_2_score (DVID 2025)
screen_fiducial_3_score (DVID 2026)
LimitVariable (DVID 2027)
EventLimit (DVID 2028)
TransitionType (DVID 2029)
RemoteBarCode (DVID 2030)
ProflowPastePressure (DVID 2031)
Traceability Data (DVID 2033)
Failed Verification Item (DVID 2034)
front_print_speed (DVID 2086)
rear_print_speed (DVID 2087)
Modified Parameters (DVID 2088)
Events (CEIDs)
Control Model Events
Control State – Change to LOCAL (CEID 31450)
Control State – Change to OFF-LINE (CEID 31451)
Control State – Change to REMOTE (CEID 31452)
Operator command issued (CEID 31456)
Process Model Events
Equipment moved to Recovery state (CEID 90001)
Equipment moved to Setup state (CEID 90002)
Equipment moved to Ready state (CEID 90003)
Equipment moved to Maintenance state (CEID 90004)
Equipment moved to Waiting state (CEID 90005)
Equipment moved to Running state (CEID 90006)
Equipment moved to Down state (CEID 90007)
Process Program Management Events
Process program loaded (CEID 31265)
New process program created and loaded (CEID 31266)
Process program change (CEID 31267)
Product Data modified (CEID 31346)
Start Modification >>>
Operator deleted process program (CEID 32035)
<<< End Modification
Equipment Constant Change Events
Equipment constant change (CEID 31440)
